ABB 5SHY4045L0001 & 3BHB018162 | IGCT Power Module & Heavy-Duty Drive Component Pair for Industrial Applications

Product 1: ABB 5SHY4045L0001 (IGCT Module)​

  • Brand: ABB
  • Model: 5SHY4045L0001
  • Product Type: Integrated Gate-Commutated Thyristor (IGCT) Module
  • Core Function: Enables high-speed switching and current control in medium- to high-voltage power conversion systems, combining the high voltage withstand capability of GTOs (Gate Turn-Off Thyristors) and the fast switching advantage of IGBTs (Insulated Gate Bipolar Transistors).
  • Key Specs: 4000A rated current; 45kV rated voltage; up to 1.6kHz switching frequency; -40°C to +125°C operating temperature; water or natural cooling; IP20 protection rating.

Product 2: ABB 3BHB018162 (Heavy-Duty Power Module)​

  • Brand: ABB
  • Model: 3BHB018162 (Variant: 3BHB018162R0001)
  • Product Type: Heavy-Duty Power Module (for ACS800 Series Drives)
  • Core Function: Converts 3-phase AC input into variable-frequency AC output for precise speed and torque regulation of heavy-duty motors, tailored for ABB ACS800 series mid-to-high power drive systems.
  • Key Specs: 350kW continuous output power (437.5kW peak 1min); 690V AC input voltage; 0-500Hz output frequency range; ≥95% efficiency; -25°C to +65°C operating temperature; forced air cooling; IP20 protection rating.
Get a Quote
Manufacturer:
Part number: ABB 5SHY4045L0001 & 3BHB018162
Our extensive catalogue, including : ABB 5SHY4045L0001 & 3BHB018162 , is available now for dispatch to the worldwide.

Description

ABB 5SHY4045L0001 & 3BHB018162: Product Overview​
The ABB 5SHY4045L0001 is a high-performance IGCT module, while the 3BHB018162 (or 3BHB018162R0001) is a heavy-duty power module designed for ABB ACS800 series drives. Together, they form a critical part of ABB’s mid-to-high power industrial drive solutions, targeting applications requiring reliable power conversion under harsh conditions.
The 5SHY4045L0001 IGCT module acts as the core power switching component, leveraging advanced semiconductor technology to achieve fast switching (up to 1.6kHz) and low conduction losses. Its rugged design (withstanding -40°C to +125°C) and high power density (4000A rated current) make it suitable for high-stress industrial environments. The 3BHB018162 power module, optimized for ACS800 drives, converts 690V AC input to variable-frequency AC output, enabling precise control of heavy-duty motors (e.g., in mining conveyors, steel rolling mills). Its ≥95% efficiency minimizes energy waste, while its forced air cooling system ensures stable operation under full load.
Both products are engineered for compatibility with ABB’s modular automation platform, simplifying system integration and maintenance. The 5SHY4045L0001’s integrated drive and protection circuits reduce the need for external components, while the 3BHB018162’s compact design (320mm × 260mm × 140mm) allows seamless installation in ACS800 drive chassis.

ABB 5SHY4045L0001 3BHB018162

ABB 5SHY4045L0001 3BHB018162

ABB 5SHY4045L0001 & 3BHB018162: Technical Specifications​
  • Model Number (IGCT Module): 5SHY4045L0001
  • Manufacturer: ABB Ltd.
  • Product Type: Integrated Gate-Commutated Thyristor (IGCT) Module
  • Rated Current: 4000A (continuous)
  • Rated Voltage: 45kV (blocking)
  • Switching Frequency: Up to 1.6kHz
  • Cooling Method: Water or natural cooling
  • Operating Temperature: -40°C to +125°C (case)
  • Protection Rating: IP20
  • Dimensions: Approx. 100mm (L) × 50mm (W) × 30mm (H) (TO-247AB package)
  • Weight: Approx. 4kg
  • Certifications: CE, UL (cULus Listed), RoHS
  • Model Number (Power Module): 3BHB018162 (3BHB018162R0001)
  • Manufacturer: ABB Ltd. (Industrial Drives & Automation Division)
  • Product Type: Heavy-Duty Power Module (for ACS800 Series Drives)
  • Input Voltage: 690V AC (3-phase, 50/60Hz)
  • Output Power Rating: 350kW (continuous), 437.5kW (peak 1min)
  • Output Frequency Range: 0-500Hz
  • Efficiency: ≥95% (full load)
  • Operating Temperature: -25°C to +65°C (operational), -40°C to +85°C (storage)
  • Cooling Method: Forced air cooling (dual high-speed fans)
  • Protection Rating: IP20
  • Dimensions: 320mm (L) × 260mm (W) × 140mm (H)
  • Weight: 16kg
  • Certifications: IEC 61800-5-1, CE, UL 508C, ATEX Zone 2
Core Features & Customer Value​
The 5SHY4045L0001 IGCT module offers high power density (4000A rated current) and fast switching (10x faster than traditional GTOs), making it ideal for high-frequency applications like medium-voltage drives and HVDC systems. Its low conduction loss (integrated free-wheeling diode reduces dynamic power consumption by ~50%) improves system efficiency, lowering operational costs. The 3BHB018162 power module’s ≥95% efficiency minimizes energy waste in continuous operation, while its -25°C to +65°C operating range handles extreme industrial temperatures (e.g., mining sites with freezing nights and 60°C daytime highs).
Both products prioritize reliability: the 5SHY4045L0001 uses advanced packaging technology to resist high temperature and corrosion, while the 3BHB018162 features overload (150% rated current for 1min), short-circuit, over-voltage, and over-temperature protection to prevent drive damage. Their modular designs simplify maintenance— the 5SHY4045L0001’s compact size allows easy replacement, and the 3BHB018162’s chassis mount design integrates seamlessly with ACS800 drives.

ABB 5SHY4045L0001 3BHB018162

ABB 5SHY4045L0001 3BHB018162

Typical Applications​
The combination of 5SHY4045L0001 and 3BHB018162 is widely used in:
  • Mining: Powering ore conveyor drives (e.g., ABB ACS800-07) in large copper mines, where the 3BHB018162’s high efficiency and the 5SHY4045L0001’s fast switching ensure reliable operation under peak loads.
  • Steel Industry: Controlling main roller motors in steel rolling mills, where precise speed regulation (via the 3BHB018162) and high power conversion (via the 5SHY4045L0001) ensure consistent strip thickness.
  • Medium-Voltage Drives: Used in industrial motor drives (e.g., pumps, fans) where high power density and fast switching are critical.
  • HVDC Transmission: Integral to high-voltage direct current (HVDC) systems, where the 5SHY4045L0001’s low switching losses and the 3BHB018162’s high efficiency enable long-distance power transmission.
  • Rail Traction: Powering traction converters in trains, where the 5SHY4045L0001’s ruggedness and the 3BHB018162’s precise control ensure consistent performance in demanding conditions.
