ABB MCU2A02V24

Description

Detailed Parameter Table

Parameter Name	Parameter Value
Product model	ABB MCU2A02V24
Manufacturer	ABB
Product category	Industrial Automation Processor Module
Operating Voltage	24V DC
Operating Temperature Range	-25°C to +70°C
Dimensions (W x H x D)	90 mm x 120 mm x 45 mm
Communication Interface	RS-485, Ethernet
Mounting Type	DIN Rail
Weight	0.5 kg
Protection Rating	IP20 (control cabinet installation)
Certifications	CE, RoHS Compliant

ABB MCU2A02V24

Product Introduction

Core Advantages and Technical Highlights

• The ABB MCU2A02V24 is powered by a high-performance ARM Cortex processor, enabling fast data processing capabilities. This ensures real-time control and monitoring of complex industrial processes.

• Designed in a compact package, the MCU2A02V24 is suitable for space-constrained applications. Its DIN rail mounting design allows for easy integration and installation in control cabinets.

• The module supports multiple communication protocols, including RS-485, Ethernet, and Modbus RTU/TCP, ensuring seamless integration with existing control networks.

• The MCU2A02V24 is designed to meet industrial standards, with robust protection mechanisms to withstand harsh environments and temperature fluctuations. It features surge protection on all field connections, enhancing system reliability.

• Built-in diagnostic tools monitor system health, detect failures, and generate error logs to assist with troubleshooting. This reduces downtime and maintenance costs.

• The module supports a mix of digital and analog I/O channels, allowing for the collection and control of various signals such as temperature, pressure, and flow. It also supports PID control algorithms for precise process control.



  ABB MCU2A02V24

Typical Application Scenarios

• Process Control: For monitoring and controlling critical parameters such as temperature, pressure, and flow rates in chemical and petrochemical plants.
• Manufacturing Automation: Used in production lines to control motors, solenoids, and other discrete manufacturing equipment.
• Building Automation: For monitoring and controlling HVAC systems, lighting, and other building automation equipment.
• Power Systems: In substations and power plants, the module is used for monitoring and controlling auxiliary equipment such as pumps and fans.
• Water and Wastewater Treatment: For controlling variables such as chemical dosing, flow regulation, and pressure monitoring.

Related Model Recommendations

• ABB PXKB 201 Relay Board: A relay board that complements the MCU2A02V24 for expanded control capabilities.
• ABB PXUB 201 Insulation Amplifier: An insulation amplifier that enhances signal integrity in harsh environments.
• ABB PM860K01 Processor Module: An industrial controller that works seamlessly with the MCU2A02V24 for complete control solutions.
• ABB PM862K01 Processor Module: An automation control module that provides advanced control algorithms and integration capabilities.
• ABB INSUMMCU2 Series: Other modules in the INSUMMCU2 series offer similar functionality with different configurations to meet specific application needs.

Installation, Commissioning, and Maintenance Instructions

• Ensure the installation environment meets the specified temperature and humidity requirements. The module should be installed in a control cabinet with adequate ventilation to dissipate heat.
• Verify that the power supply voltage is within the specified range (24V DC) to avoid damage to the module.
• Use appropriate tools and follow safety guidelines to ensure a secure installation. The module requires a DIN rail for mounting.

• Regularly inspect the module for signs of wear or damage, and ensure all connections are secure.
• Use the diagnostic LEDs to monitor the status of each channel and identify potential issues early.
• Periodically check the terminal block torque (0.6Nm) to ensure reliable connections.
• Replace any damaged components promptly to maintain system reliability.
