ABB 1SFB527068D7084

Description

Detailed Parameter Table

ABB 1SFB527068D7084

Product Introduction

The ABB 1SFB527068D7084 is a high-quality miniature circuit breaker from ABB’s System pro M compact S200 series. This single-pole 6A MCB with C tripping characteristic provides reliable protection against overloads and short circuits in residential and commercial electrical installations.

Engineered for safety and durability, this compact circuit breaker features a robust design with precise thermal-magnetic tripping mechanism. The 1SFB527068D7084 is particularly suitable for protecting lighting circuits, control circuits, and other applications with moderate inrush currents. Its screw-type terminals ensure secure connections and easy installation in distribution boards.

As part of ABB’s comprehensive circuit protection portfolio, this MCB combines German engineering quality with international safety standards, making it a trusted choice for electrical contractors and panel builders worldwide.

Core Advantages and Technical Highlights

Precise Protection:
The ABB 1SFB527068D7084 features a C characteristic tripping curve (5-10×In), making it ideal for circuits with moderate inrush currents like lighting and control circuits. The thermal-magnetic mechanism ensures reliable protection against both overloads and short circuits.

High Breaking Capacity:
With a 6kA breaking capacity at 230/400V AC, this MCB can safely interrupt high fault currents, protecting downstream equipment and wiring from damage.

Durable Construction:
The robust thermoplastic housing withstands mechanical stress and environmental factors. The silver-nickel contacts ensure long electrical life and reliable performance.

Easy Installation:
The screw terminals accept a wide range of conductor sizes (1-25mm²) and provide secure, vibration-resistant connections. The compact 1-module width (17.5mm) saves space in distribution boards.

Safety Features:
The 1SFB527068D7084 includes finger-safe terminals and a clear ON/OFF indication. The trip-free mechanism ensures protection even if the handle is held in the ON position during a fault.

Standards Compliance:
Certified to IEC/EN 60898-1 standards, this MCB meets international requirements for circuit protection in residential and commercial applications.

ABB 1SFB527068D7084

Typical Application Scenarios

Residential Buildings:
Protecting lighting circuits and socket outlets in homes and apartments, where the C characteristic provides optimal protection against moderate inrush currents.

Commercial Spaces:
Safeguarding control circuits for HVAC systems, office equipment, and retail lighting in shopping centers and office buildings.

Industrial Control Panels:
Protecting control circuits for machinery and automation equipment in manufacturing facilities.

Public Infrastructure:
Used in schools, hospitals, and municipal buildings for reliable circuit protection in essential services.

Renewable Energy Systems:
Protecting control circuits in solar PV installations and other distributed generation systems.

Related Model Recommendations

ABB 1SFB527069D7084: 10A version of same MCB

ABB 1SFB527070D7084: 16A version with C curve

ABB 1SFB527071D7084: 20A version with C curve

ABB 1SFB527072D7084: 25A version with C curve

ABB 1SFB527073D7084: 32A version with C curve

ABB 1SFB527078D7084: 6A version with B curve

ABB 1SFB527079D7084: 6A version with D curve

Installation & Commissioning

Installation Guidelines:
Mount on standard 35mm DIN rail in distribution boards. Use appropriate torque (2Nm) for terminal screws. Ensure proper conductor stripping length (10mm). Maintain adequate clearance for heat dissipation.

Commissioning:
Verify proper mechanical operation by manually testing the ON/OFF mechanism. Conduct insulation resistance tests before energizing. Check proper load connection and polarity.

Maintenance:
Regularly inspect for signs of overheating or damage. Test trip mechanism periodically by pressing the test button. Replace if unable to reset properly after tripping.

Service & Warranty

ABB provides a 12-month warranty for the 1SFB527068D7084, covering manufacturing defects. Technical support is available through ABB’s electrical distribution specialists. The product is supported by ABB’s global supply chain, with replacement units readily available.

Conclusion

The ABB 1SFB527068D7084 miniature circuit breaker delivers reliable circuit protection with its precise C characteristic tripping and robust construction. Its combination of safety features, easy installation, and compact design makes it an excellent choice for residential and commercial electrical installations. For specific application requirements or technical assistance, consult ABB’s electrical distribution experts.
