Detailed Parameter Table
| Parameter Name | Parameter Value |
|---|---|
| Product model | ABB CP676 3ABD00038801 |
| Manufacturer | ABB |
| Product category | Industrial HMI Touchscreen Control Panel |
| Display size | 15 inches |
| Display resolution | 1024 x 768 pixels |
| Display type | TFT LCD, 64K colors |
| Touchscreen type | Resistive touch screen |
| Communication protocols | Ethernet (10/100 Mbps), RS-232, RS-485, USB 2.0, CANopen |
| Operating temperature | -20°C to +60°C |
| Storage temperature | -40°C to +70°C |
| Power supply | 24 V DC (18-32 V DC) |
| Power consumption | ≤15 W |
| Dimensions | 450 mm x 102 mm x 119 mm |
| Weight | 3.3 kg |
| Protection class | IP65 (front panel) |
| Certifications | CE, UL, RoHS, IEC 61131-2, IEC 61000-6-2/4 |
CP650 1SAP550100R0001
Product Introduction
The ABB CP676 3ABD00038801 is a high-performance industrial HMI touchscreen control panel designed for a wide range of automation applications. It features a 15-inch TFT LCD display with a resolution of 1024 x 768 pixels and supports 64K colors, providing clear and detailed visual feedback for operators. The panel is equipped with multiple communication interfaces, including Ethernet, RS-232, RS-485, USB 2.0, and CANopen, enabling seamless integration with various industrial systems.
Core Advantages and Technical Highlights
High-Resolution Display: The CP676 features a 15-inch TFT LCD with a resolution of 1024 x 768 pixels and 64K colors, ensuring clear and detailed visualization.
Versatile Communication Options: The panel supports multiple communication protocols, including Ethernet (10/100 Mbps), RS-232, RS-485, USB 2.0, and CANopen, enabling seamless integration with various industrial systems.
Robust Industrial Design: The CP676 is designed for harsh industrial environments, with an IP65 protection rating for the front panel and an operating temperature range of -20°C to +60°C. Its compact size and lightweight construction (3.3 kg) make it easy to install and integrate into control panels.
User-Friendly Interface: The resistive touchscreen supports single-touch operation and is compatible with gloves, making it suitable for industrial environments. The panel also includes ABB’s Panel Builder 800 software for easy interface development.
Advanced Diagnostics: Built-in diagnostic functions monitor communication link status and report faults via indicator lights or software logs, ensuring quick identification and resolution of issues.
CP650 1SAP550100R0001
Typical Application Scenarios
The ABB CP676 3ABD00038801 is widely used in various industrial sectors, including manufacturing, power generation, water and wastewater treatment, and HVAC systems. It is ideal for applications requiring precise control and monitoring of industrial processes, such as temperature, pressure, and flow control. The panel’s ability to operate in a wide temperature range and its compact design make it suitable for both indoor and outdoor installations.
Related Model Recommendations
-
ABB CP635: A 7-inch touchscreen control panel with similar functionality but smaller in size.
-
ABB CP660: A 12.1-inch touchscreen control panel, offering a larger display for more detailed visualization.
-
ABB AC800 Series: PLC controllers that can be seamlessly integrated with the CP676 for comprehensive automation solutions.
-
ABB PM595-4ETH: An Ethernet communication module that can be used for additional connectivity options.
Installation, Commissioning and Maintenance Instructions
Installation Preparation
Before installing the ABB CP676 3ABD00038801, ensure that the environment meets the specified requirements, including an operating temperature range of -20°C to +60°C. The installation location should be free from excessive dust, moisture, and corrosive gases to ensure long-term reliability. Use a standard DIN rail or panel mount for secure installation.
Maintenance Suggestions
To maintain the ABB CP676 3ABD00038801, perform regular inspections of the panel and its connections to ensure they are secure and free from corrosion. Clean the unit regularly with a soft, dry cloth to remove dust and debris. If any issues arise, refer to the troubleshooting guide in the user manual for common solutions. Replace any worn or damaged parts promptly to ensure continued performance. Regularly update the firmware to benefit from the latest enhancements and security features.
Service and Guarantee Commitment
The ABB CP676 3ABD00038801 is backed by ABB’s commitment to quality and customer satisfaction. ABB offers a comprehensive warranty that covers manufacturing defects and ensures the product meets the highest standards of reliability. In addition to the warranty, ABB provides extensive after-sales support, including technical assistance and spare parts availability.
