ABB PM556-TP-ETH: Product Overview
The ABB PM556-TP-ETH is a compact, all-in-one programmable logic controller (PLC) with an integrated touchscreen human-machine interface (HMI), designed for decentralized industrial automation. Part of ABB’s PM500 Series, it merges PLC logic execution, HMI visualization, and Ethernet communication into a single unit, simplifying machine control and reducing cabinet space.
Targeted at small-to-medium automation tasks, the PM556-TP-ETH serves as a standalone controller for machines (e.g., packaging equipment, material handling systems) or as a distributed node in larger networks. Its integrated 4.3-inch color touchscreen allows operators to monitor process variables, adjust setpoints, and acknowledge alarms locally, while the Ethernet port enables remote programming, data logging, and integration with SCADA/MES systems. The unit supports ABB’s CODESYS programming environment, ensuring compatibility with global automation standards.
PM556-TP-ETH
ABB PM556-TP-ETH: Technical Specifications
-
Model Number: PM556-TP-ETH
-
Manufacturer: ABB Ltd.
-
Product Type: PLC with Integrated HMI (Touchscreen)
-
Processor: 32-bit RISC, 400 MHz
-
Memory:
-
RAM: 128 MB (expandable via SD card)
-
Flash: 16 MB (user program storage)
-
-
HMI Display: 4.3-inch TFT color touchscreen (480×272 pixels, resistive touch)
-
Communication Interfaces:
-
1x Ethernet port (10/100 Mbps, RJ45)
-
1x USB 2.0 port (for programming/configuration)
-
Optional RS485/RS232 serial ports (via expansion module)
-
-
Protocol Support: Modbus TCP/IP, PROFINET IO, EtherNet/IP, ABB AC500 communication protocols
-
I/O Capacity:
-
Onboard: 8 digital inputs (24VDC), 6 digital outputs (24VDC, 0.5A)
-
Expandable: Up to 256 I/O points via ABB PM5xx expansion modules
-
-
Programming Software: ABB CODESYS V3.5 (IEC 61131-3 compliant)
-
Operating Temperature: -20°C to +60°C (14°F to 140°F)
-
Storage Temperature: -40°C to +85°C (-40°F to 185°F)
-
Protection Rating: IP65 (front panel), IP20 (rear)
-
Dimensions: 150mm (H) x 130mm (W) x 60mm (D) (approximate)
-
Weight: ~0.8 kg (1.76 lbs)
-
Certifications: CE, UL/cUL Listed, RoHS, ATEX Zone 2 (optional)
PM556-TP-ETH
Core Features & Customer Value
-
All-in-One Design: Integrates PLC, HMI, and Ethernet communication into a single compact unit, reducing wiring complexity and cabinet space by up to 40% compared to separate PLC+HMI setups. Ideal for space-constrained machines like labeling equipment or small conveyors.
-
Intuitive Touchscreen HMI: The 4.3-inch resistive touchscreen enables drag-and-drop screen creation (via CODESYS HMI editor), allowing operators to visualize real-time data (temperatures, pressures, cycle counts) and adjust parameters without external devices.
-
Ethernet Connectivity: The 10/100 Mbps port supports seamless integration with factory networks, enabling remote monitoring via SCADA systems (e.g., ABB Ability™ System 800xA) and cloud-based data logging for predictive maintenance.
-
Scalable I/O Expansion: Onboard I/O (8DI/6DO) can be expanded to 256 points using ABB PM5xx series modules (digital, analog, specialty I/O), adapting to growing automation needs (e.g., adding sensors to a packaging line).
-
Robust Performance: The 400 MHz processor and 128 MB RAM handle complex logic (e.g., motion control sequences, PID loops) with scan times <10 ms, ensuring responsive machine operation.
Typical Applications
The ABB PM556-TP-ETH is widely used in decentralized automation:
-
Machine Automation: Controls packaging machines (timing, sealing, labeling), small CNC routers, and material handling systems (conveyor speed, sorting gates).
-
Process Control: Manages small-scale processes like batch mixing (temperature/level control), water treatment skids, and HVAC units.
-
Building Automation: Integrates lighting, access control, and energy monitoring in smart factories or commercial buildings.
-
OEM Equipment: Embedded in original equipment manufacturer (OEM) machines for plug-and-play automation (e.g., medical device assembly stations).
