5SHX0660F0002: Product OverviewThe 5SHX0660F0002 is a high-power IGBT (Insulated Gate Bipolar Transistor) module from ABB’s HiPak series, designed for demanding applications in medium-voltage power electronics. This module serves as a fundamental switching component in voltage source converters (VSCs) utilized in equipment such as medium-voltage variable frequency drives (VFDs) for industrial motors, renewable energy systems, and flexible AC transmission system (FACTS) devices. Its primary role is to perform high-speed switching of electrical power, enabling precise control over voltage and frequency in high-power conversion systems.The module features a standard industry package with an isolated baseplate, allowing for efficient mounting to a heatsink. This design provides effective thermal management for high-power applications. The module contains advanced IGBT chips with low saturation voltage and optimized switching characteristics, designed for high efficiency and reliability in demanding industrial environments. The internal structure includes an IGBT and anti-parallel diode in a specific configuration depending on the module type.
ABB 5SHX0660F0002
5SHX0660F0002: Technical Specifications
•• Model Number: 5SHX0660F0002
•• Manufacturer: ABB
•• Product Type: IGBT Module
•• Collector-Emitter Voltage (Vces): 3300 V
•• Nominal Collector Current (Ic): High current rating (specific value depends on cooling and application conditions)
•• Maximum Junction Temperature (Tj): 150 °C
•• Package Type: HiPak (Standard module with isolated baseplate)
•• Cooling Method: Single-sided cooling (liquid or forced air)
•• Module Configuration: Depending on specific variant
•• Application: Medium Voltage Drives, Power Conversion Systems
ABB 5SHX0660F0002
Core Features & Customer ValueThe HiPak package offers excellent thermal performance and mechanical robustness, making it suitable for industrial environments with high reliability requirements. The low thermal resistance of the package allows for efficient heat transfer to the heatsink, enabling high power density in converter designs. For system designers, this translates to compact converter sizes and reduced cooling system requirements.The high current rating makes this module suitable for driving very large industrial motors or handling high power levels in other conversion applications. The high junction temperature rating of 150°C provides additional margin for thermal management under demanding operating conditions. These characteristics make the module well-suited for heavy industrial applications where reliability and performance are critical.Typical ApplicationsIn large industrial variable frequency drives for pumps, fans, and compressors, the 5SHX0660F0002 IGBT is used in the inverter section to convert DC power to variable frequency AC output. This enables precise speed control of high-power motors in the multi-megawatt range, leading to significant energy savings in industries such as mining, metals, and oil & gas.In industrial power supplies and large UPS systems, these IGBTs perform high-frequency switching to convert power efficiently. Their high current capability and robust construction make them suitable for handling the power demands of large industrial facilities.
