ABB 3BHE009017R0102

Description

Detailed Parameter Table

3BHE009017R0102

Product introduction

The 3BHE009017R0102 is a high – performance power supply module developed by ABB, specifically designed to provide stable and reliable 24 V DC power for industrial control systems. It is an essential component in ensuring the smooth operation of various automation equipment, converting alternating current from the mains into a clean direct current that meets the strict requirements of sensitive electronic components.

This power supply module integrates seamlessly with ABB’s automation products, such as the DSTS104 3BSE007285R1 safety relay module and the DC541-CM 1SAP270000R0001 controller module. The 3BHE009017R0102 delivers consistent power to these critical components, ensuring they can perform their functions accurately and without interruption, even in harsh industrial environments.

With its high efficiency, robust protection features, and wide operating temperature range, the 3BHE009017R0102 is suitable for a wide range of industrial applications, including manufacturing plants, power generation facilities, and process control systems. It provides a reliable power source that helps maintain the integrity and performance of the entire automation system.

Core advantages and technical highlights

High efficiency and energy saving

The 3BHE009017R0102 boasts an efficiency of ≥ 90% at full load, which is significantly higher than many conventional power supply modules. This high efficiency not only reduces energy consumption but also minimizes heat generation, allowing the module to operate reliably in confined spaces within control cabinets. In a large – scale manufacturing plant with numerous control systems, the cumulative energy savings from using the 3BHE009017R0102 can be substantial, leading to lower operational costs.

Comprehensive protection mechanisms

Equipped with overcurrent, overvoltage, short – circuit, and overtemperature protection, the 3BHE009017R0102 provides comprehensive safeguards for both itself and the connected equipment. In the event of a short – circuit in a downstream component like the DSTS104 3BSE007285R1 safety relay, the power supply module immediately shuts down to prevent damage. Once the fault is resolved, it automatically restarts, minimizing downtime and ensuring the rapid recovery of the system.

Wide operating range and reliability

The 3BHE009017R0102 can operate within an input voltage range of 110 – 240 V AC, making it suitable for use in different regions with varying mains voltages. Its operating temperature range of – 25°C to +70°C allows it to function reliably in extreme environmental conditions, such as cold storage facilities or hot industrial plants. The module’s high MTBF (≥ 100,000 hours) is a testament to its long – term reliability, reducing the need for frequent replacements and maintenance.

3BHE009017R0102

Typical application scenarios

In a large – scale automotive assembly plant, the 3BHE009017R0102 is installed in the control cabinet of a robotic welding system. It supplies stable 24 V DC power to the DC541-CM 1SAP270000R0001 controller, the DSTS104 3BSE007285R1 safety relay, and various I/O modules. During peak production periods, when multiple components are operating simultaneously, the power supply module’s 10 A output current ensures there is sufficient power for all devices, preventing voltage drops that could affect system performance.

In a power generation facility, the 3BHE009017R0102 provides power to the control system of a turbine. It delivers clean power with low ripple and noise, ensuring accurate signal processing in the AI810 3BSE008516R0001 analog input module, which monitors critical turbine parameters such as temperature and pressure. The module’s ability to withstand voltage fluctuations in the mains supply ensures the control system remains stable, contributing to the safe and efficient operation of the turbine.

In a chemical processing plant, the 3BHE009017R0102 is used to power the control components of a reactor system. It supplies power to the DO524 A3 1SAP240700R0001 digital output module, which controls the valves and pumps in the reactor. The power supply’s overtemperature protection is particularly valuable in this environment, where high ambient temperatures could otherwise affect the performance of the control system. The 3BHE009017R0102 ensures the valves and pumps operate precisely, maintaining the correct reaction conditions in the reactor.

Related model recommendations

• 3BHE009018R0101: A higher – power version of the 3BHE009017R0102with an output current of 20 A, suitable for systems with more power – hungry components.
• DSTS104 3BSE007285R1: A safety relay module that relies on the 3BHE009017R0102for stable 24 V DC power to perform its safety monitoring functions.
• DC541-CM 1SAP270000R0001: A controller module that is powered by the 3BHE009017R0102and uses the power supply’s reliable output to process and execute control logic.
• AI810 3BSE008516R0001: An analog input module that receives power from the 3BHE009017R0102to accurately measure and transmit analog signals from sensors.
• TB820V2 3BSE013208R1: A terminal base that connects the 3BHE009017R0102to other modules, providing a secure and organized wiring interface.
• SINT4611C: A similar power supply module with a 10 A output, which can be used as a backup or alternative to the 3BHE009017R0102in certain applications.

Installation, commissioning and maintenance instructions

Installation preparation

Before installing the 3BHE009017R0102, ensure the control cabinet is clean, dry, and well – ventilated. The ambient temperature should be within the range of – 25°C to +70°C, and the relative humidity should not exceed 95% (non – condensing). Required tools include a screwdriver, wire strippers, and a torque wrench.

Mount the 3BHE009017R0102 on a 35 mm DIN rail, leaving at least 20 mm of space around it for heat dissipation. Connect the input power (110 – 240 V AC) to the appropriate terminals, ensuring correct phase and neutral connections. For the output, use 0.5 – 2.5 mm² wires to connect to the devices that require power, such as the DSTS104 3BSE007285R1 and DC541-CM 1SAP270000R0001. Make sure all connections are tight to avoid loose contacts and potential overheating.

Maintenance suggestions

For daily maintenance of the 3BHE009017R0102, visually inspect the module for any signs of damage, such as bulging capacitors or burn marks. Check the input and output connections regularly to ensure they are secure. Use a multimeter to measure the output voltage periodically, ensuring it remains within the 24 V DC ± 0.5 V range.

If the 3BHE009017R0102 shuts down due to a fault, first identify and resolve the cause of the fault, such as a short – circuit in a connected module. Once the fault is cleared, the module should restart automatically. If it does not, check the power supply’s fuses and replace them if necessary. When replacing the 3BHE009017R0102, always use an authentic ABB replacement part to ensure compatibility and performance. Keep a record of all maintenance activities and voltage measurements for future reference.

Service and guarantee commitment

ABB provides a comprehensive service and guarantee for the 3BHE009017R0102. The product comes with a 3 – year warranty, during which any defects in materials or workmanship will be repaired or replaced free of charge. ABB’s global technical support team is available to assist customers with installation, commissioning, and troubleshooting issues related to the 3BHE009017R0102.

Our technical experts can provide guidance on system integration, ensuring the 3BHE009017R0102 works seamlessly with other ABB components like the DSTS104 3BSE007285R1 and DC541-CM 1SAP270000R0001. We also offer training programs to help customers understand the operation and maintenance of the power supply module. ABB is committed to ensuring the reliability and performance of the 3BHE009017R0102, providing customers with peace of mind and support throughout the product’s lifecycle.
