Dual-Channel Design: The FAU810 features two independent channels, each capable of receiving and processing signals from a flame detector. Each channel has its own flame relay and 4-20 mA analog output, ensuring precise flame detection.
Smart Detection and Analysis: The unit can automatically select parameters based on different fuel conditions, eliminating the need for frequent manual adjustments. It provides real-time data on flame flickering frequency, radiation intensity, and flame quality.
High Safety and Reliability: The FAU810 continuously monitors the flame detector and its electronic components for faults. It can signal unsafe conditions, such as flame loss, and supports redundant Profibus DP-V1 or standard Modbus interfaces for secure data exchange.
Easy Installation and Configuration: The FAU810 is easy to install and configure. It can be used with all ABB flame detectors and is the standard module for retrofitting existing installations.
Low Power Consumption: The unit consumes only 3.6W, making it energy-efficient and environmentally friendly.
Get a Quote
Manufacturer:

Our extensive catalogue, including , is available now for dispatch to the worldwide.
  • Full 12-month warranty
  • Available for dispatch immediately
  • We deliver worldwide

Description

Detailed Parameter Table

Parameter Name Parameter Value
Product Model FAU810
Manufacturer ABB
Product Category Flame Analysis Unit
Series Uvisor™
Input Voltage Range 21.6V to 31.2V DC
Power Consumption 4W to 10W (standard 6W)
Operating Temperature Range 0°C to 60°C
Storage Temperature Range -25°C to 65°C
Humidity Range 95% non-condensing
Dimensions (W×D×H) 220 mm × 150 mm × 50 mm
Weight 1.5 kg
Certifications CE, UL, CSA
Protection Level IP66 (NEMA 4)
Explosion-proof Rating ATEX II 2GD Ex d IIC T6
Communication Protocols Profibus DP-V1, Modbus
Number of Channels 2 independent channels
Signal Output 4-20 mA (2 channels)
Flame Relays 3 relays (250 Vac, 3A, 750 VA; 220 Vdc, 300 mA, 66W)
Self-Test Cycle 0.1 seconds
ABB FAU810

ABB FAU810

Product Introduction

The ABB FAU810 is a high-performance flame analysis unit designed for industrial applications. It is part of the Uvisor™ series and is known for its robustness, reliability, and efficiency in harsh industrial environments.

Core Advantages and Technical Highlights

Dual-Channel Design: The FAU810 features two independent channels, each capable of receiving and processing signals from a flame detector. Each channel has its own flame relay and 4-20 mA analog output, ensuring precise flame detection.
Smart Detection and Analysis: The unit can automatically select parameters based on different fuel conditions, eliminating the need for frequent manual adjustments. It provides real-time data on flame flickering frequency, radiation intensity, and flame quality.
High Safety and Reliability: The FAU810 continuously monitors the flame detector and its electronic components for faults. It can signal unsafe conditions, such as flame loss, and supports redundant Profibus DP-V1 or standard Modbus interfaces for secure data exchange.
Easy Installation and Configuration: The FAU810 is easy to install and configure. It can be used with all ABB flame detectors and is the standard module for retrofitting existing installations.
Low Power Consumption: The unit consumes only 3.6W, making it energy-efficient and environmentally friendly.

ABB FAU810

ABB FAU810

Typical Application Scenarios

The ABB FAU810 is widely used in various industrial sectors, including:
  • Power Plants: For monitoring and controlling combustion processes in boilers.
  • Industrial Furnaces: For ensuring safe and efficient operation in various industrial heating applications.
  • Incinerators: For real-time monitoring of flame conditions to ensure complete combustion.

Related Model Recommendations

  • SF810 Flame Scanning Head: Compatible with FAU810 for advanced flame detection.
  • DFS Flame Scanning Head: Legacy flame detector compatible with FAU810.

Installation, Commissioning, and Maintenance Instructions

Installation Preparation: Ensure the installation environment is clean and free of interference. Prepare the necessary tools and follow the installation manual carefully.
Maintenance Suggestions: Regularly inspect the unit for physical damage, monitor output signals using a multimeter, and check for abnormal heat generation or noises. Clean the unit’s surface periodically to prevent dust accumulation, which can affect performance.

Service and Guarantee Commitment

The ABB FAU810 comes with a comprehensive warranty, ensuring customer satisfaction and peace of mind. ABB provides technical support and service to assist with installation, troubleshooting, and maintenance.
