NI SCXI-1326

Product Introduction

The National Instruments SCXI – 1326 is a high – voltage terminal block, an integral part of the SCXI (Signal Conditioning eXtension for Instrumentation) platform. It serves as a crucial interface for applications that demand the handling of high – voltage signals.

Functionally, the SCXI – 1326 is designed to connect external high – voltage signals to compatible SCXI modules such as the SCXI – 1162, SCXI – 1162 HV, SCXI – 1163, and SCXI – 1163 R. With its 48 screw terminals, it provides a substantial number of connection points, enabling the management of multiple high – voltage channels. This makes it highly suitable for complex systems where numerous high – voltage signals need to be routed and controlled. Whether in an industrial setting for power control or a high – voltage research environment, the SCXI – 1326 plays a vital role in ensuring the seamless transfer of high – voltage signals within the SCXI system.

Core Advantages and Technical Highlights

High – Voltage Compatibility

The SCXI – 1326 is engineered to handle high – voltage signals with a common – mode isolation of 300 VRMS. This high – voltage handling capability makes it ideal for applications in industrial power systems, where high – voltage signals are used to operate large – scale machinery and equipment. It can safely and efficiently route these high – voltage signals, maintaining electrical safety and signal integrity. For example, in a power – intensive manufacturing plant, the SCXI – 1326 can be used to connect high – voltage sensors and actuators to the SCXI system, ensuring reliable operation of the production process.

Ample Connection Points

With 48 screw terminals arranged in eight groups, the SCXI – 1326 offers a large number of connection options. Each group consists of a Vcc, Gnd, and four channels, providing flexibility in signal routing. This is particularly beneficial in multi – channel high – voltage applications, such as in a high – voltage testing laboratory where multiple signals need to be connected and monitored simultaneously. The numerous connection points simplify the wiring process and reduce the likelihood of connection errors, enhancing the overall efficiency of the system.

Shielded Design

The shielded design of the SCXI – 1326 is a significant advantage. It helps in reducing electromagnetic interference, which is crucial in high – voltage environments where electrical noise can affect the accuracy of signal transmission. By minimizing interference, the SCXI – 1326 ensures that the high – voltage signals are transmitted clearly and accurately. This makes it suitable for applications where precise signal detection and control are required, such as in high – voltage power grid monitoring systems.

Typical Application Scenarios

In industrial power distribution systems, the SCXI – 1326 is used to manage high – voltage circuits. For instance, in a large – scale manufacturing facility, high – voltage electricity powers heavy – duty machinery. The SCXI – 1326 can be connected to the SCXI – 1162 or SCXI – 1162 HV modules to switch these high – voltage circuits on and off, protecting the equipment and ensuring the smooth operation of the manufacturing process. It can also be used to monitor high – voltage signals, providing real – time data on the power distribution system’s performance.

In high – voltage research laboratories, the SCXI – 1326 is essential for conducting experiments. When studying the behavior of high – voltage electrical components or materials, accurate control and routing of high – voltage signals are necessary. The SCXI – 1326 allows researchers to connect various high – voltage sensors and instruments to the SCXI system, enabling precise measurement and analysis of experimental data. This contributes to advancements in fields such as electrical engineering and materials science.

For power grid monitoring and control, the SCXI – 1326 plays a key role. High – voltage signals in the power grid need to be monitored and controlled to maintain grid stability. The SCXI – 1326 can be used to connect sensors that measure parameters like voltage, current, and power quality. By routing these high – voltage signals to the appropriate SCXI modules, the data can be processed and analyzed, allowing operators to detect and address any issues in the power grid promptly.

NI SCXI-1326

Related Model Recommendations

SCXI – 1324: Another high – voltage terminal block in the NI product line. While the SCXI – 1326 is designed for use with specific modules like the SCXI – 1162 series, the SCXI – 1324 is tailored for use with the SCXI – 1160 relay module. The SCXI – 1324 has 24 screw terminals compared to the SCXI – 1326‘s 48, and it may be more suitable for applications with fewer high – voltage connection requirements. However, both are used for high – voltage signal handling within the SCXI system.

SCXI – 1162: A module that the SCXI – 1326 is designed to work with. The SCXI – 1162 is a digital input module, and the SCXI – 1326 provides the connection interface for external high – voltage signals to this module. They are closely related in high – voltage digital input applications within the SCXI system. For example, in an industrial control system where high – voltage digital signals need to be input for equipment operation control, the SCXI – 1326 connects the signals to the SCXI – 1162 for further processing.

SCXI – 1162 HV: A high – voltage version of the SCXI – 1162 module. The SCXI – 1326 is also compatible with this module, and together they are used in applications that require handling even higher – voltage digital signals. In a high – voltage testing setup, the SCXI – 1326 can connect high – voltage sensors to the SCXI – 1162 HV to measure and analyze high – voltage digital signals accurately.

SCXI – 1327: A terminal block with 16 signal terminals. It has a different terminal configuration compared to the SCXI – 1326. The SCXI – 1327 may be more suitable for applications with a lower number of signal connections, while the SCXI – 1326 is better for scenarios where a larger number of high – voltage connections are needed. However, both are part of the SCXI terminal – block product family and can be used in different aspects of an SCXI – based data acquisition or control system.

Installation, Commissioning and Maintenance Instructions

Installation Preparation

Before installing the SCXI – 1326, ensure the SCXI chassis is in a clean, dry, and well – ventilated environment. Power off the chassis to prevent electrical accidents during installation. Gather the necessary tools, including a wire cutter, wire insulation stripper, long – nose pliers, a 1/8 in. flathead screwdriver, and number 1 and 2 Philips – head screwdrivers. When handling the SCXI – 1326, take care not to damage the screw terminals or any internal components. Identify the appropriate slot on the front of the SCXI chassis where the SCXI – 1326 will be installed, following the chassis layout guidelines provided in the SCXI system documentation.

Maintenance Suggestions

For regular maintenance, visually inspect the SCXI – 1326 for any signs of physical damage, such as loose screws, damaged terminals, or signs of overheating. Check for any abnormal odors, which could indicate an electrical problem. If there are issues with signal routing or high – voltage handling, refer to the user manual to troubleshoot. First, verify the connections at the screw terminals to ensure they are secure. In case of a malfunction, if a spare part replacement is needed, always use genuine NI replacement parts to maintain the high – performance and safety standards of the SCXI – 1326. Regularly clean the terminal block to remove dust and debris, as this can help in maintaining optimal electrical conductivity and preventing short – circuits.

Service and Guarantee Commitment

NI offers a comprehensive quality assurance program for the SCXI – 1326. The product undergoes rigorous testing during the manufacturing process to ensure it meets the highest industry standards for performance, safety, and reliability. In terms of after – sales service, NI provides detailed user manuals and installation guides, which are available online for easy access. Technical support is accessible through user forums, where users can interact with NI experts and other users to solve any issues they may encounter. In case of a product defect within the 3 – year warranty period, NI will provide repair or replacement services. This commitment to quality and customer support gives users the confidence that the SCXI – 1326 is a reliable choice for their high – voltage switching and data acquisition needs.
