3HNE09058-1: Product Overview
The ABB 3HNE09058-1 is a specialized signal cable designed for ABB industrial robots, specifically for connecting the A3 valve group to the robot’s control system. As a critical spare part, it enables reliable transmission of valve status signals (e.g., open/close commands, position feedback) between the robot and peripheral equipment (e.g., grippers, welding torches). This ensures precise coordination in applications like material handling, assembly, and welding, where timing and accuracy are essential.
Role in Automation Systems:
Positioned as a “signal bridge” in the robot ecosystem, the 3HNE09058-1 performs two primary functions:
-
Signal Transmission: Carries digital/analog signals from the A3 valve group to the robot controller, allowing the robot to adjust its movements based on valve status (e.g., pausing to wait for a valve to open).
-
System Coordination: Synchronizes the robot’s actions with peripheral devices, ensuring seamless integration in automated production lines (e.g., in an automotive assembly plant, the cable enables the robot to pick up a part only after the valve releases it).
Core Functionality:
-
Valve Signal Support: Designed to handle signals from 2 valves, making it suitable for applications requiring multiple valve controls.
-
Industrial-Grade Durability: Constructed with robust insulation and shielding to resist electromagnetic interference (EMI) and mechanical stress (e.g., vibration, bending) in harsh industrial environments.
-
Plug-and-Play Compatibility: Features standardized connectors that fit directly into ABB robot control cabinets and valve groups, reducing installation time and effort.
Platform Benefits (ABB Robot Spare Parts):
The 3HNE09058-1 leverages ABB’s expertise in industrial robotics, offering:
-
Reliability: Genuine ABB spare parts ensure compatibility and performance parity with original components, reducing the risk of integration issues.
-
Minimal Downtime: Quick replacement of faulty cables minimizes robot downtime, which is critical for high-volume production lines.
-
Scalability: Adapts to evolving automation needs (e.g., adding new valves or modifying production processes) without replacing the entire control system.
ABB SPAU140C
Technical Specifications
Model Number: 3HNE09058-1
Manufacturer: ABB
Product Type: Robot Valve Signal Cable
-
Application: ABB industrial robots (IRB series)
-
Valve Compatibility: A3 valve group (2 valves)
-
Signal Type: Digital/analog (valve status signals)
-
Shielding: EMI-shielded (to resist electromagnetic interference)
-
Insulation Material: PVC (polyvinyl chloride) or cross-linked polyethylene (XLPE)
-
Connector Type: Standardized industrial connector (compatible with ABB robot control cabinets)
-
Length: Customizable (supplier-dependent)
-
Operating Temperature: -20°C to +60°C (-4°F to 140°F)
-
Certifications: CE, UL (inferred from ABB’s industrial product standards)
Core Features & Customer Value
1. Reliable Signal Transmission:
The 3HNE09058-1’s EMI shielding and robust construction ensure that valve status signals are transmitted accurately, even in electrically noisy environments (e.g., near motors or welders). This reliability prevents miscommunications between the robot and valves, which could lead to production errors or equipment damage.
2. Durable Construction for Harsh Environments:
The cable’s industrial-grade insulation and connectors resist vibration, bending, and temperature fluctuations, making it suitable for use in harsh industrial settings (e.g., steel mills, automotive plants). This durability reduces maintenance costs and extends the cable’s lifespan.
3. Easy Installation & Replacement:
The plug-and-play design allows technicians to install or replace the cable quickly, minimizing downtime during maintenance. This is essential for industries where continuous production is required (e.g., food and beverage, pharmaceuticals).
4. Compatibility with ABB Robots:
As a genuine ABB spare part, the 3HNE09058-1 is guaranteed to work with ABB robots, eliminating the need for custom modifications or adapters. This compatibility saves time and money during system integration.
