ABB LXN1604-6 3BHL000986P7000

Description

Detailed Parameter Table

Parameter Name	Parameter Value
Product model	ABB LXN1604-6
Manufacturer	ABB
Product category	Digital Input/Output Extension Module
Input Voltage Range	24V DC (sinking/sourcing)
Output Voltage	24V DC
Output Current	0.5A per channel (transistor outputs)
I/O Channels	16 digital inputs + 16 digital outputs (configurable)
Communication Protocols	Profibus DP/PA, DeviceNet, Modbus RTU/TCP
Operating Temperature Range	-25°C to +55°C
Storage Temperature Range	-40°C to +85°C
Humidity	5% to 95% (non-condensing)
Dimensions	194 mm x 113.6 mm x 138 mm
Weight	0.5 kg
Protection Rating	IP20 (control cabinet installation)
Certifications	UL 508, CE, IEC 61131-2

ABB LXN1604-6 3BHL000986P7000

Product Introduction

Core Advantages and Technical Highlights

• The ABB LXN1604-6 features 32 total I/O points (16 digital inputs and 16 digital outputs) in a compact form factor, making it ideal for space-constrained applications.
• The module supports hot-swappable replacement, minimizing downtime during maintenance.

• The I/O channels can be configured in 8-channel blocks, allowing for a mix of input and output groups to suit specific application needs.
• Each channel is equipped with diagnostic LEDs, providing real-time status monitoring and simplifying troubleshooting.

• The module is designed with surge protection on all field connections, ensuring reliability in harsh industrial environments.
• It features a DIN rail mounting design, making installation and maintenance straightforward.

• The ABB LXN1604-6 supports multiple communication protocols, including Profibus DP/PA, DeviceNet, and Modbus RTU/TCP, ensuring compatibility with a wide range of control systems.

• The module supports redundancy options, enhancing system reliability and minimizing the risk of single-point failures.
• It includes built-in diagnostic features that provide immediate alerts for any issues, ensuring timely maintenance and reduced downtime.



  ABB LXN1604-6 3BHL000986P7000
  ABB LXN1604-6 3BHL000986P7000

Typical Application Scenarios

• Process Control: For monitoring and controlling critical parameters such as temperature, pressure, and flow rates in chemical and petrochemical plants.
• Power Systems: In substations and power plants, the module is used for monitoring and controlling auxiliary equipment such as pumps and fans.
• Manufacturing: In production lines, it is used for I/O expansion, enabling seamless integration with PLCs and other control systems.
• Water and Wastewater Treatment: For monitoring and controlling water levels, flow rates, and other critical parameters in treatment plants.

Related Model Recommendations

• ABB LXN0804-4: A similar module with fewer I/O points (16 points) and lower power consumption, suitable for space-constrained applications.
• ABB LXN1604-8: An upgraded model with additional I/O points and enhanced communication capabilities, ideal for high-density applications.
• ABB AC500 PLC: A programmable logic controller that works seamlessly with the ABB LXN1604-6 for complete control solutions.
• ABB 3BSE020510R: A termination unit designed for use with the ABB LXN1604-6 to ensure reliable communication.
• ABB Automation Builder: A configuration tool that simplifies the setup and management of ABB automation systems, including the ABB LXN1604-6.

Installation, Commissioning, and Maintenance Instructions

• Ensure the installation environment meets the specified temperature and humidity requirements. The module should be installed in a control cabinet with adequate ventilation to dissipate heat.
• Verify that the power supply voltage is within the specified range (24V DC) to avoid damage to the module.
• Use appropriate tools and follow safety guidelines to ensure a secure installation. The module requires a DIN rail for mounting.

• Regularly inspect the module for signs of wear or damage, and ensure all connections are secure.
• Use the diagnostic LEDs to monitor the status of each channel and identify potential issues early.
• Periodically check the terminal block torque (0.6Nm) to ensure reliable connections.
• Replace any damaged components promptly to maintain system reliability.
