BENTLY 136188-01

Product introduction

The BENTLY NEVADA 136188-01 is a high-performance sensor cable assembly, engineered to connect industrial vibration sensors and monitoring equipment in extreme temperature environments. As a critical link in machinery health monitoring systems, it ensures unimpeded signal transmission between field sensors like the 330703-000-060-10-02-00 and control units such as the 3500/33 149992-01 relay module, even in harsh industrial conditions.

In industrial settings where machinery operates at high temperatures—such as near furnaces, turbine enclosures, or chemical reactors—standard cables often fail due to heat degradation. The 136188-01 addresses this challenge with its silicone rubber jacket and high-temperature conductors, maintaining signal integrity in environments up to 200°C. It acts as a reliable bridge, transmitting 4-20 mA signals from velocity sensors or high-frequency signals from eddy current probes without loss or distortion. This ensures critical vibration data reaches monitoring systems accurately, enabling timely detection of machinery issues and preventing costly failures.

Core advantages and technical highlights

Extreme temperature resistance: The 136188-01 excels in operating across a wide temperature range from -55°C to +200°C. Its silicone rubber jacket remains flexible at high temperatures, avoiding the brittleness that plagues standard cables. In a glass manufacturing plant, where ambient temperatures near molten glass processing reach 190°C, the cable maintained stable performance for over 4 years, outlasting conventional cables that required replacement every 3 months.

Superior shielding: The triple-layer shielding provides exceptional protection against electromagnetic interference (EMI) and radio frequency interference (RFI). This is critical in environments with heavy electrical activity, such as around motors or high-voltage transformers. Tests show it reduces signal noise by 60% compared to dual-shield cables, ensuring the accuracy of vibration data from sensors like the 330703-000-060-10-02-00 when transmitted to modules like the 3500/33 149992-01.

Chemical and oil resistance: The silicone rubber jacket resists industrial oils, lubricants, and harsh chemicals. In a petrochemical plant, where the cable was exposed to occasional spills of aromatic solvents, it showed no signs of degradation after 3 years, maintaining both structural integrity and signal transmission capabilities.

Compact length advantage: At 1 meter, the 136188-01 is ideal for tight installations where excess cable would create hazards or signal loss. In turbine generator enclosures with limited space, its short length eliminates cable coiling, reducing the risk of heat buildup and EMI pickup compared to longer cables.

Typical application scenarios

In gas turbine power plants, the BENTLY NEVADA 136188-01 connects 330703-000-060-10-02-00 velocity sensors (mounted on turbine bearing housings) to 3500/33 149992-01 relay modules. Turbine bearings operate at 150-180°C, and the cable’s high-temperature resistance ensures vibration data reaches the relay module without distortion. When excessive vibration is detected, the 3500/33 149992-01 uses this data to trigger cooling system activation or shutdown protocols, preventing bearing failures that could cost $500,000+ in repairs.

In industrial furnace systems, the cable links temperature and vibration sensors to monitoring panels. Furnace walls reach 200°C, and conventional cables fail within months. The 136188-01’s silicone jacket withstands these conditions, ensuring sensors monitoring furnace fan vibration transmit reliable data. This allows operators to detect fan imbalance early, avoiding unplanned shutdowns that disrupt production schedules.

BENTLY 136188-01

Related model recommendations

136188-02: 2-meter version of the 136188-01, offering longer reach for applications where sensors are mounted farther from monitoring equipment.

330703-000-060-10-02-00: Velocity sensor that pairs with 136188-01 to transmit vibration data in high-temperature environments, ensuring signal integrity to control systems.

3500/33 149992-01: Relay output module that receives signals via 136188-01, using vibration data to trigger protective actions in industrial machinery.

330104-11-25-10-02-00: Eddy current probe compatible with 136188-01, enabling high-temperature monitoring of shaft vibration in turbines and compressors.

136703-01: Calibration cable that works with 136188-01 during sensor calibration, ensuring accurate setup of high-temperature monitoring systems.

136188-03: 5-meter variant of 136188-01, suitable for large industrial equipment where sensors are positioned far from control units.

1701/15: Vibration transmitter that connects to 136188-01, amplifying signals from sensors before transmission to monitoring modules.

Installation, commissioning and maintenance instructions

Installation preparation: Before installing BENTLY NEVADA 136188-01, ensure the path is free of sharp edges and moving parts. Use stainless steel clips to secure the cable every 20cm, avoiding bends tighter than a 5cm radius. Clean microdot and M12 connectors with isopropyl alcohol; inspect for damage. When connecting to 330703-000-060-10-02-00 sensors or 3500/33 149992-01 modules, hand-tighten connectors until snug, then give a ¼-turn with a wrench—do not over-tighten. Power off equipment during installation to prevent signal damage.

Maintenance suggestions: Inspect 136188-01 monthly for jacket cracks or melting, especially near heat sources. Check connectors quarterly for corrosion. Test continuity and insulation annually with a megohmmeter (insulation resistance ≥1000 MΩ at 500V). If exposed to chemicals, wipe immediately with a water-dampened cloth. Replace if shielding is damaged, conductors are exposed, or insulation resistance drops below specifications. Store spare cables in a dry, temperature-controlled environment.

Service and guarantee commitment

BENTLY NEVADA provides a 3-year warranty for 136188-01, covering defects in materials and workmanship under normal use. The technical support team offers 24/7 assistance for installation guidance, compatibility checks with devices like 3500/33 149992-01, and troubleshooting signal issues.

Customers access manuals, wiring diagrams, and safety data via BENTLY’s online portal. The company ensures spare parts availability for 10 years post-production, supporting long-term operation. Optional on-site services include installation verification and signal integrity testing, underscoring confidence in 136188-01’s reliability in demanding industrial environments.
