ABB 1SVR011700R0000

Product introduction

The 1SVR011700R0000 is a high-efficiency DIN rail-mounted power supply from ABB, designed to deliver stable 24 V DC power to industrial control systems and automation components. As a reliable power source in ABB’s industrial power portfolio, it converts alternating current (AC) from the mains into clean, regulated direct current (DC) for devices such as PLC modules, sensors, actuators, and relays.

Engineered for versatility, the 1SVR011700R0000 accepts a wide input voltage range (100-240 V AC), making it suitable for global applications without hardware modifications. Its compact 39 mm width allows easy integration into crowded control cabinets, while its robust design ensures consistent performance in harsh industrial environments—from manufacturing plants to outdoor enclosures. Whether powering an AI523 1SAP250300R0001 analog module or a network of sensors, the 1SVR011700R0000 provides the stable voltage critical for reliable system operation.

Core advantages and technical highlights

Wide operating temperature range

The 1SVR011700R0000 performs reliably from -25°C to +70°C, making it suitable for extreme environments. In a food processing plant with cold storage areas, it continues supplying power to temperature sensors and control modules even when cabinet temperatures drop to -10°C. In steel mills, where ambient temperatures can reach 60°C near furnaces, its thermal protection prevents shutdowns, ensuring uninterrupted operation of critical PLC components.

High efficiency and energy savings

With up to 92% efficiency at full load, the 1SVR011700R0000 minimizes energy waste compared to lower-efficiency power supplies. In a factory with 50 control cabinets each using a 1SVR011700R0000, this efficiency translates to annual energy savings of approximately 3,000 kWh—reducing operational costs and environmental impact. Its low no-load power consumption (≤1 W) further cuts energy use during idle periods.

Comprehensive protection features

The 1SVR011700R0000 includes multiple safeguards: short circuit protection prevents damage during wiring faults, overvoltage protection shields connected devices from voltage spikes, and overtemperature protection shuts down the unit if it exceeds 70°C, preventing fire risks. In a water treatment plant, if a sensor wire accidentally shorts, the power supply limits output current to safe levels, protecting expensive PLC modules like the AI523 1SAP250300R0001 from damage.

ABB 1SVR011700R0000

Typical application scenarios

In an automotive assembly line control cabinet, the 1SVR011700R0000 serves as the primary power source for a network of automation components:

• AI523 1SAP250300R0001analog modules monitoring conveyor belt tension
• Digital input modules tracking limit switch statuses
• Solenoid valve drivers controlling part grippers
• Ethernet switches enabling communication between devices

The power supply’s 10 A capacity easily handles these loads, while its stable 24 V output ensures accurate signal measurements from the AI523 1SAP250300R0001. During voltage fluctuations common in manufacturing facilities, its tight regulation (±0.5%) prevents erroneous sensor readings or controller malfunctions.

In a remote water pumping station, the 1SVR011700R0000 operates in an outdoor cabinet, powering a small PLC system, level sensors, and valve actuators. Its wide temperature range and rugged design ensure reliable performance through winter cold and summer heat, eliminating the need for climate-controlled enclosures.

Related model recommendations

• 1SVR011701R0000: A 5 A version of the 1SVR011700R0000, ideal for smaller systems with lower power demands.
• 1SVR011703R0000: A 20 A higher-capacity power supply, suitable for systems requiring more current than the 1SVR011700R0000.
• 1SVR405611R0000: ABB’s redundant power supply module that pairs with the 1SVR011700R0000for fault-tolerant systems.
• AI523 1SAP250300R0001: Analog input module commonly powered by the 1SVR011700R0000in control systems.
• 1SNA646101R1200: ABB terminal block used to distribute 1SVR011700R0000output to multiple devices.
• 1SVR040060R0000: Surge protection device that safeguards the 1SVR011700R0000from voltage spikes.

Installation, commissioning and maintenance instructions

Installation preparation

Before installing the 1SVR011700R0000, ensure the input power is disconnected. Mount the unit on a 35 mm DIN rail, leaving at least 10 mm of clearance above and below for airflow. Use 1.5 mm² wires for input connections and 2.5 mm² wires for output, stripping 8 mm of insulation. Connect the AC input (L, N, PE) to terminals 1-3 and DC output (positive, negative) to terminals 4-5. Verify proper grounding to ensure safety and reduce electrical noise, especially when powering sensitive modules like the AI523 1SAP250300R0001.

Maintenance suggestions

Check the 1SVR011700R0000’s green LED daily to confirm normal operation—a red LED indicates a fault (overload, overtemperature, or short circuit). Clean the unit quarterly with compressed air to remove dust, which can impede cooling. Inspect wiring connections annually for tightness and corrosion, tightening screws to 1.2 Nm if needed. If a fault occurs, disconnect non-essential devices to reduce load; the power supply will auto-recover once the issue is resolved. Replace the 1SVR011700R0000 with an ABB-approved spare if faults persist, ensuring compatibility with connected equipment.

Service and guarantee commitment

The 1SVR011700R0000 is backed by a 5-year warranty, reflecting ABB’s confidence in its durability and performance. This coverage includes defects in materials and workmanship under normal operating conditions. ABB’s technical support team provides 24/7 assistance for installation and troubleshooting, including guidance on proper wiring and integration with devices like the AI523 1SAP250300R0001.

Customers receive access to detailed installation manuals and technical data sheets. ABB’s global distribution network ensures fast delivery of replacement units, minimizing downtime in critical systems. Trust the 1SVR011700R0000 to deliver reliable power, backed by ABB’s expertise in industrial electrical components.
