ABB PCD230A101 3BHE022291R0101

Description

Detailed Parameter Table

Parameter Name	Parameter Value
Product model	ABB PCD230A101 3BHE022291R0101
Manufacturer	ABB
Product category	Industrial Control Module
Operating Voltage	DC 9-36V (typical 24V DC)
Power Consumption	<4W
Communication Interface	Modbus TCP/IP, RS485, CAN Bus
Operating Temperature Range	-20°C to +60°C
Storage Temperature Range	-40°C to +85°C
Protection Rating	IP67
Dimensions (W x H x D)	132 mm x 105 mm x 52 mm
Weight	1.5 kg
Certifications	CE, UL, IECEx

ABB PCD230A101 3BHE022291R0101

Product Introduction

Core Advantages and Technical Highlights

• The ABB PCD230A101 3BHE022291R0101 features a high-performance processor and ample memory, capable of handling complex control algorithms and tasks with high-speed response and real-time performance.

• The module supports multiple communication protocols, including Modbus TCP/IP, RS485, and CAN Bus, ensuring seamless integration with existing industrial networks and systems.

• The module is designed for harsh industrial environments, with an IP67 protection rating, ensuring durability and reliability even in challenging conditions.

• The module supports programming in five standard IEC-61131-3 languages, providing flexibility for users to customize control logic and algorithms.

• With low power consumption (<4W), the module is designed to optimize energy use without compromising performance.



  ABB PCD230A101 3BHE022291R0101

Typical Application Scenarios

• Manufacturing: For precise control of robotic arms, CNC machines, and packaging lines.
• Energy Management: For monitoring and controlling valve positions and conveyor belts in power plants.
• Process Control: For precise position and speed control in industrial processes.
• Robotics: For joint control and motion synchronization in robotic systems.

Related Model Recommendations

• ABB ACS800: A frequency converter that works seamlessly with the ABB PCD230A101 3BHE022291R0101 for complete control solutions.
• ABB ACS850: Another compatible frequency converter that benefits from the control capabilities of the ABB PCD230A101 3BHE022291R0101.
• ABB ACS550: A versatile frequency converter that can utilize the ABB PCD230A101 3BHE022291R0101 for enhanced control.

Installation, Commissioning, and Maintenance Instructions

• Ensure the installation environment meets the specified temperature and humidity requirements. The module should be installed in a location with adequate ventilation to dissipate heat. Verify that the power supply voltage is within the specified range (DC 9-36V) to avoid damage to the module.

• Regularly inspect the installation to ensure the module is securely mounted and all connections are tight. Monitor the operational status of the module to detect any signs of malfunction early. Conduct functional testing on the module at least once a year to ensure optimal performance.
