ABB DO815

Product Introduction

The ABB DO815 is a high-performance digital output module designed for industrial automation systems, specifically tailored to work with ABB’s AC800M PLC system. As a key component in control signal transmission, it converts digital control signals from the central processor into actionable commands for field actuators, enabling precise control of various industrial equipment.

Equipped with 8 isolated output channels, the ABB DO815 can connect to a range of devices such as relays, contactors, solenoid valves, and indicator lights. When paired with a processor module like ABB 3BSE018741R15 and a digital input module such as ABB DI524 1SAP240000R0001, it forms a complete control loop—collecting input signals, processing them, and outputting control commands. This makes it an essential part of automation systems in manufacturing, energy, and process industries.

Core Advantages and Technical Highlights

High Reliability in Output Control

The ABB DO815 offers stable output performance with a maximum current of 2 A per channel, capable of driving various industrial actuators. Its fast response time of ≤ 1 ms ensures that control commands are executed promptly, which is critical in time-sensitive applications. For example, in a packaging line, when the ABB DI524 1SAP240000R0001 detects a product in position, the processor module sends a signal to the ABB DO815, which immediately activates the sealing device, ensuring precise and efficient packaging.

Strong Isolation Protection

With 2.5 kV AC isolation between channels and the backplane, the ABB DO815 effectively resists electromagnetic interference and prevents cross-talk between channels. This ensures that output signals remain stable even in harsh industrial environments with high electrical noise, such as near large motors or welding machines. In a steel processing plant, this isolation guarantees that the module can reliably control conveyor belt motors without being affected by nearby heavy machinery, reducing the risk of operational errors.

Flexible Integration

The ABB DO815 seamlessly integrates with ABB’s AC800M PLC system, enabling easy connection with processor modules and input modules. Its compact design and DIN rail mounting save space in control cabinets, facilitating system layout optimization. Multiple ABB DO815 modules can be deployed in parallel to expand output channels, meeting the needs of large-scale automation systems. For instance, in a water treatment plant, combining multiple modules allows for simultaneous control of numerous valves and pumps, enhancing system scalability.

ABB DO815

Typical Application Scenarios

In automotive assembly lines, the ABB DO815 is used to control robotic arms, conveyor belt drives, and clamping devices. It receives control signals from the ABB 3BSE018741R15 processor module (which processes data from ABB DI524 1SAP240000R0001 input modules) and activates corresponding actuators. For example, when a car body reaches a specific station, the input module detects its presence, the processor issues a command, and the ABB DO815 triggers the clamping device to secure the car body, ensuring accurate assembly operations.

In food and beverage processing facilities, the ABB DO815 controls packaging machines, filling valves, and conveyor systems. It works with input modules to monitor production status and adjusts output signals accordingly. If a sensor detects an empty container, the input module sends a signal to the processor, which instructs the ABB DO815 to activate the filling valve, ensuring precise filling and avoiding waste. Additionally, it can control alarm lights to alert operators of abnormal conditions, enhancing production safety.

In power distribution systems, the ABB DO815 is employed to control circuit breakers, disconnect switches, and cooling fans. It receives control commands from the central processor based on input signals from current and voltage sensors. For example, when overcurrent is detected, the processor sends a signal to the ABB DO815 to trip the circuit breaker, protecting electrical equipment from damage. This ensures the safe and stable operation of the power grid.

Related Model Recommendations

• ABB DI815: A digital input module that complements the ABB DO815, collecting signals from field sensors to provide input data for the control system.
• ABB 3BSE018741R15: A processor module that works with the ABB DO815to process data and issue control commands, forming the core of the control system.
• ABB AI815: An analog input module that, when used with the ABB DO815, enables the system to handle both analog and digital signals, suitable for complex industrial environments.
• ABB AO815: An analog output module that pairs with the ABB DO815to provide variable output signals, controlling devices such as variable frequency drives.
• ABB TU830V1: A terminal unit that simplifies wiring between the ABB DO815and field devices, reducing installation time and improving system reliability.
• ABB CI867K01 3BSE043660R1: A communication module that facilitates data transmission between the ABB DO815and remote monitoring systems, enabling remote control and diagnosis.

Installation, Commissioning and Maintenance Instructions

Installation Preparation

Before installing the ABB DO815, ensure the control cabinet is clean, dry, and free from excessive vibration or electromagnetic interference. The ambient temperature should be within -25°C to +60°C, with relative humidity below 95% (non-condensing). Required tools include a screwdriver (PH2), wire strippers, and a torque wrench (set to 0.5 – 0.7 Nm for terminal connections). Disconnect the power supply before installation to avoid electrical hazards. Mount the module on a 35 mm DIN rail, ensuring a secure fit. Use shielded cables for output connections, with the shield grounded to minimize interference. Follow the wiring diagram to connect each channel to the corresponding field device, ensuring correct polarity.

Maintenance Suggestions

Regularly inspect the ABB DO815 for dust accumulation and clean it with a soft, dry cloth or compressed air (low pressure). Check the status LEDs; a green light indicates normal operation, while a red light may signal a fault. Periodically tighten terminal connections to prevent loose contacts and intermittent output issues. Test each output channel regularly using a multimeter to verify voltage and current output. If a channel fails, first check the connected device and wiring; if they are functional, replace the module with an ABB-approved spare part. It is recommended to perform a full system test annually to ensure all modules work properly.

Service and Guarantee Commitment

The ABB DO815 comes with a 2-year warranty, covering defects in materials and workmanship under normal operating conditions. During the warranty period, ABB will repair or replace faulty modules free of charge. Our global technical support team is available 24/7 via phone, email, or online chat to provide assistance with installation, troubleshooting, and technical inquiries.

We offer comprehensive online resources, including user manuals, wiring diagrams, and firmware updates, to support efficient system deployment. Optional service contracts provide on-site technical support, training sessions, and priority response times, ensuring optimal performance of the ABB DO815 throughout its lifecycle. ABB’s commitment to quality and service ensures reliable operation of your industrial automation systems.
