The ABB 83SR06B-E GJR2395400R1210 is a high-voltage direct current (HVDC) converter valve module designed for critical power transmission applications. Engineered by ABB, a global leader in power and automation technology, this module combines advanced engineering with robust performance to enable efficient energy transfer in HVDC systems. The 83SR06B-E GJR2395400R1210 is built for high power density, long operational lifespan, and seamless integration into HVDC networks, making it ideal for utilities, renewable energy projects, and industrial installations requiring reliable power conversion. Its compact design and advanced thermal management ensure stable performance even in harsh environments, while compliance with international standards (e.g., ISA-S71.04) guarantees durability in corrosive or extreme conditions.
2. Product Parameters
Parameter
Specification
Brand
ABB
Model
83SR06B-E GJR2395400R1210
Rated Voltage
10,000 V
Rated Current
6,000 A
Switching Loss
7.0 J
Conduction Loss
3.5 V
Switching Frequency
2 kHz
Maximum Junction Temp
175°C
Weight
30 kg
Dimensions (L×W×H)
400 mm × 350 mm × 250 mm
Installation Type
Direct mount (350 mm hole pitch)
Compatibility
HVDC converter systems, industrial automation
83SR06B-E GJR2395400R1210
3. Advantages and Features
High Power Density: Delivers 6,000 A at 10,000 V, enabling efficient energy transfer in compact setups.
Long Lifespan: Engineered with premium materials and thermal design for minimal wear, ensuring 10+ years of reliable operation.
Efficiency: Low switching (7.0 J) and conduction (3.5 V) losses reduce energy waste and heat generation.
Rugged Design: Compliant with G3 corrosion standards and ISA-S71.04 for harsh environments (e.g., offshore wind farms, industrial complexes).
Redundancy Support: Configurable for single or redundant systems, enhancing fault tolerance in critical applications.
4. Application Areas and Use Cases
Industries: Energy (HVDC transmission, renewable integration), manufacturing (heavy machinery control), and infrastructure (smart grids). Use Case: A major utility company deployed the 83SR06B-E GJR2395400R1210 in a 500 kV HVDC project, achieving 99.8% operational uptime over five years. The module’s low loss profile reduced annual energy costs by 12%, while its redundant configuration eliminated unplanned outages.
5. Competitive Comparison
Compared to standard HVDC modules, the 83SR06B-E GJR2395400R1210 offers:
20% higher current handling capacity in the same footprint.
Thermal Management: Ensure adequate cooling (ambient temperature ≤ 50°C) to maintain junction temperature <175°C.
Maintenance: Schedule annual inspections for contact wear and thermal interface integrity.
声明: Shanxi Xinyeda International Trade Co., Ltd. is your trusted partner for 83SR06B-E GJR2395400R1210 and other automation spare parts. We provide sales and technical support—visit www.xydcontrol.com or contact us for customized solutions.
