ABB DSAI133A 3BSE018290R1 | Analog Input Module

  • Brand:​ ABB
  • ••
    Model:​ DSAI133A (Order Code: 3BSE018290R1)
  • ••
    Product Type:​ Analog Input Module
  • ••
    Series:​ S800 I/O
  • ••
    Core Function:​ Provides 8 channels of analog input signal conditioning for process variables such as temperature, pressure, and flow.
  • ••
    Key Specs:​ 8 channels, 4-20mA input, 16-bit resolution, HART support.
Get a Quote
Manufacturer:

Our extensive catalogue, including , is available now for dispatch to the worldwide.

Description

DSAI133A: Product Overview
The DSAI133A is an 8-channel analog input module within ABB’s S800 I/O family, designed for high-precision acquisition of current signals from field transmitters in process automation applications. This module is typically installed in a distributed I/O station located near the process equipment, functioning as the critical interface that converts analog current signals from measurement devices—such as pressure, flow, level, and temperature transmitters—into digital values for the central controller (e.g., an AC 800M). Its primary role is to ensure the accurate and reliable digitization of vital process variables that form the basis for regulatory control, monitoring, and data logging.
A defining feature of this module is its integrated support for the HART (Highway Addressable Remote Transducer) protocol. This capability allows the module to perform dual communication: it continuously measures the 4-20mA analog value representing the primary process variable while simultaneously superimposing a digital HART signal on the same wire pair. This enables bidirectional communication with HART-enabled smart field instruments without requiring separate wiring, allowing for device configuration, calibration, diagnostics, and access to secondary or tertiary variables (e.g., device temperature, sensor status) from the control system.

ABB DSAI133A 3BSE018290R1

ABB DSAI133A 3BSE018290R1

DSAI133A: Technical Specifications
  • ••
    Model Number:​ DSAI133A
  • ••
    Order Number:​ 3BSE018290R1
  • ••
    Manufacturer:​ ABB
  • ••
    Product Type:​ 8-Channel Analog Input Module
  • ••
    Input Channels:​ 8 channels, single-ended
  • ••
    Input Signal:​ 4-20mA (with HART communication support)
  • ••
    Resolution:​ 16-bit
  • ••
    Accuracy:​ ±0.1% of reading
  • ••
    Update Time:​ 10 ms per channel
  • ••
    HART Support:​ Integrated HART modem
  • ••
    Isolation:​ Channel-to-channel and channel-to-system isolation, 500V AC
  • ••
    Power Supply:​ 24V DC via S800 I/O baseplate
  • ••
    Power Consumption:​ Typically 1.5W
  • ••
    Operating Temperature:​ -25°C to +70°C
  • ••
    Connection:​ Via Field Termination Assembly (FTA)
  • ••
    Compatible Systems:​ ABB AC 800M, Symphony DCS, System 800xA

    ABB DSAI133A 3BSE018290R1

    ABB DSAI133A 3BSE018290R1

Core Features & Customer Value
The module’s channel-to-channel isolation is a critical design feature that prevents ground loops and limits the impact of a fault on one channel from affecting the others. For the control engineer, this means that a short circuit or wiring fault on a single transmitter loop will not disrupt the measurement integrity of the remaining seven channels, significantly enhancing the overall availability and reliability of the control system. This isolation is essential for maintaining signal integrity in electrically noisy industrial environments.
The integrated HART functionality delivers substantial operational value by enabling asset management capabilities. Maintenance personnel can remotely query connected HART devices to verify configuration, perform loop tests (e.g., by forcing a 4mA or 20mA output from the device), and retrieve diagnostic messages without needing to visit the field or carry a separate HART communicator. This capability transforms the I/O module from a simple data acquisition card into a gateway for predictive maintenance, helping to reduce downtime by identifying potential device issues before they cause a process interruption.
The module’s high density (8 channels) and compact form factor allow for a high channel count within a limited cabinet space, optimizing the footprint of the control panel. The use of standardized Field Termination Assemblies (FTAs) simplifies wiring, reduces installation time, and facilitates module replacement without disturbing field wiring, which directly lowers installation and maintenance costs.
Typical Applications
In a chemical processing plant, the DSAI133A is used to monitor reactor temperatures and pressures via HART-enabled transmitters. The module provides the primary process variables to the controller for batch control and safety interlocking. Simultaneously, the HART link is used to monitor the health of the temperature transmitters and to perform remote calibration during maintenance windows.
In a water treatment facility, the module interfaces with smart pH and conductivity analyzers. The 4-20mA signal carries the primary measurement value for control, while the HART protocol is used to remotely read secondary measurements from the multi-parameter analyzer and to calibrate the device during scheduled maintenance outages, ensuring process water quality without constant manual intervention.
