ABB SUE3000 1VCF750090R0804

Product introduction

The ABB SUE3000 1VCF750090R0804 is a high-performance static uninterruptible power supply (UPS) designed to provide reliable backup power and voltage regulation for critical electronic equipment. As part of ABB’s SUE series, this 3000 VA UPS combines advanced online double-conversion technology with compact design, making it ideal for protecting servers, network devices, medical equipment, and industrial control systems from power disruptions.

Equipped with a robust VRLA battery system, the ABB SUE3000 1VCF750090R0804 ensures seamless transition to backup power within milliseconds of a mains failure, preventing data loss, equipment damage, and operational downtime. Its online topology continuously conditions the input power, eliminating voltage fluctuations, harmonics, and frequency variations that could affect sensitive electronics.

In modern infrastructure, the ABB SUE3000 1VCF750090R0804 serves as a critical power safeguard, bridging the gap between utility power outages and backup generator activation. Its dual mounting options (rack or tower) and flexible battery extension capability allow customization for diverse environments, from data center racks to industrial control rooms.

Core advantages and technical highlights

Online double-conversion technology: The ABB SUE3000 1VCF750090R0804 employs online topology, where incoming AC power is continuously converted to DC and back to regulated AC. This ensures the output power remains stable regardless of input fluctuations, providing “clean” power for sensitive equipment like medical imaging devices or laboratory instruments. Unlike offline UPS systems, there is no transfer time during power failures, eliminating the risk of equipment shutdown.

High efficiency modes: With up to 92% efficiency in online mode and 98% in eco mode, the ABB SUE3000 1VCF750090R0804 minimizes energy waste. Eco mode automatically activates during stable mains conditions, bypassing the double-conversion process to reduce energy consumption while maintaining surge protection. This balance of performance and efficiency lowers operational costs, especially in 24/7 environments like data centers.

Flexible backup time: The standard configuration provides 5-15 minutes of backup at full load, sufficient for safe shutdown of servers or bridging short outages. For extended runtime, the ABB SUE3000 1VCF750090R0804 supports external battery packs, allowing customization to match application needs—from 30 minutes for critical industrial controls to several hours for emergency communication systems.

Comprehensive protection: The UPS integrates multiple protection mechanisms, including overload (up to 150% for 10 seconds), short circuit, and surge protection (up to 20kA). It also guards against undervoltage/overvoltage conditions, ensuring connected equipment is shielded from all common power anomalies. This all-in-one protection eliminates the need for separate surge suppressors or voltage regulators.

Smart monitoring and control: Via USB, RS232, and dry contact interfaces, the ABB SUE3000 1VCF750090R0804 enables remote monitoring and management. Compatible with ABB’s Power Management Software, it provides real-time status updates, battery health diagnostics, and automated shutdown triggers for connected devices. This visibility allows proactive maintenance, such as replacing batteries before failure, and ensures orderly shutdowns during prolonged outages.

Typical application scenarios

In small to medium-sized data centers, the ABB SUE3000 1VCF750090R0804 protects rack-mounted servers, switches, and storage systems. Installed in 19-inch racks, it provides clean power to prevent data corruption from voltage spikes and ensures enough runtime to safely shut down equipment or switch to generator power during mains failures. Its eco mode reduces energy costs during stable operation, while remote monitoring via the data center’s BMS tracks UPS performance across multiple units.

Within medical clinics, the UPS safeguards diagnostic equipment (e.g., ultrasound machines, ECG monitors) and electronic health record systems. Its online topology ensures consistent power quality, critical for accurate test results, while backup time is extended with external batteries to maintain operation during emergency power transitions. The dry contact interface triggers alerts to staff when mains power fails, ensuring patient care is uninterrupted.

In industrial settings, the ABB SUE3000 1VCF750090R0804 protects PLCs, HMI panels, and sensor networks in manufacturing lines. It mitigates power fluctuations from factory machinery, preventing control system errors and production stoppages. The UPS’s rugged design withstands the temperature variations of industrial environments, while its short-circuit protection guards against faults in connected equipment.

For retail and office environments, the UPS protects point-of-sale systems, routers, and VoIP phones. It ensures transaction data is saved during outages and maintains communication systems, preventing revenue loss and customer service disruptions. The compact tower design fits unobtrusively in back offices, while USB connectivity allows integration with POS management software for automated alerts.

ABB SUE3000 1VCF750090R0804

Related model recommendations

ABB SUE6000 1VCF750091R0804: A 6000 VA variant of the ABB SUE3000 1VCF750090R0804 for higher-power applications like server clusters.

ABB BPE100: An external battery pack that extends the runtime of the ABB SUE3000 1VCF750090R0804 by up to 4 hours at full load.

ABB PMCS100: Power management software that monitors and controls the ABB SUE3000 1VCF750090R0804, enabling remote shutdown and battery diagnostics.

ABB surge arrester OVR T2: A supplementary surge protection device that enhances the ABB SUE3000 1VCF750090R0804‘s ability to handle extreme voltage spikes.

ABB AC500 PLC: A programmable logic controller that can interface with the ABB SUE3000 1VCF750090R0804 via RS232 for industrial power management.

ABB rack mounting kit RMK-SUE: A hardware accessory for secure 19-inch rack installation of the ABB SUE3000 1VCF750090R0804.

Installation, commissioning and maintenance instructions

Installation preparation: Choose a well-ventilated location with ambient temperature between 0°C and 40°C, away from direct sunlight and heat sources. For rack mounting, ensure the 19-inch rack has sufficient depth (≥600mm) and weight capacity (≥20kg). For tower installation, place on a flat, stable surface. Required tools include a screwdriver, cable ties, and a multimeter. Connect input power via a dedicated circuit breaker (16A recommended) to avoid overloads.

Commissioning steps: After installation, power on the UPS and verify the LCD display shows “Online” mode. Test battery backup by disconnecting mains power—confirm the UPS switches to battery mode without output interruption. Use the USB/RS232 interface to connect to a computer and install monitoring software, configuring shutdown thresholds (e.g., 20% battery remaining). Perform a full battery discharge test to calibrate runtime indicators, ensuring accurate backup time readings.

Maintenance suggestions: Inspect the ABB SUE3000 1VCF750090R0804 monthly for dust accumulation; clean vents with compressed air if needed. Check battery status via the LCD or software—replace batteries every 3-5 years (or when capacity drops below 80%). Test the UPS annually by simulating a mains failure to verify battery runtime and transfer functionality. Ensure firmware is updated to the latest version via ABB’s software portal to access performance improvements.

Service and guarantee commitment

The ABB SUE3000 1VCF750090R0804 comes with a 3-year warranty from the date of purchase, covering parts and labor for manufacturing defects. The battery is covered for 2 years. ABB guarantees technical support response within 24 hours and, for critical failures, on-site service within 48 hours in major urban areas.

Extended service contracts are available, offering options like annual preventive maintenance, battery replacement services, and 24/7 priority support. These contracts ensure the UPS remains in optimal condition, with ABB’s certified technicians performing regular health checks and addressing issues before they cause downtime. The ABB SUE3000 1VCF750090R0804 is designed for a 10-year operational lifespan with proper maintenance.
