ABB 3BDH000320R0101 | AC 800M Controller Module

  • Brand:​ ABB
  • ••
    Model:​ 3BDH000320R0101
  • ••
    Product Type:​ Process Controller (CPU Module)
  • ••
    Series:​ AC 800M
  • ••
    Core Function:​ Serves as the central processing unit for ABB’s System 800xA distributed control system (DCS), executing regulatory control, logic, and sequencing functions.
  • ••
    Key Specs:​ High-performance processor, redundant configuration support, extensive I/O capacity.
Get a Quote
Manufacturer:
Part number: ABB 3BDH000320R0101
Our extensive catalogue, including : ABB 3BDH000320R0101 , is available now for dispatch to the worldwide.

Description

3BDH000320R0101: Product Overview
The 3BDH000320R0101 is a high-performance controller module within ABB’s AC 800M series, designed for System 800xA distributed control system (DCS) applications. This module functions as the computational core of the control system, executing complex control strategies including regulatory control algorithms, sequence logic, and advanced process optimization. Installed in an AC 800M controller baseplate, it manages all controller operations, including scanning I/O modules via various fieldbus networks, executing application programs, and handling communication with operator stations.
The controller operates as part of a modular system architecture where it coordinates with other modules in the controller chassis. It runs the control application program developed with ABB’s Control Builder engineering tool, processing real-time data from field devices and executing control commands with deterministic performance. The controller’s design focuses on high availability, cybersecurity, and seamless integration for continuous process operations in demanding industrial environments.

ABB 3BDH000320R0101

ABB 3BDH000320R0101

3BDH000320R0101: Technical Specifications
  • ••
    Model Number:​ 3BDH000320R0101
  • ••
    Manufacturer:​ ABB
  • ••
    Product Type:​ Process Controller (CPU)
  • ••
    Compatible System:​ System 800xA DCS
  • ••
    Processor:​ High-performance processor
  • ••
    Memory:​ Extensive application memory
  • ••
    Communication Ports:​ Ethernet ports for system and plant network
  • ••
    Fieldbus Support:​ PROFIBUS DP, PROFINET, Modbus TCP, IEC 61850
  • ••
    Redundancy:​ Supports 1:1 redundancy
  • ••
    Power Supply:​ 24V DC via power supply module
  • ••
    Operating Temperature:​ 0°C to 60°C
  • ••
    Relative Humidity:​ 5% to 95% non-condensing
  • ••
    Certifications:​ UL, CE, cULus

    ABB 3BDH000320R0101

    ABB 3BDH000320R0101

Core Features & Customer Value
The controller’s high-performance processor provides substantial computational power for complex control strategies including multi-variable predictive control, custom algorithms, and sophisticated sequencing logic. For process engineers, this enables implementation of advanced control schemes that improve process stability, product quality, and energy utilization. The deterministic execution ensures consistent control loop performance, which is critical for maintaining process variables within tight tolerances in continuous process industries.
Integrated support for multiple fieldbus protocols allows the controller to communicate with a wide range of field devices and remote I/O stations. This flexibility enables integration of diverse equipment into a unified control strategy, reducing system complexity and lifecycle costs. The controller’s high availability features, including 1:1 redundancy support, ensure continuous operation even during maintenance activities or component failures.
Typical Applications
In chemical processing plants, the 3BDH000320R0101 executes batch recipes for reactor control, managing precise temperature and pressure profiles while coordinating material addition and product transfer sequences. The batch management capabilities ensure recipe consistency and regulatory compliance.
In power generation facilities, the controller manages turbine control, boiler management, and balance-of-plant systems. The wide operating temperature range makes it suitable for installation in both control rooms and field enclosures where environmental conditions may vary.
