Description
3HXD1135-70: Product Overview
The ABB 3HXD1135-70 is a specialized robot arm component engineered for ABB’s IRB 7600 series—ABB’s flagship heavy-duty industrial robot platform. Designed for applications requiring high payload capacity (150–500 kg) and precision, this component plays a pivotal role in maintaining the structural integrity and operational accuracy of the IRB 7600 robot arm.
Role in Automation Systems:
Positioned as a core structural element of the IRB 7600 robot arm, the 3HXD1135-70 component connects the robot’s base to its upper arm, transferring motion and force from the motors to the end-effector (e.g., gripper, welding torch). Its high-strength design ensures that the robot can handle heavy loads (up to 500 kg) without compromising precision, making it ideal for industries like automotive manufacturing, metal fabrication, and logistics.
Core Functionality:
-
Structural Support: Provides a rigid framework for the robot arm, minimizing vibration and deflection during heavy-duty operations.
-
Precision Motion Transfer: Ensures that the motor’s rotational motion is translated into precise linear or angular movement of the end-effector, maintaining ±0.05 mm repeatability (critical for tasks like welding or component assembly).
-
Compatibility: Seamlessly integrates with other IRB 7600 components (e.g., motors, encoders, gearboxes), ensuring that the robot operates as a cohesive system.
Platform Benefits (IRB 7600 Series):
The 3HXD1135-70 leverages ABB’s expertise in heavy-duty robotics, offering:
-
High Payload Capacity: Supports up to 500 kg, making it suitable for lifting and moving heavy components (e.g., car bodies, steel beams).
-
Precision: ±0.05 mm repeatability ensures that tasks are performed accurately, reducing waste and rework.
-
Durability: Constructed from high-strength aluminum alloy, the component resists wear and tear in harsh industrial environments (e.g., high temperatures, vibration).
ABB 3HXD1135-70
Technical Specifications
Model Number: 3HXD1135-70
Manufacturer: ABB
Product Type: Industrial Robot Arm Component
-
Compatibility: ABB IRB 7600 series robots (payload: 150–500 kg)
-
Material: High-strength aluminum alloy (6061-T6)
-
Repeatability: ±0.05 mm
-
Load Capacity: Up to 500 kg
-
Weight: 25 kg (approximate)
-
Dimensions (L×W×H): 800 mm × 300 mm × 200 mm (approximate)
-
Operating Temperature: 0°C to +50°C (32°F to 122°F)
-
Certifications: CE, UL (inferred from ABB’s industrial product standards)
Core Features & Customer Value
1. High Strength-to-Weight Ratio:
The 3HXD1135-70’s aluminum alloy construction provides exceptional strength while keeping the component lightweight. This reduces the overall weight of the robot arm, improving energy efficiency and reducing wear on motors and gearboxes. For customers, this translates to lower operational costs and extended equipment lifespan.
2. Precision Engineering:
With ±0.05 mm repeatability, the component ensures that the IRB 7600 robot performs tasks with high accuracy. This is critical for applications like welding, where even minor deviations can lead to defective welds and rework. Customers in automotive manufacturing, for example, rely on this precision to maintain consistent product quality.
3. Seamless Compatibility:
Designed specifically for the IRB 7600 series, the 3HXD1135-70 integrates seamlessly with other robot components. This eliminates the need for custom modifications, reducing setup time and ensuring that the robot operates at peak performance. For customers, this means faster deployment and reduced integration costs.
4. Durability in Harsh Environments:
The component’s aluminum alloy construction resists corrosion and wear, making it suitable for use in harsh industrial environments (e.g., metal fabrication shops, chemical plants). This durability reduces maintenance costs and minimizes downtime, which is critical for customers who rely on continuous production.
ABB 3HXD1135-70
Typical Applications
The ABB 3HXD1135-70 is widely used in industries requiring heavy-duty robotic automation:
-
Automotive Manufacturing:
-
Used in IRB 7600 robots to lift and position car bodies during assembly. The component’s high load capacity (500 kg) and precision (±0.05 mm) ensure that car bodies are aligned correctly, reducing assembly errors.
-
-
Metal Fabrication:
-
Powers IRB 7600 robots that handle steel beams and plates for welding or cutting. The component’s strength and durability allow it to withstand the heavy loads and vibrations associated with metalworking.
-
-
Logistics:
-
Enables IRB 7600 robots to lift and move heavy packages (up to 500 kg) in warehouses. The component’s precision ensures that packages are placed accurately on conveyor belts or pallets, improving logistics efficiency.
-
