Brand: ABB
Model: DSTA001B
Product Code: 3BSE018316R1
Product Type: Analog Connection Unit
Series: Advant OCS (Advanced Open Control System)
Core Function: Provides electrical connectivity between the DSAX 110A analog board and ABB’s Advant OCS control system, enabling reliable analog signal transmission (e.g., 4-20mA, 0-10V) for process control applications.
Manufacturer: ABB Part number: ABB 3BSE018316R1 DSTA001B
Our extensive ABB catalogue, including
: ABB 3BSE018316R1 DSTA001B
, is available now for dispatch to the worldwide.
ABB DSTA001B 3BSE018316R1: Product OverviewThe ABB DSTA001B (3BSE018316R1) is a specialized analog connection unit within ABB’s Advant OCS series, engineered to facilitate seamless communication between the DSAX 110A analog input/output (I/O) board and the Advant OCS control system. As part of ABB’s legacy industrial automation portfolio, this module plays a critical role in process control environments where reliable analog signal transmission (e.g., from sensors, transducers, or actuators) is essential for maintaining operational efficiency and product quality.Its primary function is to act as an electrical interface, converting and routing analog signals between the DSAX 110A board and the control system’s processing units. This ensures that critical process variables—such as temperature, pressure, flow, or level—are accurately measured, transmitted, and used for closed-loop control. The module’s robust design (industrial-grade materials, compact form factor) makes it suitable for harsh industrial environments, including manufacturing plants, power generation facilities, and water treatment facilities.Functionally, the DSTA001B supports multiple analog signal types (compatible with DSAX 110A specifications) and includes built-in circuitry for signal conditioning (e.g., filtering, amplification) to minimize noise and ensure signal integrity. It uses standardized electrical connectors (per Advant OCS guidelines) for easy integration with existing control panels or I/O racks, reducing installation time and complexity for engineers.For continuous process industries—such as oil refining or chemical manufacturing—this module mitigates risks associated with signal loss or corruption, which could lead to unplanned downtime or product defects. Maintenance teams benefit from its modular design, which allows for quick replacement in case of failure, minimizing mean time to repair (MTTR).
Compatibility: Designed exclusively for ABB DSAX 110A analog boards.
Dimensions:
Depth: 540mm
Height: 30mm
Width: 335mm
Net Weight: 0.222kg
Operating Temperature Range: -25°C to +70°C
Signal Support: Compatible with analog signals supported by DSAX 110A (e.g., 4-20mA, 0-10V; refer to DSAX 110A datasheet for exact specifications).
Connectivity: Uses industrial-grade electrical connectors (per Advant OCS standards) for secure integration with control panels or I/O racks.
RoHS Compliance: Exempt under EU Directive 2011/65/EU (confirmed by manufacturer documentation).
ABB DSTA001B 3BSE018316R1
Core Features & Customer ValueSeamless Integration with Advant OCS: The DSTA001B is engineered to work exclusively with ABB’s Advant OCS system and DSAX 110A analog boards, ensuring plug-and-play compatibility and eliminating the need for custom wiring or configuration. This reduces integration time and costs for engineers, who can leverage their existing knowledge of Advant OCS architecture.Robust Industrial Design: Built to withstand harsh conditions—including extreme temperatures (-25°C to +70°C), vibration, and electrical noise—the module delivers reliable performance in environments where lesser components would fail. Its compact size (540x30x335mm) allows for easy installation in space-constrained control panels or I/O racks, making it ideal for retrofit projects or new installations.Accurate Signal Transmission: By supporting high-integrity analog signals (compatible with DSAX 110A), the DSTA001B ensures that critical process variables are transmitted without distortion. This is essential for maintaining precise control in applications like chemical processing or power generation, where even minor signal errors can lead to significant quality issues or safety risks.Easy Maintenance: The module’s modular design allows for quick replacement in case of failure, minimizing downtime. Maintenance teams can replace the DSTA001B without disrupting the entire control system, reducing the impact of unplanned outages on production.Typical ApplicationsThe ABB DSTA001B 3BSE018316R1 is deployed in a wide range of industrial automation environments where reliable analog signal transmission is critical:
Process Control: In chemical plants, the module connects DSAX 110A analog boards to sensors measuring temperature, pressure, or flow, enabling closed-loop control of reactors or distillation columns. Its robust design ensures consistent performance in high-temperature, corrosive environments.
Power Generation: In thermal power plants, the DSTA001B facilitates communication between DSAX 110A boards and sensors monitoring boiler pressure or turbine speed, helping to optimize power output and prevent equipment damage.
Manufacturing Automation: In automotive or electronics manufacturing, the module supports analog signal transmission for robotic arms, conveyor systems, or quality control sensors, ensuring precise operation and product consistency.
Water Treatment: In municipal water facilities, the DSTA001B connects DSAX 110A boards to sensors measuring water level, flow rate, or chemical dosage, enabling automated treatment processes and compliance with environmental regulations.
