ABB CI630 3BSE011000R1 | Advant OCS Series Communication Interface Module
ABB CI630 3BSE011000R1 | Advant OCS Series Communication Interface Module
Brand: ABB
Model: CI630
Product Code: 3BSE011000R1
Product Type: Communication Interface Module
Series: Advant OCS (Advanced Open Control System)
Core Function: Manages Profibus DP communication between Advant OCS controllers and distributed I/O modules/field devices; handles data exchange, protocol conversion, and system diagnostics.
Key Specs: PowerPC 405 processor, 256MB RAM, Profibus DP (up to 12 Mbps), -25°C to +60°C operating temperature, hot-swappable design.
Manufacturer: ABB Part number: ABB CI630 3BSE011000R1
Our extensive ABB catalogue, including
: ABB CI630 3BSE011000R1
, is available now for dispatch to the worldwide.
CI630 3BSE011000R1: Product OverviewThe ABB CI630 (3BSE011000R1) is a communication interface module within ABB’s Advant OCS (Advanced Open Control System) series, designed to facilitate reliable data exchange between Advant OCS controllers and distributed I/O modules or field devices. Positioned as a protocol-specific gateway, its primary role is to manage Profibus DP communication—converting controller commands into field-readable signals and transmitting sensor data back to the control system. This module is integral to maintaining deterministic communication in industrial automation architectures, where timely and accurate data flow is critical for process stability in continuous operations such as chemical processing, power generation, and manufacturing.Functionally, the CI630 processes cyclic data (real-time I/O updates) and acyclic messages (diagnostic/config commands) via Profibus DP (up to 12 Mbps). It acts as an intermediary, isolating the controller from field-level electrical noise and ensuring signal integrity. As part of the Advant OCS family, the module leverages the platform’s modular architecture, compatibility with ABB’s legacy and modern control systems, and support for unified engineering tools like Control Builder. Benefits include simplified system integration, reduced wiring complexity through standardized protocols, and seamless scalability for expanding I/O networks.CI630 3BSE011000R1: Technical Specifications
Communication Protocol: Profibus DP (up to 12 Mbps, master/slave mode)
I/O Capacity: Up to 32 distributed I/O modules per segment
Data Throughput: Up to 8,000 I/O points per second (cyclic exchange)
Operating Temperature: -25°C to +60°C
Humidity Range: 5% to 95% non-condensing
Power Supply: 24V DC (from Advant OCS rack backplane, 18-32V DC range)
Power Consumption: 5W (typical)
Dimensions: 245mm x 135mm x 115mm (width x height x depth)
Weight: 0.9kg
Certifications: CE, UL, cULus, RoHS
Core Features & Customer ValueThe CI630 3BSE011000R1 is engineered to address critical communication challenges in industrial automation. Its support for Profibus DP—a widely adopted fieldbus protocol—enables seamless integration with ABB S800 I/O modules and third-party devices (e.g., Siemens ET 200), eliminating the need for protocol converters. For engineers, this simplifies system design and reduces component count, lowering upfront integration costs.The module’s PowerPC 405 processor and 256MB RAM ensure efficient handling of large data volumes, critical for dense I/O networks in applications like turbine control or batch processing. Deterministic data exchange (≤10ms latency) guarantees that control commands reach actuators without delay, maintaining process precision. Galvanic isolation (1500VAC) between the controller and field bus protects against ground loops and EMI, a necessity in environments with VFDs or high-power motors.Hot-swap capability minimizes downtime during maintenance. Technicians can replace the module without de-energizing the rack, as the Advant OCS controller automatically reallocates communication tasks to redundant paths (if configured). Integration with ABB’s Control Builder software streamlines configuration, allowing engineers to reuse communication profiles across projects and cut commissioning time by 15-20%. For maintenance teams, built-in diagnostics (LED indicators, error logs) accelerate fault isolation, reducing mean time to repair (MTTR).
ABB CI630 3BSE011000R1
Typical ApplicationsThe ABB CI630 3BSE011000R1 is deployed in Advant OCS environments requiring Profibus DP communication. In a petroleum refinery’s catalytic reformer, it connects the Advant OCS C100 controller to 24 S800 I/O modules monitoring temperature, pressure, and flow. Real-time data transmission enables precise adjustment of hydrogen-to-hydrocarbon ratios, optimizing octane output.At a chemical plant’s batch reactor, the module interfaces the Advant OCS safety controller with Profibus DP-linked emergency shutdown (ESD) devices (e.g., flame detectors, pressure switches). Its deterministic communication ensures ESD signals are prioritized, meeting SIL 2 requirements for rapid response.In a municipal water treatment facility, the CI630 links the Advant OCS controller to remote pump station I/O racks via Profibus DP. Data on pump status and tank levels is transmitted for remote adjustment of chemical dosing, with the module’s -25°C cold-start capability supporting winter operations.
