Manufacturer: ABB Part number: ABB 5SHX2645L0002
Our extensive ABB catalogue, including
: ABB 5SHX2645L0002
, is available now for dispatch to the worldwide.
5SHX2645L0002: Product OverviewThe 5SHX2645L0002 is a high-power IGBT (Insulated Gate Bipolar Transistor) module from ABB’s HiPak series, designed for robust performance in industrial power electronic systems. This module serves as a core switching element in voltage source converters (VSCs) used in applications such as medium-voltage variable frequency drives (VFDs) for industrial motors, industrial power supplies, and renewable energy systems. Its primary function is to switch high currents at high voltages with precise timing to synthesize controlled AC waveforms from a DC bus.The module utilizes a standard industry package with an isolated baseplate, allowing for easy mounting to a heatsink. This design provides single-sided cooling, which is effective for many high-power applications. The module contains advanced IGBT chips with low saturation voltage and fast switching characteristics, optimized for high efficiency and reliability in demanding industrial environments. The internal structure includes an IGBT and anti-parallel diode in a half-bridge or other configuration, depending on the specific module type.
ABB 5SHX2645L0002
5SHX2645L0002: Technical Specifications
•• Model Number: 5SHX2645L0002
•• Manufacturer: ABB
•• Product Type: IGBT Module
•• Collector-Emitter Voltage (Vces): 3300 V
•• Nominal Collector Current (Ic): 1500 A (at specific case temperature)
•• Maximum Junction Temperature (Tj): 150 °C
•• Package Type: HiPak (Standard module with isolated baseplate)
•• Cooling Method: Single-sided cooling (liquid or forced air)
•• Module Configuration: Depending on specific variant
•• Application: Industrial Drives, Power Conversion
ABB 5SHX2645L0002
Core Features & Customer ValueThe HiPak package offers excellent thermal performance and mechanical robustness, making it suitable for industrial environments with high reliability requirements. The low thermal resistance of the package allows for efficient heat transfer to the heatsink, enabling high power density in converter designs. For system designers, this translates to compact converter sizes and reduced cooling system requirements.The high current rating of 1500A makes this module suitable for driving very large industrial motors or handling high power levels in other conversion applications. The high junction temperature rating of 150°C provides additional margin for thermal management under demanding operating conditions. These characteristics make the module well-suited for heavy industrial applications where reliability and performance are critical.Typical ApplicationsIn large industrial variable frequency drives for pumps, fans, and compressors, the 5SHX2645L0002 IGBT is used in the inverter section to convert DC power to variable frequency AC output. This enables precise speed control of high-power motors in the multi-megawatt range, leading to significant energy savings in industries such as mining, metals, and oil & gas.In industrial power supplies and large UPS systems, these IGBTs perform high-frequency switching to convert power efficiently. Their high current capability and robust construction make them suitable for handling the power demands of large industrial facilities.
