Advanced Measurement Technology: The EL3020 uses non-dispersive infrared absorption (NDIR) technology to detect gas concentrations, ensuring high accuracy and reliability.
Automatic Calibration: The analyzer includes automatic calibration features, simplifying the calibration process and eliminating the need for test gas cylinders.
User-Friendly Interface: The EL3020 features a simple menu-driven interface with a backlit graphic display (240 x 160 pixels) that can display up to five measurements simultaneously.
Versatile Communication Options: The analyzer supports multiple communication protocols, including Ethernet, Modbus, and PROFIBUS, ensuring seamless integration with existing systems.
Wide Operating Range: The EL3020 operates reliably within a temperature range of +5°C to +45°C and a humidity range of <75%, allowing for slight condensation.
Get a Quote
Manufacturer:
Part number: ABB EL3020
Our extensive catalogue, including : ABB EL3020 , is available now for dispatch to the worldwide.
  • Full 12-month warranty
  • Available for dispatch immediately
  • We deliver worldwide

Description

Detailed Parameter Table

Parameter Name Parameter Value
Product Model EL3020
Manufacturer ABB
Product Category Continuous Gas Analyzer
Series EasyLine EL3000
Measurement Principle Non-dispersive Infrared Absorption (NDIR)
Optional Detectors Uras26 Infrared Photometer, Magnos206 Oxygen Analyzer, Caldos27 Thermal Conductivity Analyzer, Electrochemical Oxygen Sensor
Number of Measurement Components Up to 5 (e.g., CO, NO, SO2, O2, N2)
Operating Temperature Range +5°C to +45°C (Uras26: +5°C to +40°C)
Storage Temperature Range -25°C to +65°C
Humidity Range <75% (allowing slight condensation)
Dimensions (W×D×H) 483 mm × 357 mm × 132 mm
Weight 7-15 kg
Power Supply 100-240 V AC, 50-60 Hz
Maximum Power Consumption 187 W
Certifications CE, UL, CSA
Protection Level IP20
Application Areas Industrial Process Control, Emission Monitoring, Environmental Monitoring
ABB EL3020

ABB EL3020

Product Introduction

The ABB EL3020 is a high-performance continuous gas analyzer designed for process and emission monitoring applications. It is part of the EasyLine EL3000 series and is known for its robustness, reliability, and efficiency in harsh industrial environments.

Core Advantages and Technical Highlights

Advanced Measurement Technology: The EL3020 uses non-dispersive infrared absorption (NDIR) technology to detect gas concentrations, ensuring high accuracy and reliability.
Automatic Calibration: The analyzer includes automatic calibration features, simplifying the calibration process and eliminating the need for test gas cylinders.
User-Friendly Interface: The EL3020 features a simple menu-driven interface with a backlit graphic display (240 x 160 pixels) that can display up to five measurements simultaneously.
Versatile Communication Options: The analyzer supports multiple communication protocols, including Ethernet, Modbus, and PROFIBUS, ensuring seamless integration with existing systems.
Wide Operating Range: The EL3020 operates reliably within a temperature range of +5°C to +45°C and a humidity range of <75%, allowing for slight condensation.

ABB EL3020

ABB EL3020

Typical Application Scenarios

The ABB EL3020 is widely used in various industrial sectors, including:
  • Environmental Monitoring: For continuous monitoring of emissions and pollutants.
  • Industrial Process Control: For monitoring gas concentrations in industrial processes.
  • Safety Monitoring: For detecting hazardous gases in industrial environments.

Related Model Recommendations

  • Uras26 Infrared Photometer: For measuring infrared-active gases such as CO, NO, and SO2.
  • Magnos206 Oxygen Analyzer: For measuring oxygen concentrations in process gases.
  • Caldos27 Thermal Conductivity Analyzer: For measuring binary gas mixtures with different thermal conductivities.

Installation, Commissioning, and Maintenance Instructions

Installation Preparation: Ensure the installation environment is clean and free of interference. Prepare the necessary tools and follow the installation manual carefully.
Maintenance Suggestions: Regularly inspect the analyzer for physical damage, monitor output signals using a multimeter, and check for abnormal heat generation or noises. Clean the analyzer’s surface periodically to prevent dust accumulation, which can affect performance.

Service and Guarantee Commitment

The ABB EL3020 comes with a comprehensive warranty, ensuring customer satisfaction and peace of mind. ABB provides technical support and service to assist with installation, troubleshooting, and maintenance.
