EMERSON VE3007 12P4375X012 | Industrial Control Valve Actuator
EMERSON VE3007 12P4375X012 | Industrial Control Valve Actuator
Brand: Emerson
• Model: VE3007 (Part Number: 12P4375X012)
• Product Type: Control Valve Package (Actuated Ball Valve)
• Series: Fisher V300 Vee-Ball Valve
• Core Function: Regulates the flow of process fluids (liquids, gases, slurries) in industrial piping systems by varying the position of a V-notch ball in response to a control signal.
Manufacturer: ABB Part number: EMERSON VE3007 12P4375X012
Our extensive ABB catalogue, including
: EMERSON VE3007 12P4375X012
, is available now for dispatch to the worldwide.
VE3007: Product OverviewThe EMERSON VE3007 is a control valve package from the Fisher V300 series, specifically a Vee-Ball control valve. This model combines a V300 valve body with a pneumatic actuator and likely a Fisher field-mounted or digital valve controller. It is designed for precise modulating control in demanding industrial applications involving liquids, gases, and slurries. The valve’s defining feature is its characterized V-notch ball, which rotates to provide a precise equal percentage flow characteristic, excellent shutoff, and enhanced ability to handle erosive and cavitating flows compared to standard ball valves.Installed in process pipelines, its primary function is to automatically adjust the flow rate based on a control signal (typically 3-15 psi or 4-20 mA) from a process controller (DCS or PLC). The Vee-Ball design is particularly effective for applications requiring high rangeability (the ratio of maximum to minimum controllable flow) and tight shutoff. The package is engineered for reliability in severe service conditions, including high-pressure drops, flashing, and slurry services, common in industries like oil & gas, power generation, chemical, and mining.
EMERSON VE3007 12P4375X012
VE3007: Technical Specifications
• Model Number: VE3007
• Manufacturer Part Number: 12P4375X012
• Manufacturer: Emerson (Fisher)
• Product Type: Vee-Ball Control Valve Package
• Valve Body Style: V300 Vee-Ball
• Valve Size: Specific size (e.g., 2-inch, 3-inch) defined by the full part number.
• Pressure Class: ANSI Class 150, 300, 600, etc. (specific to order)
• Body Material: Carbon steel, stainless steel (e.g., CF8M), or other alloys.
• Trim Material: Typically hardened stainless steel or stellite for erosion resistance.
• Actuator: Pneumatic spring-return or double-acting (specific type and size based on required thrust).
• Flow Characteristic: Equal percentage (inherent from the V-notch).
• Leakage Class: ANSI Class IV, V, or VI (depending on seat material).
• Accessories: Positioner, limit switches, solenoid valves, etc. (as per the specific package configuration).
EMERSON VE3007 12P4375X012
Core Features & Customer ValueThe primary value of the Vee-Ball design is its superior control performance for difficult services. The V-port creates a shearing action as it moves past the seat, which helps prevent clogging and makes it ideal for slurry applications like mining tailings or wastewater. The characterized profile provides precise and stable control over a wide range of flows (high rangeability), which is crucial for processes requiring tight control loops.The robust construction ensures long service life even with abrasive or cavitating fluids. For plant operators, this translates to reduced maintenance costs and less unplanned downtime. The package is designed as a complete, pre-assembled solution, which simplifies procurement, installation, and commissioning. When equipped with a digital valve controller (like Fisher FIELDVUE or Fisher Vee-Ball Series 2), it provides valuable diagnostic data for predictive maintenance, allowing issues like packing wear or seat degradation to be identified before they cause a process shutdown.Typical ApplicationsIn mineral processing plants, the VE3007 controls the flow of abrasive slurries in grinding and separation circuits. The Vee-Ball’s shearing action and erosion-resistant trim handle the abrasive particles effectively.In chemical processing, it regulates the flow of corrosive monomers or polymers, where its tight shutoff and precise control are essential for batching and reaction processes.
