ABB BSD0750: Product Overview
The ABB BSD0750 is a three-pole molded case circuit breaker (MCCB) from the BSD Series, designed for low-voltage power distribution systems requiring reliable circuit protection. As a core component in industrial and commercial electrical networks, it safeguards downstream equipment (motors, transformers, control panels) by detecting and interrupting abnormal currents (overloads, short circuits).
The BSD Series is engineered for versatility, featuring adjustable trip units that allow customization of protection settings to match specific load requirements. The BSD0750 is typically installed in switchboards, motor control centers (MCCs), or distribution boards, serving as the first line of defense against electrical faults. Its compact design and modular construction simplify integration into new or retrofit projects, aligning with global standards (IEC 60947-2) for safety and performance.
ABB BSD0750
ABB BSD0750: Technical Specifications
-
Model Number: BSD0750
-
Manufacturer: ABB Ltd.
-
Product Type: Molded Case Circuit Breaker (MCCB)
-
Poles: 3-pole
-
Rated Current (In): 750A
-
Rated Operational Voltage (Ue): 690V AC (3-phase)
-
Rated Insulation Voltage (Ui): 1000V AC
-
Breaking Capacity:
-
Ultimate Breaking Capacity (Icu): 50kA @ 415V AC
-
Service Breaking Capacity (Ics): 35kA @ 415V AC (70% of Icu)
-
-
Trip Units: Adjustable thermal-magnetic (LSIG optional)
-
Thermal Trip: Adjustable overload protection (0.4–1.0 × In)
-
Magnetic Trip: Fixed short-circuit protection (5–10 × In)
-
-
Operating Temperature: -25°C to +70°C
-
Mounting: Fixed or plug-in (panel-mounted)
-
Dimensions: ~250mm (H) x 150mm (W) x 110mm (D) (approximate)
-
Weight: ~8.5 kg (18.7 lbs)
-
Certifications: CE, IEC 60947-2, UL 489 (cULus Listed), RoHS
Core Features & Customer Value
-
High Breaking Capacity: With a 50kA ultimate breaking capacity (Icu), the BSD0750 safely interrupts severe short-circuit currents, protecting critical infrastructure in industrial plants or commercial buildings.
-
Adjustable Protection: Thermal-magnetic trip units allow fine-tuning of overload (thermal) and short-circuit (magnetic) thresholds, optimizing protection for diverse loads (e.g., motors, heaters, lighting circuits).
-
Durability: Robust construction with thermoset housing resists mechanical stress and environmental factors (humidity, dust), ensuring a service life of 15,000+ mechanical operations.
-
Easy Integration: Plug-in mounting options reduce installation time, while compatibility with ABB’s System Pro M compact switchgear simplifies system design.
-
Safety Compliance: Meets IEC 60947-2 and UL 489 standards, ensuring global acceptance for safety-critical applications.
ABB BSD0750
Typical Applications
The ABB BSD0750 is widely used in low-voltage power distribution systems:
-
Industrial Facilities: Protects motor circuits in manufacturing plants, conveyor systems, and HVAC units.
-
Commercial Buildings: Safeguards distribution boards in offices, hospitals, and shopping malls.
-
Infrastructure: Used in data centers, water treatment plants, and renewable energy substations.
-
Marine & Offshore: Suitable for shipboard electrical systems (with corrosion-resistant coatings).
Example: In a manufacturing plant, the BSD0750 protects a 750A motor control circuit, interrupting a 40kA short-circuit fault within 10ms to prevent damage to the motor and upstream transformer.
