BENTLY 133292-01

Product introduction

The 133292-01 from Bently Nevada is a high-performance shielded communication cable assembly designed specifically for reliable data transmission within 3500 Machinery Protection Systems. This 3-meter cable features D-sub 9-pin connectors on both ends, making it an essential link for serial communication between critical system components. As a specialized connectivity solution, 133292-01 ensures secure and interference-free data transfer between 3500/05-01-03-00-00-00 communication modules and other serial devices, playing a vital role in maintaining the integrity of the system’s data transmission network.

Bently Nevada’s 133292-01 is engineered to address the unique challenges of industrial communication environments, where electromagnetic interference (EMI) and electrical noise can compromise data integrity. Its shielded design and twisted-pair construction minimize signal degradation, ensuring accurate transmission of configuration data, status updates, and measurement values between connected components. This cable is particularly valuable in linking 3500/05-01-03-00-00-00 modules to configuration tools, auxiliary displays, or other serial devices within the 3500 ecosystem.

Core advantages and technical highlights

Enhanced EMI protection: A defining feature of 133292-01 is its dual-layer shielding (foil and braid) with a drain wire, which provides superior protection against electromagnetic interference common in industrial environments. This shielding is critical for maintaining data integrity when transmitting sensitive information between 3500/05-01-03-00-00-00 modules and other system components, preventing communication errors that could lead to incorrect readings or missed alarms.

Robust construction: The cable features 24 AWG conductors with twisted-pair geometry, optimized for serial data transmission at rates up to 115.2 kbps—the maximum speed supported by 3500/05-01-03-00-00-00 serial ports. The twisted pairs reduce cross-talk between conductors, while the durable outer jacket withstands mechanical stress, temperature variations, and exposure to industrial contaminants, ensuring long-term reliability in harsh operating conditions.

Precision connectors: 133292-01 is equipped with high-quality D-sub 9-pin male connectors with solder contacts, ensuring secure mechanical and electrical connections. The connectors feature metal shells that integrate with the cable shielding, providing continuous EMI protection through the entire signal path. This attention to connector design minimizes signal loss at connection points, a common source of communication issues in industrial systems.

System-specific compatibility: Unlike generic serial cables, 133292-01 is engineered specifically for Bently Nevada 3500 systems, ensuring perfect compatibility with 3500/05-01-03-00-00-00 communication modules and other serial devices in the ecosystem. This compatibility eliminates issues with pin assignments, impedance matching, and shielding continuity that can occur with off-the-shelf cables, reducing installation time and troubleshooting efforts.

Typical application scenarios

System configuration connections

In 3500 system commissioning and maintenance, 133292-01 cables connect laptops or configuration terminals to 3500/05-01-03-00-00-00 communication modules via serial ports. This connection enables engineers to upload configuration parameters, download system logs, and perform diagnostic tests using Bently Nevada’s configuration software. The cable’s reliable data transmission ensures that configuration changes are accurately transferred, preventing setup errors that could compromise system performance.

Auxiliary display integration

Industrial facilities often use 133292-01 to connect 3500/05-01-03-00-00-00 modules to remote display panels or annunciators located in control rooms. This setup allows operators to view critical machinery health data without accessing the main rack, enhancing operational visibility. The cable’s shielding ensures that data remains intact even when routed through areas with high electrical noise, such as near motor control centers or power distribution equipment.

Inter-module communication

In larger 3500 installations with multiple racks, 133292-01 cables facilitate serial communication between 3500/05-01-03-00-00-00 modules in different racks, enabling data synchronization across the system. This inter-rack communication ensures consistent status reporting and alarm propagation throughout the protection system, providing a unified view of machinery health across plant-wide monitoring networks.

BENTLY 133292-01

Related model recommendations

3500/05-01-03-00-00-00: Communication module requiring 133292-01 for serial connections.

136180-01: Configuration module that connects to communication modules via this cable.

3500/60 163179-01: Display module that receives serial data through 133292-01.

123M4610: USB cable for environments requiring USB rather than serial connectivity.

3500/44M 176449-03: Monitoring module whose data is transmitted through connected systems.

125744-02: Rack assembly containing components linked by 133292-01 cables.

3500/15 106M1079-01: Power supply module supporting systems using this communication cable.

Installation, handling and maintenance guidelines

Installation

When installing 133292-01, ensure the cable is routed away from high-voltage power lines, motor leads, and other sources of electromagnetic interference to maximize shielding effectiveness. Connect one end to the serial port of the 3500/05-01-03-00-00-00 module and the other end to the target device, ensuring connectors are fully seated and the thumbscrews are tightened to a torque of 0.5-0.6 N·m. Avoid sharp bends (minimum bend radius of 50 mm/2 inches) and excessive tension that could damage conductors or shielding. Secure the cable to rack rails or cable trays using non-metallic clips to prevent vibration-induced wear.

Handling

Handle 133292-01 cables by the jacket rather than the connectors to prevent strain on solder joints. When disconnecting, grasp the connector body rather than pulling on the cable itself. Coil excess cable in loose loops (minimum 200 mm/8 inches in diameter) rather than tightly wrapping to avoid conductor damage. Store unused cables in a clean, dry environment away from direct sunlight and extreme temperatures.

Maintenance

Include 133292-01 in quarterly system inspections, visually checking for cable damage, connector corrosion, or loose connections. Clean connectors annually using approved electronic contact cleaner and a lint-free cloth, ensuring no cleaning agents enter the connector housing. Verify data transmission integrity periodically by checking for communication errors in system logs. Replace cables immediately if they show signs of physical damage, shielding compromise, or if communication issues persist after connector cleaning.

Service and guarantee commitment

Bently Nevada provides the 133292-01 with a 24-month warranty covering manufacturing defects and performance issues under normal operating conditions, including shielding integrity, connector reliability, and signal transmission capability when used with compatible modules like 3500/05-01-03-00-00-00. Our technical support team offers guidance on proper installation, routing, and maintenance practices to ensure optimal performance.

We provide recommendations for cable management and system integration to maximize the longevity of 133292-01 in industrial environments. Beyond the warranty period, our service agreements include cable testing and replacement services to maintain reliable communication within 3500 systems. Bently Nevada’s commitment to quality ensures that 133292-01 cables provide consistent, interference-free communication throughout their operational lifecycle, backed by our global network of service professionals.
