Name: ABB DSSB-01C | Rectifier Control Board for ACS800 Drives - XINYEDA
Brand: ABB
SKU: ABB DSSB-01C

ABB DSSB-01C | Rectifier Control Board for ACS800 Drives

Model: DSSB-01C
Alt. P/N: 3AFE68300746
Series: ACS800
Type: Rectifier Control Board
Key Feature: Dual power supply input, 1500V isolation
Primary Use: AC/DC conversion in variable frequency drives

Manufacturer: ABB
Part number: ABB DSSB-01C
Our extensive ABB catalogue, including : ABB DSSB-01C , is available now for dispatch to the worldwide.

Description

Key Technical Specifications

Model Number: DSSB-01C (3AFE68300746)
Manufacturer: ABB
Product Type: Rectifier Control Board
Input Voltage: 110-380V AC
Operating Voltage: 24V DC
Power Consumption: 5-130W
Isolation Voltage: 1500V DC
Operating Temperature: -20°C to +60°C
Storage Temperature: -40°C to +70°C
Humidity: 0-95% non-condensing
Protection Features: Overcurrent, surge, reverse polarity, lightning protection
Communication: RS-485, Ethernet (version dependent)

DSSB-01C
Weight: ~1.8 kg

Field Application & Problem Solved

In industrial environments, the DSSB-01C addresses the critical need for reliable AC/DC power conversion in variable frequency drives. It converts incoming AC power to stable DC for motor control, ensuring operational stability. Common applications include heavy machinery in mining, pumps in oil/gas facilities, and automation systems in manufacturing plants. Its primary value lies in robust protection features that safeguard equipment from electrical anomalies and minimize downtime.

Installation & Maintenance Pitfalls

Verify Compatibility: Confirm the board matches your ACS800 drive model and version to prevent integration issues.

Grounding: Properly ground the shield at one end only to avoid noise interference.

Environmental Checks: Ensure ambient temperature and humidity are within specified ranges to prevent overheating or condensation.

Firmware Updates: Regularly update firmware to maintain compatibility and performance.

Spare Parts: Keep a spare board on hand to reduce downtime during failures.

DSSB-01C

Technical Deep Dive

The DSSB-01C utilizes thyristors or diodes for rectification, managed by an onboard processor for precise control. It supports multiple communication protocols for seamless integration and features advanced thermal management for reliability in harsh conditions.
