High Precision Control: The module features a measurement accuracy of ±0.05%, enabling precise control of magnetic excitation currents even in complex industrial environments.
Multiple Communication Protocols: The DCF1061134R0001 YPP110A supports a wide range of communication protocols, including RS-485, Ethernet, Profibus DP v1.0, Modbus RTU, and Modbus TCP/IP, ensuring seamless integration with existing automation systems.
Fast Response Capability: The module is designed to respond quickly to load changes, providing real-time adjustments to ensure system stability.
High Reliability: Manufactured with high-quality components and stringent production processes, the module ensures stable operation in harsh industrial conditions.
Get a Quote
Manufacturer:
Part number: DCF1061134R0001 YPP110A
Our extensive catalogue, including : DCF1061134R0001 YPP110A , is available now for dispatch to the worldwide.
  • Full 12-month warranty
  • Available for dispatch immediately
  • We deliver worldwide

Description

Detailed Parameter Table

Parameter Name Parameter Value
Product model ABB DCF1061134R0001 YPP110A
Manufacturer ABB
Product category Industrial Control Module
Input voltage 24 V DC (±10%)
Output voltage 480 V AC
Output current 110 A
Power 52.8 kW
Frequency range 0.5 Hz to 150 Hz
Cooling method Natural cooling
Protection class IP20
Installation method Plug-in
Dimensions 280 mm x 170 mm x 70 mm
Weight 2.5 kg
Operating temperature -20°C to +60°C
Humidity Up to 90% non-condensing
Communication protocols RS-485, Ethernet, Profibus DP v1.0, Modbus RTU, Modbus TCP/IP
Certifications CE, RoHS
ABB DCF1061134R0001 YPP110A

ABB DCF1061134R0001 YPP110A

Product Introduction

The ABB DCF1061134R0001 YPP110A is a high-performance magnetic excitation controller module designed for industrial automation applications. It is part of the ABB YPP series and is specifically designed for precise control of magnetic excitation currents in generators and electric motors. This module ensures stable and reliable operation in power systems by providing high-precision control and real-time monitoring.

Core Advantages and Technical Highlights

High Precision Control: The module features a measurement accuracy of ±0.05%, enabling precise control of magnetic excitation currents even in complex industrial environments.
Multiple Communication Protocols: The DCF1061134R0001 YPP110A supports a wide range of communication protocols, including RS-485, Ethernet, Profibus DP v1.0, Modbus RTU, and Modbus TCP/IP, ensuring seamless integration with existing automation systems.
Fast Response Capability: The module is designed to respond quickly to load changes, providing real-time adjustments to ensure system stability.
High Reliability: Manufactured with high-quality components and stringent production processes, the module ensures stable operation in harsh industrial conditions.

ABB DCF1061134R0001 YPP110A

ABB DCF1061134R0001 YPP110A

Typical Application Scenarios

The ABB DCF1061134R0001 YPP110A is widely used in various industrial sectors, including:
  • Power Generation: Precise control of generator excitation systems to ensure stable power output.
  • Manufacturing: Driving and controlling electric motors in applications such as pumps, fans, and compressors.
  • Oil and Gas: Ensuring reliable operation of electric motors in harsh environments.

Related Model Recommendations

  • ABB YPP110A: A digital processor module that can be used in conjunction with the DCF1061134R0001 for enhanced control capabilities.
  • ABB AC500 Series PLCs: Compatible with the DCF1061134R0001 for comprehensive automation solutions.
  • ABB ACS880 Drives: Can be integrated with the DCF1061134R0001 for precise motor speed and torque regulation.

Installation, Commissioning and Maintenance Instructions

Installation Preparation

Before installing the ABB DCF1061134R0001 YPP110A, ensure that the environment meets the specified requirements, including an operating temperature range of -20°C to +60°C. The installation location should be free from excessive dust, moisture, and corrosive gases to ensure long-term reliability. Use a standard DIN rail or panel mount for secure installation.

Maintenance Suggestions

To maintain the ABB DCF1061134R0001 YPP110A, perform regular inspections of the module and its connections to ensure they are secure and free from corrosion. Clean the unit regularly with a soft, dry cloth to remove dust and debris. If any issues arise, refer to the troubleshooting guide in the user manual for common solutions. Replace any worn or damaged parts promptly to ensure continued performance. Regularly update the firmware to benefit from the latest enhancements and security features.
