GE IS200EISBH1AAA | Mark V Series Analog I/O Board for Gas Turbine Control

  • Brand: GE (General Electric)
  • Model: IS200EISBH1AAA (Variant of IS200 Series)
  • Product Type: Analog Input/Output (I/O) Board
  • Series: Mark V (Gas Turbine Control Systems)
  • Core Function: Serves as a critical analog signal processing interface in GE Mark V gas turbine control systems, enabling precise scaling, conditioning, and transmission of analog signals between field devices (e.g., sensors, actuators) and the VMEbus controller. Designed for high-reliability industrial environments.
  • Key Specs:
    • Bus Compatibility: VMEbus Rev. C.1 (supports 8/16/32-bit data transfer)
    • Form Factor: 6U Eurocard (160 mm × 233 mm)
    • Input Signal Types: LVDT (Linear Variable Differential Transformer), thermocouple, 4–20 mA, ±10 V DC
    • Output Signal Types: 4–20 mA, ±10 V DC, relay driver
    • Isolation: Galvanic isolation (optocouplers, 1500 V AC channel-to-channel)
    • Operating Temperature: 0°C to +55°C (industrial-grade)
Get a Quote
Manufacturer:
Part number: IS200EISBH1AAA
Our extensive catalogue, including : IS200EISBH1AAA , is available now for dispatch to the worldwide.

Description

IS200EISBH1AAA: Product Overview​
The GE IS200EISBH1AAA​ is an analog I/O board designed specifically for GE Mark V gas turbine control systems, a legacy platform renowned for its reliability in industrial power generation. As part of the Mark V ecosystem, it acts as a “signal conditioner” for analog inputs from field devices (e.g., turbine blade position sensors, fuel flow meters) and analog outputs to actuators (e.g., servo valves, pumps). Its primary role is to ensure accurate signal transmission between the field and the VMEbus controller, which is critical for maintaining turbine stability and efficiency.
Role in Automation Systems:
Positioned as a “field signal interface” in Mark V architectures, the IS200EISBH1AAA performs two key functions:
  1. Signal Conditioning: Receives raw analog signals from field devices (e.g., a thermocouple measuring turbine exhaust temperature) and scales/conditions them into a format suitable for the VMEbus controller (e.g., converting millivolt signals to 4–20 mA current loops).
  2. Signal Transmission: Sends conditioned analog signals to the VMEbus controller for processing (e.g., adjusting fuel flow based on temperature readings) and receives control signals from the controller to drive actuators (e.g., opening a valve to increase coolant flow).
Core Functionality:
  • VMEbus Compatibility: Conforms to VMEbus Rev. C.1, ensuring seamless integration with VME64 backplanes and controllers (e.g., GE Fanuc 90-30 series). This allows the board to work with existing Mark V components without major system upgrades.
  • Flexible Signal Handling: Supports multiple analog signal types (LVDT, thermocouple, 4–20 mA, ±10 V DC) through configurable input channels, making it adaptable to diverse field devices.
  • Galvanic Isolation: Uses optocouplers to isolate field devices from the controller, protecting sensitive electronics from voltage spikes and electromagnetic interference (EMI) in harsh industrial environments.
  • High Precision: Provides accurate signal scaling (e.g., 12-bit resolution for analog inputs) to ensure reliable data for turbine control algorithms.

    GE DS3800NAIF1A1A

    GE DS3800NAIF1A1A

Platform Benefits (Mark V Series):
The IS200EISBH1AAA inherits the Mark V platform’s strengths, including:
  • Reliability: The Mark V system is the industry standard for gas turbine control, with a proven track record of 24/7 operation in power plants worldwide.
  • Legacy Compatibility: The board is designed to work with existing Mark V components (e.g., contactors, I/O modules), reducing the cost of system upgrades.
  • Scalability: Supports expansion with additional I/O modules to accommodate growing system demands (e.g., adding more sensors to a turbine control system).
Technical Specifications​
  • Model Number: IS200EISBH1AAA (Variant of IS200 Series)
  • Manufacturer: GE (General Electric)
  • Product Type: Analog I/O Board
  • Series: Mark V (Gas Turbine Control)
  • Form Factor: 6U Eurocard (160 mm × 233 mm)
  • Bus Standard: VMEbus Rev. C.1 (supports 8/16/32-bit data transfer)
  • Input Channels: Configurable (e.g., 8 analog inputs, 4–20 mA or ±10 V DC)
  • Output Channels: Configurable (e.g., 4 analog outputs, 4–20 mA or ±10 V DC)
  • Isolation: Galvanic isolation (optocouplers, 1500 V AC channel-to-channel)
  • Resolution: 12-bit (analog input), 10-bit (analog output)
  • Accuracy: ±0.1% (full-scale, analog input), ±0.2% (full-scale, analog output)
  • Operating Temperature: 0°C to +55°C (32°F to 131°F)
  • Storage Temperature: -40°C to +85°C (-40°F to 185°F)
  • Humidity: 5–95% non-condensing
  • Weight: 0.2 kg (0.44 lbs)
  • Certifications: CE, UL (inferred from GE industrial product standards)
Core Features & Customer Value​
1. Reliable Signal Conditioning:
The IS200EISBH1AAA’s ability to scale and condition analog signals ensures that the VMEbus controller receives accurate data from field devices. For example, in a power plant, the board can precisely measure turbine exhaust temperature (via a thermocouple) and convert it to a 4–20 mA signal for the controller, which adjusts fuel flow to maintain optimal efficiency.
2. Flexible Configuration:
Configurable input/output channels allow engineers to customize the board’s functionality for different field devices, reducing the need for additional signal conditioning hardware. This flexibility saves time and money during installation.
3. Rugged Industrial Design:
The board’s operating temperature range (0°C to +55°C) and compact form factor make it suitable for harsh industrial environments. Its DIN rail mounting option simplifies installation in crowded control cabinets.
4. Easy Integration:
VMEbus compatibility ensures seamless integration with existing VMEbus systems, minimizing downtime and effort during upgrades. This is invaluable for facilities with legacy VMEbus installations, allowing them to enhance system capabilities without replacing entire architectures.

GE DS3800NAIF1A1A

GE DS3800NAIF1A1A

Typical Applications​
The GE IS200EISBH1AAA​ is widely used in industrial automation systems for:
  1. Power Generation:
    • Conditions analog signals from gas/steam turbines (e.g., blade position, fuel flow, temperature) for real-time control, ensuring stable power output.
  2. Manufacturing:
    • Used in assembly lines to process analog signals from sensors (e.g., pressure, flow) and control actuators (e.g., valves, motors).
  3. Petrochemical Industry:
    • Controls analog signals from refinery equipment (e.g., distillation columns, pumps), ensuring safe and efficient operation in hazardous environments.
