ABB 3BHB030310R0001 & 5SHY4045L0006: Product Overview
This pairing consists of a control unit and a high-power IGCT module, designed to operate as a unified solution in ABB medium- and high-voltage drive systems (e.g., ACS5000, ACS6000 series). The control unit (3BHB030310R0001) serves as the central processing component, executing logic operations, managing signal conditioning, and generating drive signals for the IGCT module. The IGCT module (5SHY4045L0006) functions as the power conversion element, handling high-current switching and energy transfer. Together, they interface with DCS/PLC architectures to regulate motor speeds, stabilize power grids, or transmit energy in HVDC applications.
The combination belongs to ABB’s modular automation platform, which prioritizes interoperability and scalability. The control unit’s software-configurable I/O and the IGCT module’s standardized packaging simplify system integration, while shared diagnostic tools streamline maintenance. This pairing is engineered for applications requiring precise power management under high-stress conditions, such as industrial motor drives and power transmission systems.
ABB 3BHB030310R0001 & 5SHY4045L0006
ABB 3BHB030310R0001 & 5SHY4045L0006: Technical Specifications
-
Model Number (Control Unit): 3BHB030310R0001
-
Manufacturer: ABB Ltd.
-
Product Type: Control Unit (CPU Module)
-
Rated Current: 40A (control side)
-
Operating Temperature: -25°C to +70°C
-
Communication Interfaces: Ethernet, RS-485, CAN, USB
-
Mounting: DIN rail or bolt-on
-
Protection Rating: IP20
-
Dimensions: 217mm (H) x 68.5mm (W) x 63mm (D)
-
Weight: 1kg
-
Certifications: CE, UL (cULus Listed)
-
Model Number (IGCT Module): 5SHY4045L0006
-
Manufacturer: ABB Ltd.
-
Product Type: Integrated Gate-Commutated Thyristor (IGCT) Module
-
Rated Current: 4000A (continuous)
-
Rated Voltage: 45kV (blocking)
-
Switching Frequency: Up to 1.6kHz
-
Cooling Method: Water or natural cooling
-
Operating Temperature: -40°C to +125°C (case)
-
Protection Rating: IP20
-
Dimensions: Approx. 100mm (L) x 50mm (W) x 30mm (H) (TO-247AB package)
-
Weight: Approx. 4kg
-
Certifications: CE, UL (cULus Listed), RoHS
ABB 3BHB030310R0001 & 5SHY4045L0006
Core Features & Customer Value
The control unit’s high-speed processing (150/60Hz task execution) enables real-time adjustment of drive parameters, critical for applications like steel mill roller speed control. Its hot-swappable design and self-diagnostic logging reduce downtime during maintenance. For engineers, this means fewer unplanned outages and simplified troubleshooting. The IGCT module’s low conduction loss (minimized on-state voltage drop) and fast switching (<1μs turn-off) improve system efficiency, lowering operational costs. Its rugged construction withstands vibration and temperature extremes, making it suitable for rail traction or mining environments.
Together, the pairing offers modular scalability. The control unit supports expansion slots for additional I/O, while the IGCT module can be paralleled to increase current capacity (up to 8000A). This flexibility allows adaptation to evolving system demands without full redesign. For procurement managers, this reduces lifecycle costs by extending component reuse across projects.
Typical Applications
In steel rolling mills, the control unit coordinates multi-axis synchronization while the IGCT module regulates main roller motor torque, ensuring consistent strip thickness. For HVDC transmission, the IGCT module handles high-voltage power conversion, and the control unit manages grid synchronization and fault response. In rail traction, the pairing powers locomotive inverters, with the control unit adjusting for load variations and the IGCT module managing regenerative braking energy. Another application is in cement plant conveyors, where the system optimizes motor speed to match material feed rates, reducing energy waste.
