High Precision and Fast Response: The DI01 module can accurately receive and process external digital signals, achieving fast response times of less than 10ms. This high precision and rapid response make it ideal for real-time monitoring and control in industrial environments.
Stable and Reliable: The DI01 features a robust design with isolation and protection functions for each input channel, ensuring reliable operation in harsh industrial conditions. It can operate stably within a wide temperature range of -20°C to +70°C.
Multi-Channel Design: The DI01 module typically supports up to 16 input channels, allowing it to monitor multiple signal sources simultaneously. This multi-channel design enhances the system’s parallel processing capabilities.
Signal Conversion and Processing: The module converts external digital signals into signals that can be recognized by PLCs or other control systems, ensuring high data quality and reliability.
Wide Application Range: The DI01 is widely used in various industrial sectors, including manufacturing, power generation, oil & gas, and water treatment, for monitoring switch states, sensor signals, and other digital inputs.
Get a Quote
Manufacturer:
Part number: ABB DI01
Our extensive catalogue, including : ABB DI01 , is available now for dispatch to the worldwide.
  • Full 12-month warranty
  • Available for dispatch immediately
  • We deliver worldwide

Description

Detailed Parameter Table

Parameter Name Parameter Value
Product model ABB DI01
Manufacturer ABB
Product category Digital Input Module
Input voltage range 24V DC
Input signal type Digital (typically passive contacts or active signals like 0/1VDC or 4-20mA)
Input channels Up to 16 channels (depending on model)
Response time < 10ms
Operating temperature -20°C to +70°C
Humidity 5% to 95% non-condensing
Protection class IP20
Dimensions 100 mm x 130 mm x 77 mm
Weight 0.5 kg
Communication protocols Profibus, Modbus, Ethernet/IP (depending on model)
Certifications CE, RoHS
ABB DI01

ABB DI01

Product Introduction

The ABB DI01 is a high-performance digital input module designed for industrial automation and control systems. It is part of ABB’s extensive range of I/O modules and is specifically designed to receive and process digital signals from various sensors and switches. The DI01 module is known for its high precision, fast response, and robust design, making it suitable for a wide range of industrial applications.

Core Advantages and Technical Highlights

High Precision and Fast Response: The DI01 module can accurately receive and process external digital signals, achieving fast response times of less than 10ms. This high precision and rapid response make it ideal for real-time monitoring and control in industrial environments.
Stable and Reliable: The DI01 features a robust design with isolation and protection functions for each input channel, ensuring reliable operation in harsh industrial conditions. It can operate stably within a wide temperature range of -20°C to +70°C.
Multi-Channel Design: The DI01 module typically supports up to 16 input channels, allowing it to monitor multiple signal sources simultaneously. This multi-channel design enhances the system’s parallel processing capabilities.
Signal Conversion and Processing: The module converts external digital signals into signals that can be recognized by PLCs or other control systems, ensuring high data quality and reliability.
Wide Application Range: The DI01 is widely used in various industrial sectors, including manufacturing, power generation, oil & gas, and water treatment, for monitoring switch states, sensor signals, and other digital inputs.

ABB DI01

ABB DI01

Typical Application Scenarios

The ABB DI01 is widely used in various industrial sectors, including:
  • Manufacturing: Monitoring assembly lines and robotic systems.
  • Power Generation: Controlling turbines, generators, and boilers in power plants.
  • Oil & Gas: Managing pipeline monitoring and refinery operations.
  • Water Treatment: Monitoring water flow and treatment processes.

Related Model Recommendations

  • ABB DO01: A digital output module that can be used in conjunction with the DI01 for complete control solutions.
  • ABB ACS880 Drives: Compatible with the DI01 for precise motor speed and torque regulation.

Installation, Commissioning and Maintenance Instructions

Installation Preparation

Before installing the ABB DI01, ensure that the environment meets the specified requirements, including an operating temperature range of -20°C to +70°C. The installation location should be free from excessive dust, moisture, and corrosive gases to ensure long-term reliability. Use a standard DIN rail for secure installation.

Maintenance Suggestions

To maintain the ABB DI01, perform regular inspections of the module and its connections to ensure they are secure and free from corrosion. Clean the unit regularly with a soft, dry cloth to remove dust and debris. If any issues arise, refer to the troubleshooting guide in the user manual for common solutions. Replace any worn or damaged parts promptly to ensure continued performance.
