ABB DC541-CM 1SAP270000R0001 | Industrial PLC Digital Input Unit for Sensor/Switch Signals

  • Brand: ABB
  • Model: DC541-CM 1SAP270000R0001
  • Product Type: Digital Input Module
  • Series: AC500 Series (ABB Advant Controller 500 I/O Family)
  • Core Function: Provides 16 isolated digital input channels to acquire signals from field devices (e.g., proximity switches, limit switches, pushbuttons) and transmit them to AC500 PLC CPUs for logic processing in industrial automation systems.
  • Key Specs: 16 channels, 24V DC input (dry contact/solid-state), 2500VAC isolation, supports AC500 bus communication, -25°C to +60°C operating temperature, hot-swappable design.
Get a Quote
Manufacturer:

Our extensive catalogue, including , is available now for dispatch to the worldwide.
  • Full 12-month warranty
  • Available for dispatch immediately
  • We deliver worldwide

Description

DC541-CM 1SAP270000R0001: Product Overview
The DC541-CM 1SAP270000R0001 is a 16-channel digital input module within ABB’s AC500 series of I/O modules, designed for integration into AC500 PLC systems to serve as a front-end interface for discrete signal acquisition. Its role is to convert field device signals (e.g., proximity switch activations, emergency stop button presses, valve position feedback) into digital data that AC500 CPUs can process for control logic execution. For industries such as manufacturing, water treatment, and chemical processing—where reliable monitoring of discrete events is critical—it ensures accurate signal transmission and simplifies wiring in distributed I/O architectures.
Functionally, the module processes inputs from 16 independent channels, each configurable for 24V DC dry contact (relay) or solid-state (transistor) signals. It employs galvanic isolation (2500VAC) to prevent ground loops and electromagnetic interference (EMI) from corrupting data, a necessity in electrically noisy environments. As part of the AC500 I/O family, the DC541-CM 1SAP270000R0001 leverages the AC500 platform’s advantages: modular scalability, compatibility with CODESYS V3 programming, and seamless integration with ABB 800xA DCS. This design simplifies system expansion, reduces validation effort, and enables reuse of I/O configurations across projects.

ABB DC541-CM 1SAP270000R0001

ABB DC541-CM 1SAP270000R0001

DC541-CM 1SAP270000R0001: Technical Specifications
  • Model Number: DC541-CM 1SAP270000R0001
  • Manufacturer: ABB
  • Product Type: Digital Input Module
  • Number of Channels: 16 (individually isolated)
  • Input Type: Dry contact (relay, 24V DC), Solid-state (transistor, 24V DC)
  • Input Voltage: 24V DC nominal (18-30V DC range)
  • Isolation Voltage: 2500VAC (channel-to-channel, channel-to-bus)
  • Signal Response Time: <5 ms (input change to CPU update)
  • Operating Temperature: -25°C to +60°C
  • Humidity Range: 5% to 95% non-condensing
  • Power Supply: 24V DC (from AC500 rack backplane, 18-32V DC range)
  • Power Consumption: 1.2W (typical, all channels active)
  • Diagnostics: Channel short/open circuit, power monitoring, communication heartbeat
  • Hot Swap Support: Yes (plug-and-play replacement without system shutdown)
  • Dimensions: 25mm x 128mm x 115mm (width x height x depth, fits AC500 I/O rack)
  • Weight: 0.18kg
  • Certifications: CE, UL, cULus, RoHS
Core Features & Customer Value​
High-Channel Density Reduces Cabinet Complexity: With 16 input channels per module, the DC541-CM 1SAP270000R0001 minimizes the number of I/O modules required in control cabinets. For engineers designing systems with numerous discrete devices (e.g., a manufacturing line with 10 proximity switches and 6 pushbuttons), this cuts cabinet space by 50% compared to 8-channel alternatives, simplifying wiring and lowering material costs.
Galvanic Isolation Ensures Signal Integrity: The 2500VAC isolation between channels and the AC500 bus prevents EMI from industrial equipment (e.g., VFDs, motors) from distorting digital signals. In a chemical plant’s reactor control system, this ensures reliable detection of limit switch activations—critical for preventing over-pressurization—even near high-power agitators.
Comprehensive Diagnostics Accelerate Maintenance: Built-in diagnostics monitor each channel for short circuits (to ground/power), open circuits (broken wires), and power supply health. Faults are reported to the AC500 CPU via the I/O bus, with LED indicators on the faceplate for quick visual identification. For maintenance teams, this reduces troubleshooting time from hours to minutes—e.g., identifying a failed proximity switch in an automotive assembly line without invasive testing.
Hot-Swappable Design Minimizes Downtime: The module can be replaced while the system remains powered, essential for continuous processes like water treatment. Technicians remove the faulty unit and insert a new one; the AC500 CPU automatically reloads configuration data. This eliminates scheduled shutdowns for module replacement, saving thousands in lost production per incident.
Seamless Integration with AC500 Platform: As a native AC500 I/O component, the module uses ABB’s Automation Builder software (CODESYS V3) for configuration and monitoring. Engineers reuse existing I/O profiles across projects, cutting commissioning time by 20%. Compatibility with AC500 remote I/O racks enables scalable expansion from local to distributed architectures.

ABB DC541-CM 1SAP270000R0001

ABB DC541-CM 1SAP270000R0001

Typical Applications​
The DC541-CM 1SAP270000R0001 is deployed in AC500 PLC systems requiring discrete signal acquisition. In an automotive assembly plant, it connects 16 proximity switches on a conveyor line to monitor part presence. The 2500VAC isolation prevents EMI from robotic arms from causing false triggers, ensuring accurate part tracking.
At a municipal water treatment plant, the module acquires signals from 12 level switches (dry contact) and 4 valve position sensors (solid-state) across lift stations. One Ethernet port (via AC500 CPU) sends status data to the plant’s SCADA system, alerting operators to high/low tank levels.
In a chemical batch reactor, the DC541-CM 1SAP270000R0001 monitors 8 agitator overload switches (dry contact) and 8 temperature limit switches (solid-state). Its -25°C cold-start capability supports indoor control rooms, while hot-swap functionality allows maintenance during planned turnarounds.
