Multi-Protocol Support: The FI830F supports multiple communication protocols, including PROFIBUS-DP, Modbus RTU, and Modbus TCP, ensuring compatibility with various industrial devices and systems.
High-Speed Communication: The module supports high-speed data transmission at up to 12 Mbps, ensuring quick and efficient communication.
Electrical Isolation: The module includes 500V AC isolation between channels and the bus, protecting against ground faults and ensuring stable operation.
Wide Operating Temperature Range: The FI830F operates reliably within a temperature range of -20°C to +60°C, making it suitable for diverse industrial environments.
Compact Design: The module has a compact form factor (155 mm × 28 mm × 26 mm) and weighs only 0.26 kg, making it easy to install and integrate into existing systems.
Redundancy and Fault Tolerance: The module supports redundant operation, ensuring continuous operation even in case of network failures.
Get a Quote
Manufacturer:

Our extensive catalogue, including , is available now for dispatch to the worldwide.
  • Full 12-month warranty
  • Available for dispatch immediately
  • We deliver worldwide

Description

Detailed Parameter Table

Parameter Name Parameter Value
Product Model FI830F
Manufacturer ABB
Product Category Fieldbus Module
Series Freelance AC 800F
Communication Protocol PROFIBUS-DP, Modbus RTU, Modbus TCP
Input Voltage Range 24V DC ±10%
Operating Temperature Range -20°C to +60°C
Storage Temperature Range -40°C to +85°C
Humidity Range <75% (allowing slight condensation)
Dimensions (W×D×H) 155 mm × 28 mm × 26 mm
Weight 0.26 kg
Certifications CE, UL, CSA
Protection Level IP20
ABB FI830F

ABB FI830F

Product Introduction

The ABB FI830F is a high-performance fieldbus module designed for industrial automation systems. It is part of the ABB Freelance AC 800F series and is known for its robustness, reliability, and efficiency in harsh industrial environments.

Core Advantages and Technical Highlights

Multi-Protocol Support: The FI830F supports multiple communication protocols, including PROFIBUS-DP, Modbus RTU, and Modbus TCP, ensuring compatibility with various industrial devices and systems.
High-Speed Communication: The module supports high-speed data transmission at up to 12 Mbps, ensuring quick and efficient communication.
Electrical Isolation: The module includes 500V AC isolation between channels and the bus, protecting against ground faults and ensuring stable operation.
Wide Operating Temperature Range: The FI830F operates reliably within a temperature range of -20°C to +60°C, making it suitable for diverse industrial environments.
Compact Design: The module has a compact form factor (155 mm × 28 mm × 26 mm) and weighs only 0.26 kg, making it easy to install and integrate into existing systems.
Redundancy and Fault Tolerance: The module supports redundant operation, ensuring continuous operation even in case of network failures.

ABB FI830F

ABB FI830F

Typical Application Scenarios

The ABB FI830F is widely used in various industrial sectors, including:
  • Manufacturing Plants: For seamless communication between PLCs and industrial devices.
  • Power Plants: For monitoring and controlling power generation processes.
  • Water Treatment Facilities: For managing pumps and valves in water treatment systems.
  • Transportation Systems: For real-time control of traffic signals and other transportation infrastructure.

Related Model Recommendations

  • PM 802F: A compatible power supply module for rack I/O.
  • PM 803F: Another compatible power supply module for rack I/O.
  • FI820F: A similar fieldbus module with different communication protocols.
  • FI830F-3BDH000032R1: A specific variant with PROFIBUS-DP support.

Installation, Commissioning, and Maintenance Instructions

Installation Preparation: Ensure the installation environment is clean and free of interference. Prepare the necessary tools and follow the installation manual carefully.
Maintenance Suggestions: Regularly inspect the module for physical damage, monitor output signals using a multimeter, and check for abnormal heat generation or noises. Clean the module’s surface periodically to prevent dust accumulation, which can affect performance.

Service and Guarantee Commitment

The ABB FI830F comes with a comprehensive warranty, ensuring customer satisfaction and peace of mind. ABB provides technical support and service to assist with installation, troubleshooting, and maintenance.
