ABB NTAC-02 58976008

Description

Detailed Parameter Table

Parameter Name	Parameter Value
Product model	ABB NTAC-02 58976008
Manufacturer	ABB
Product category	Pulse Encoder Interface Module
Operating Voltage	24V DC
Input Signal	Pulse encoder signal (A phase, B phase)
Output Signal	Standard digital signal, supports RS-422 or PROFIBUS DP
Resolution	Configurable, up to 20 bits
Accuracy	±0.01° (precision conversion)
Operating Temperature Range	-25°C to +70°C
Protection Rating	IP65
Dimensions (W x H x D)	85 mm x 45 mm x 25 mm
Weight	0.2 kg

ABB NTAC-02 58976008

Product Introduction

Core Advantages and Technical Highlights

• The ABB NTAC-02 58976008 offers high precision with a resolution of up to 20 bits and an accuracy of ±0.01°, ensuring reliable and accurate signal conversion.

• The module supports a wide range of pulse encoder types, including incremental and absolute encoders, making it suitable for various industrial applications.

• Designed for harsh industrial environments, the ABB NTAC-02 58976008 features an IP65 protection rating and operates reliably within a temperature range of -25°C to +70°C.

• With a response time of less than 1 ms, the module ensures real-time control and monitoring, critical for high-speed industrial processes.

• The module supports multiple communication protocols, including RS-422 and PROFIBUS DP, and can be easily configured using ABB’s Control Builder M software.



  ABB NTAC-02 58976008

Typical Application Scenarios

• Manufacturing: For precise control of robotic arms, CNC machines, and packaging lines.
• Energy Management: For monitoring and controlling valve positions and conveyor belts in power plants.
• Process Control: For precise position and speed control in industrial processes.
• Robotics: For joint control and motion synchronization in robotic systems.

Related Model Recommendations

• ABB NTAC-01: A similar pulse encoder interface module with different configurations, suitable for applications requiring lower resolution.
• ABB NTAC-03: An advanced model with higher resolution and additional features for more complex applications.
• ABB ACS800: A frequency converter that works seamlessly with the ABB NTAC-02 58976008 for complete control solutions.
• ABB ACS850: Another compatible frequency converter that benefits from the control capabilities of the ABB NTAC-02 58976008.

Installation, Commissioning, and Maintenance Instructions

• Ensure the installation environment meets the specified temperature and humidity requirements. The module should be installed in a location with adequate ventilation to dissipate heat. Verify that the power supply voltage is within the specified range (24V DC) to avoid damage to the module.

• Regularly inspect the installation to ensure the module is securely mounted and all connections are tight. Monitor the operational status of the module to detect any signs of malfunction early. Conduct functional testing on the module at least once a year to ensure optimal performance.
