ABB 0745745Q

Product introduction

The ABB 0745745Q is a high-quality industrial terminal block designed for secure and reliable electrical connections in control cabinets, distribution panels, and automation systems. As a fundamental component in electrical infrastructure, this terminal block provides a safe and organized way to terminate, connect, and distribute electrical wires, ensuring efficient current flow and simplifying maintenance in industrial environments.

Featuring a 2-pole design with screw-clamp terminals, the ABB 0745745Q accommodates wire sizes from 0.5 mm² to 2.5 mm², making it suitable for a wide range of low to medium current applications. Its robust polyamide housing (flame-retardant to UL94 V0 standard) and copper contacts ensure durability and excellent conductivity, even in harsh conditions. The terminal block is designed for DIN rail mounting, allowing for quick and secure installation in standard control cabinets, which helps streamline panel assembly processes.

Ideal for use in manufacturing plants, power distribution systems, and building automation, the ABB 0745745Q meets global safety standards, providing peace of mind in critical electrical installations. Whether used to connect sensors, actuators, or control circuits, this terminal block delivers consistent performance, ensuring reliable electrical connections that minimize downtime and reduce the risk of faults.

Core advantages and technical highlights

Secure wire termination

The ABB 0745745Q features a screw-clamp termination design with M3.5 screws, ensuring firm and vibration-resistant wire connections. The clamping mechanism applies uniform pressure across the wire, preventing loosening over time—even in high-vibration environments such as near motors or heavy machinery. This reliability is critical in applications like conveyor systems, where loose connections could lead to unexpected shutdowns.

Wide wire compatibility

With a wire size range of 0.5 mm² to 2.5 mm² (AWG 20 to AWG 14), the terminal block accommodates both small control wires (e.g., 0.5 mm² for sensor signals) and larger power wires (e.g., 2.5 mm² for motor controls). This versatility eliminates the need for multiple terminal block types in a single panel, simplifying inventory management and reducing installation complexity.

High-temperature resistance

The terminal block’s polyamide housing is rated to operate in -40°C to 100°C environments, making it suitable for extreme conditions—from cold storage facilities to hot industrial plants. The material remains stable even at high temperatures, resisting deformation and maintaining insulation properties, which is essential for safety in enclosed control cabinets where heat can accumulate.

Flame-retardant construction

Compliant with UL94 V0 flammability standards, the ABB 0745745Q’s housing self-extinguishes quickly if exposed to fire, preventing the spread of flames in electrical panels. This feature enhances safety in critical applications such as power distribution cabinets, where fire risks could lead to widespread equipment damage or operational failures.

Easy installation and maintenance

Designed for 35mm DIN rail mounting (EN 50022), the terminal block can be quickly snapped into place without tools, speeding up panel assembly. Its compact design (standard 2-pole footprint) allows for high-density mounting, maximizing space efficiency in control cabinets. For maintenance, the clear labeling area and accessible screws make it easy to identify and rewire connections, reducing downtime during system modifications.

Typical application scenarios

Industrial control panels

In manufacturing control panels, the ABB 0745745Q connects various components such as PLC I/O modules, contactors, and push buttons. For example, it terminates 0.75 mm² wires from limit switches to the input module of an AC 800M controller, ensuring reliable signal transmission. The terminal block’s secure clamping prevents signal loss due to vibration, maintaining consistent communication between sensors and the control system.

Power distribution systems

In low-voltage distribution panels, the terminal block connects branch circuits to main power lines, distributing 16 A currents safely. Its 600 V AC rating allows use in three-phase systems, while the flame-retardant housing ensures compliance with electrical safety codes. For instance, it can terminate 2.5 mm² wires feeding lighting circuits or small motors, providing a neat and organized distribution point.

Building automation

In HVAC control systems, the ABB 0745745Q connects thermostats, actuators, and fan controllers. Its wide temperature range (-40°C to 100°C) allows installation in unconditioned spaces like rooftop equipment rooms, where temperature fluctuations are common. The terminal block’s secure connections ensure that control signals for damper actuators or valve controls remain stable, maintaining comfortable building environments.

Renewable energy installations

In solar inverter cabinets, the terminal block connects DC wiring from solar panels to the inverter’s input terminals. Its copper contacts ensure low resistance, minimizing power loss in the system. The flame-retardant housing and high-temperature tolerance make it suitable for outdoor inverter enclosures, where exposure to sunlight can raise internal temperatures.

ABB 0745745Q

Related model recommendations

ABB 0745746Q: A 3-pole variant of the ABB 0745745Q for three-phase connections or circuits requiring additional poles.

ABB 0745750Q: A 16 A terminal block with a larger wire range (0.5 mm² – 4 mm²) for higher-current applications.

ABB TB850 3BSE008519R1: A surge-protected terminal block that pairs with the ABB 0745745Q in high-EMI environments, such as near variable frequency drives.

ABB DIN rail 1SFA619501R1001: A 35mm DIN rail optimized for mounting the ABB 0745745Q and other terminal blocks in control cabinets.

ABB marking kit 1SFA619600R1000: Pre-printed labels for the ABB 0745745Q, simplifying identification of connections in complex panels.

ABB XO08R2 1SBP260109R1001: A digital output module that uses the ABB 0745745Q for terminal connections to field devices like solenoid valves.

Installation, commissioning and maintenance instructions

Installation preparation

Ensure the 35mm DIN rail (EN 50022) is securely mounted in the control cabinet, with adequate space for the terminal blocks (minimum 5mm between adjacent units for cooling).

Prepare wires by stripping 8-10mm of insulation, ensuring no stray strands remain (trim if necessary to prevent short circuits).

Gather required tools: a Phillips screwdriver (size 2) for terminal screws, wire strippers, and a torque wrench (set to 0.8-1.0 Nm for M3.5 screws).

Verify the application’s voltage (≤600 V AC / 250 V DC) and current (≤16 A) are within the terminal block’s ratings.

Installation steps

Snap the ABB 0745745Q onto the DIN rail, ensuring it locks into place with an audible click. For multiple terminal blocks, align them in a straight line to maintain organized wiring.

Loosen the terminal screws (do not remove) using the screwdriver, creating space for the wire. Insert the stripped end of the wire into the terminal clamp, ensuring the conductor is fully seated against the contact.

Tighten the screw to 0.8-1.0 Nm using the torque wrench, securing the wire firmly. Pull gently on the wire to confirm it is not loose.

Repeat for the second pole, ensuring wires are routed neatly (use cable ties if needed) to avoid strain on connections.

Label each terminal using the integrated marking area to identify the circuit function (e.g., “Sensor Input 1” or “Motor Control”).

Maintenance suggestions

Inspect the ABB 0745745Q quarterly for signs of loosening, corrosion, or overheating (discoloration of the housing). Retighten screws to 0.8-1.0 Nm if loose.

Check wire connections semi-annually, especially in high-vibration areas. Look for frayed wires or damaged insulation and replace as needed.

Clean the terminal blocks annually with a dry cloth or compressed air (low pressure) to remove dust, which can cause insulation issues. Do not use water or cleaning solvents.

During system upgrades, verify that new wires are within the 0.5-2.5 mm² range and that connections are properly tightened to prevent increased resistance.

Replace terminal blocks immediately if the housing is cracked, the screw is stripped, or there is evidence of arcing (blackened contacts), as these issues compromise safety and performance.

Service and guarantee commitment

The ABB 0745745Q comes with a 5-year warranty from the date of purchase, covering manufacturing defects such as faulty clamping mechanisms or defective materials. ABB guarantees that the terminal block will meet published performance specifications (rated current, voltage, and temperature range) under normal operating conditions.

Technical support is available through ABB’s global network of electrical component specialists, who can provide assistance with installation guidelines, compatibility checks, and application recommendations. Online resources include detailed dimensional drawings, material safety data sheets (MSDS), and compliance certificates. For bulk orders, ABB offers customized packaging and labeling options to streamline inventory management, ensuring the ABB 0745745Q integrates seamlessly into your electrical panel assembly processes.
