ABB 3BHE023784R2530 PPD113B01-25-111000

Description

Detailed parameter table

ABB 3BHE023784R2530 PPD113B01-25-111000

Product introduction

The ABB 3BHE023784R2530 PPD113B01-25-111000 is a compact yet robust power distribution module designed to provide reliable power management for industrial control systems. As a key component in ABB’s power distribution portfolio, ABB 3BHE023784R2530 PPD113B01-25-111000 integrates 12 regulated 24 V DC circuits and 6 unregulated 110 V DC circuits, offering versatile power distribution for a mix of low-voltage and medium-voltage devices in control cabinets.

ABB 3BHE023784R2530 PPD113B01-25-111000 features per-circuit protection mechanisms that isolate faults to prevent system-wide outages, ensuring continuous operation of critical components. Its flexible input (110-250 V AC/DC) makes it suitable for global applications, while its compact design saves valuable cabinet space. Whether paired with turbine control modules like the ABB DKTFM418B 3BHB015651P0001 or supporting safety modules such as the UNC4672AV1, ABB 3BHE023784R2530 PPD113B01-25-111000 simplifies power system design, enhances reliability, and streamlines maintenance in industrial environments.

Core advantages and technical highlights

Mixed voltage output: ABB 3BHE023784R2530 PPD113B01-25-111000 combines 12 x 24 V DC and 6 x 110 V DC outputs, eliminating the need for separate power distribution units for different voltage requirements. In a turbine control cabinet, this allows powering of 24 V devices (e.g., DKTFM418B control module, DSCA114 analog input module) and 110 V components (e.g., contactor coils, solenoid valves) from a single module, reducing wiring complexity and cabinet footprint by up to 30%.

Global input compatibility: With an input range of 110-250 V AC/DC, ABB 3BHE023784R2530 PPD113B01-25-111000 operates seamlessly in regions with different electrical standards, from 110 V AC grids in North America to 220 V AC systems in Europe and Asia. This universality simplifies inventory management for multinational industrial operations, as a single module model can be deployed worldwide.

Advanced protection mechanisms: Each output circuit includes adjustable overcurrent protection (0.5-1.5 A for 24 V, 1-3 A for 110 V), while the module also features short circuit, overtemperature, and reverse polarity protection. In a chemical plant’s control system, this multi-layered protection prevents a shorted 110 V valve solenoid from affecting 24 V sensors and communication modules, ensuring critical process data continues to flow to the DCS.

Regulated DC stability: The 24 V DC outputs maintain voltage within ±2% of nominal (23.5-24.5 V) across load variations, ensuring reliable operation of sensitive electronics like the XVC517AE10 HMI and CI627A communication module. Low ripple (<80 mV peak-to-peak) prevents interference with analog signals, critical for accurate sensor data acquisition in turbine control applications.

Typical application scenarios

In a gas turbine control panel, ABB 3BHE023784R2530 PPD113B01-25-111000 distributes power to the DKTFM418B turbine control module (24 V), DSCA114 analog input modules (24 V), and 110 V components such as fuel valve actuators and alarm buzzers. When a 110 V actuator develops a short circuit, the module’s per-circuit protection trips only that circuit, allowing the turbine control module and sensors to continue operating—preventing an unnecessary turbine shutdown. Its compact size fits easily alongside other components in the crowded control cabinet.

In a water treatment plant’s SCADA cabinet, ABB 3BHE023784R2530 PPD113B01-25-111000 powers 24 V devices (PLC, HMI, RXIDK 2H digital inputs) and 110 V equipment (pump contactors, valve solenoids). The module’s 110-250 V AC input allows it to operate from the plant’s 220 V AC supply, while its regulated 24 V outputs ensure stable performance of the PLC and communication modules. During a voltage surge, its overvoltage protection clamps the input, safeguarding sensitive electronics from damage.

ABB 3BHE023784R2530 PPD113B01-25-111000

Related model recommendations

ABB DKTFM418B 3BHB015651P0001: A turbine control module powered by ABB 3BHE023784R2530 PPD113B01-25-111000’s 24 V DC circuits.

ABB XVC517AE10 3BHB004744R0010: An HMI panel that receives stable 24 V power from ABB 3BHE023784R2530 PPD113B01-25-111000.

ABB DSCA114 57510001-AA: An analog input module powered by ABB 3BHE023784R2530 PPD113B01-25-111000.

ABB CI627A 3BSE017457R1: A communication module that uses ABB 3BHE023784R2530 PPD113B01-25-111000 for reliable power.

ABB 200900-004: A terminal block used to distribute outputs from ABB 3BHE023784R2530 PPD113B01-25-111000 to field devices.

ABB TB857: A surge protection device installed upstream of ABB 3BHE023784R2530 PPD113B01-25-111000 to shield against input transients.

Installation, commissioning and maintenance instructions

Installation preparation: Mount ABB 3BHE023784R2530 PPD113B01-25-111000 on a 35 mm DIN rail in a control cabinet, ensuring 50mm clearance above and below for ventilation. Connect input power (110-250 V AC/DC) using 1.5mm² cable, protected by a 10A circuit breaker. Adjust 24 V circuit overcurrent settings (0.5-1.5 A) and 110 V settings (1-3 A) using the front-panel potentiometers before connecting loads. Wire outputs to devices via 200900-004 terminal blocks, using 0.75mm² cable for 24 V circuits and 1mm² for 110 V circuits. Ground the module via the dedicated earth terminal. Use a torque screwdriver set to 1.0 Nm for all connections. Power off the input supply during installation.

Maintenance suggestions: Inspect ABB 3BHE023784R2530 PPD113B01-25-111000 quarterly for loose connections, dust accumulation, and LED status (power: green, circuit faults: red per channel). Clean ventilation slots with compressed air. Measure output voltage semi-annually under full load to ensure 24 V circuits remain within 23.5-24.5 V. Test overcurrent protection annually by simulating overloads on each circuit and verifying trip functionality. Replace faulty circuits with ABB-approved fuses only. If regulation fails or protection features malfunction, replace the module with an ABB-certified unit to maintain system safety.

Service and guarantee commitment

ABB 3BHE023784R2530 PPD113B01-25-111000 is backed by a 5-year warranty from installation, covering manufacturing defects and ensuring protection features operate within published specifications. ABB’s technical support team provides response within 6 hours for standard inquiries, with troubleshooting guidance available during business hours.

The warranty includes access to installation guides and configuration tools. Extended service contracts offer annual performance verification and priority support, ensuring the module maintains reliable power distribution throughout its 15-year design lifespan. ABB’s commitment to quality underscores confidence in ABB 3BHE023784R2530 PPD113B01-25-111000 as a durable foundation for industrial control system power management.
