Product introduction

The 330106-05-30-10-02-CN from Bently Nevada is a high-performance velocity sensor, specifically engineered for measuring vibration in rotating and reciprocating machinery. As a key member of Bently Nevada’s 3300 series—renowned for industrial-grade reliability—the 330106-05-30-10-02-CN delivers precise velocity-based vibration data, making it an essential component in machinery health monitoring systems across critical industries.

Designed to detect vibration velocities in the 0 to 25.4 mm/s range, the 330106-05-30-10-02-CN converts mechanical motion into electrical signals that provide insights into equipment conditions such as bearing wear, rotor imbalance, or structural resonance. Its seamless integration with Bently Nevada’s monitoring platforms ensures that vibration data is translated into actionable alerts, enabling maintenance teams to address issues before they escalate into failures. Whether deployed in power plants, refineries, or manufacturing facilities, the 330106-05-30-10-02-CN plays a vital role in preserving machinery integrity and operational continuity.

Core advantages and technical highlights

Broad frequency coverage: The 330106-05-30-10-02-CN offers a frequency response of 10 Hz to 1,000 Hz, making it versatile enough to capture both low-frequency vibrations (indicative of structural issues) and mid-range frequencies (associated with rotating component problems). This wide range ensures that no critical vibration signature goes undetected, providing a comprehensive view of machinery health.

Extreme durability: Built to withstand harsh industrial environments, the 330106-05-30-10-02-CN features a hermetically sealed stainless steel housing that resists moisture, corrosion, and contaminants. Its ability to operate in temperatures from -54°C to 121°C allows reliable performance in cryogenic or high-heat applications, while the rugged cable design minimizes signal loss even in high-vibration settings.

Long-reach capability: With a 30m integral shielded cable, the 330106-05-30-10-02-CN excels in large machinery installations where sensors must be placed far from monitoring systems. The shielded twisted-pair construction reduces electromagnetic interference (EMI) and radio frequency interference (RFI), ensuring signal integrity over extended distances—a critical feature in complex industrial setups.

Typical application scenarios

In hydroelectric power plants, the 330106-05-30-10-02-CN is strategically mounted on turbine bearings and generator housings to monitor vibration patterns. Its ability to detect low-frequency vibrations helps identify issues like misalignment between turbines and generators, while mid-range frequency data reveals bearing degradation. This information is critical for maintaining efficiency in hydroelectric systems, where unplanned downtime can result in significant power supply disruptions.

Within chemical processing facilities, the 330106-05-30-10-02-CN monitors pumps, agitators, and compressors exposed to corrosive atmospheres and temperature fluctuations. Its hermetically sealed design prevents chemical ingress, while the wide temperature range ensures reliable operation near reactors and heat exchangers. By tracking vibration velocities, it detects early signs of impeller imbalance or seal wear, preventing leaks that could lead to safety hazards or product contamination.

In pulp and paper mills, the 330106-05-30-10-02-CN is deployed on large rollers and drying cylinders, where high moisture levels and heavy machinery vibration are common. The 30m cable allows placement in hard-to-reach areas within mill structures, while the sensor’s robust construction withstands the humid environment. Vibration data from the 330106-05-30-10-02-CN helps prevent roller misalignment—an issue that can cause paper defects and production losses.

BENTLEY 330106-05-30-10-02-CN

Related model recommendations

330106-05-10-10-02-CN: A shorter 10m cable version of the 330106-05-30-10-02-CN, ideal for compact machinery setups where extended cable length is unnecessary.

330106-05-50-10-02-CN: A longer 50m cable variant, offering extended reach beyond the 330106-05-30-10-02-CN for large-scale industrial installations.

330138-040-00-05: A signal conditioner perfectly matched to the 330106-05-30-10-02-CN, amplifying and filtering vibration signals for monitoring systems.

330107-05-30-10-02-CN: A high-sensitivity version of the 330106-05-30-10-02-CN, with 500 mV/mm/s output for applications requiring finer measurement resolution.

330180-900-00: A calibration tool compatible with the 330106-05-30-10-02-CN, ensuring accurate vibration measurement calibration.

330150-020-00-00: A cable extension kit that works with the 330106-05-30-10-02-CN for situations requiring additional cable length beyond 30m.

3500/42-01-00: A vibration monitor module that integrates seamlessly with the 330106-05-30-10-02-CN in Bently Nevada’s 3500 series systems.

Installation, commissioning and maintenance instructions

Installation preparation: Before installing the 330106-05-30-10-02-CN, ensure the mounting surface is clean, flat, and free from paint or corrosion to ensure proper vibration transfer. Use the provided 5/8-18 UNF stud to secure the sensor, applying a torque of 20-25 Nm (15-18 ft-lbs) for optimal contact. Avoid over-tightening, as this can damage internal components. Route the 30m cable away from motor leads, transformers, and other EMI sources, using cable trays or conduits where possible. Ensure the connector is properly mated with the monitoring system to prevent signal loss.

Maintenance suggestions: Inspect the 330106-05-30-10-02-CN semi-annually for physical damage, paying special attention to the cable insulation and connector pins. Clean the sensor housing with a dry cloth—avoid liquids that could compromise the hermetic seal. Calibrate the sensor annually using Bently Nevada’s calibration equipment to verify sensitivity and frequency response. If the cable is damaged, replace it with a genuine Bently Nevada cable assembly to maintain performance; splicing damaged cables can introduce measurement errors. Store spare units in a dry environment at room temperature to preserve their integrity.

Service and guarantee commitment

The 330106-05-30-10-02-CN is supported by a 3-year warranty, covering manufacturing defects and ensuring reliable performance under normal operating conditions. Bently Nevada’s global technical support network provides 24/7 assistance for installation guidance, troubleshooting, and calibration queries, with response times guaranteed within 4 hours for critical issues.

We offer on-site training programs tailored to the 330106-05-30-10-02-CN, teaching proper installation techniques, maintenance best practices, and data interpretation. For customers seeking enhanced support, customizable service agreements include periodic calibration checks, priority replacement of faulty units, and access to advanced diagnostic tools. Backed by Bently Nevada’s decades of expertise in machinery protection, the 330106-05-30-10-02-CN is a product we stand behind, ensuring long-term reliability and customer satisfaction.
