  • High-Speed Signal Processing: The module features a 400 MHz ARM9 32-bit processor, ensuring rapid processing of complex signal transmission tasks.
  • Robust Design: The module is designed to withstand harsh industrial conditions, with a wide operating temperature range and IP67 protection rating.
  • Flexible Communication: Supports multiple communication protocols, including Modbus RTU, Profibus DP, CANopen, EtherNet/IP, and PROFINET, ensuring seamless integration with various industrial systems.
  • Compact Size: With dimensions of 100 mm × 50 mm × 30 mm and a weight of 0.25 kg, the module is easy to install and maintain.
  • Integrated UPS: Features a 1-second integrated UPS power supply to enhance system reliability.
Get a Quote
Manufacturer:
Part number: ABB 802A028D-3
Our extensive catalogue, including : ABB 802A028D-3 , is available now for dispatch to the worldwide.
  • Full 12-month warranty
  • Available for dispatch immediately
  • We deliver worldwide

Description

Detailed Parameter Table

Parameter Name Parameter Value
Product model ABB 802A028D-3
Manufacturer ABB
Product category Signal Conditioning and Interface Module
Operating Voltage 24 V DC (±10%)
Input Channels 8-16 digital inputs (24V DC, source/sink)
Output Channels 8-16 transistor/relay outputs (≤2A)
Analog Input Channels 4-8 channels (0-10V, 4-20mA, 12-16 bit resolution)
Analog Output Channels 2-4 channels (0-20mA, ±10V)
Communication Interfaces RS-485, Ethernet
Supported Protocols Modbus RTU, Profibus DP, CANopen, EtherNet/IP, PROFINET
Real-Time Clock Battery-backed
UPS Function 1-second integrated UPS power supply
Operating Temperature Range -40°C to +70°C
Storage Temperature Range -55°C to +85°C
Humidity Range 5% to 95% RH (non-condensing)
Protection Class IP67
Dimensions 100 mm × 50 mm × 30 mm
Weight 0.25 kg
Certifications CE, UL, cUL, RoHS compliant
ABB 802A028D-3

ABB 802A028D-3

Product Introduction

The ABB 802A028D-3 is a high-performance signal conditioning and interface module designed for industrial automation systems. It acts as a bridge between field devices, such as sensors and actuators, and control platforms, ensuring seamless communication and data transfer.

Core Advantages and Technical Highlights

  • High-Speed Signal Processing: The module features a 400 MHz ARM9 32-bit processor, ensuring rapid processing of complex signal transmission tasks.
  • Robust Design: The module is designed to withstand harsh industrial conditions, with a wide operating temperature range and IP67 protection rating.
  • Flexible Communication: Supports multiple communication protocols, including Modbus RTU, Profibus DP, CANopen, EtherNet/IP, and PROFINET, ensuring seamless integration with various industrial systems.
  • Compact Size: With dimensions of 100 mm × 50 mm × 30 mm and a weight of 0.25 kg, the module is easy to install and maintain.
  • Integrated UPS: Features a 1-second integrated UPS power supply to enhance system reliability.

    ABB 802A028D-3

    ABB 802A028D-3

Typical Application Scenarios

The ABB 802A028D-3 is widely used in various industrial applications, including:
  • Mechanical Manufacturing: Efficiently handles signal transmission between sensors and actuators to ensure stable and efficient production processes.
  • Petrochemical and Energy Industry: Ensures high reliability and real-time performance in harsh working environments.
  • Water Conservancy, Environmental Protection, and Power Industry: Improves the efficiency and accuracy of data transmission and optimizes resource allocation.
  • Building Automation: Used in HVAC systems, lighting management, and security systems.

Related Model Recommendations

  • ABB 802A028D-4: An upgraded version with enhanced signal processing capabilities, suitable for scenarios requiring higher precision and faster data processing.
  • ABB 802A028D-2: An economical alternative with basic signal conditioning functions, suitable for less complex industrial automation settings.
  • ABB 802A029D-3: A variant with additional communication interfaces, providing more flexibility for integration with a wider range of devices.
  • ABB 802A028E-3: With improved diagnostic capabilities, it provides more detailed insights for troubleshooting complex signal-related issues.
  • ABB 802A027D-3: A compact version with smaller external dimensions, suitable for space-limited installations without sacrificing core functionality.

Installation, Commissioning and Maintenance Instructions

Installation Preparation

Before installing the ABB 802A028D-3, ensure the environment is free from excessive dust and moisture. Verify that the power supply matches the module’s requirements (24 V DC) and that the operating temperature range (-40°C to +70°C) is suitable for the installation location.

Maintenance Suggestions

Regular maintenance is crucial for extending the lifespan of the ABB 802A028D-3. Perform routine inspections to check for loose connections or signs of wear. Clean the module periodically to prevent dust buildup and monitor its operation to detect any potential issues early.

Service and Guarantee Commitment

The ABB 802A028D-3 is backed by a comprehensive warranty, ensuring customer satisfaction and peace of mind. ABB is committed to providing exceptional after-sales service, with a dedicated technical support team available to assist with any issues or inquiries.
