BENTLY 3500/05-01-02-00-00-01

Product introduction

The 3500/05-01-02-00-00-01 from Bently Nevada is a high-reliability power supply module engineered as the primary power source for 3500 Machinery Protection Systems. This compact, rack-mount module delivers regulated multi-voltage outputs specifically optimized for powering the sensitive electronics in 3500 series monitoring components, ensuring stable operation of critical machinery protection and vibration monitoring systems. Bently Nevada’s 3500/05-01-02-00-00-01 serves as the power backbone for advanced monitoring architectures, providing clean, reliable power to system components while maintaining the integrity of measurement data from sensors and expansion modules like the 136719-01.

Bently Nevada’s 3500/05-01-02-00-00-01 addresses the critical need for stable, multi-voltage power in complex monitoring systems where voltage fluctuations can corrupt sensor data or cause system malfunctions. Its rugged design and comprehensive protection features ensure uninterrupted operation even in harsh industrial environments, making it an essential component for maintaining the reliability of the entire 3500 system chain—from field sensors to rack-mounted monitors. This power supply plays a vital role in preserving the accuracy of measurements and ensuring that protection systems have the consistent power required to function correctly.

Core advantages and technical highlights

Multi-voltage output capability: The 3500/05-01-02-00-00-01 provides three regulated output voltages (5 VDC, ±15 VDC, and 24 VDC) to power different components within the 3500 system. This integrated approach eliminates the need for multiple standalone power supplies, simplifying system architecture while ensuring proper voltage matching for sensitive electronics like signal conditioners and monitoring cards.

Dual input flexibility: Supporting both AC (85-264 VAC) and DC (110-300 VDC) input sources, the module offers versatile installation options across global industrial facilities. This flexibility allows seamless integration into facilities with varying power infrastructure, from standard AC mains to DC backup systems, enhancing system reliability.

Comprehensive protection mechanisms: Equipped with overvoltage, overcurrent, short circuit, overtemperature, and reverse polarity protection, the 3500/05-01-02-00-00-01 safeguards both itself and connected 3500 system components from electrical anomalies. This protection is particularly critical for expensive monitoring equipment, ensuring system availability during power disturbances.

High-reliability design: With a mean time between failures (MTBF) exceeding 150,000 hours, the module delivers exceptional long-term reliability required in mission-critical applications. Its compact form factor (1 slot in 3500 racks) maximizes rack space efficiency while maintaining robust performance in industrial environments.

Typical application scenarios

In power generation facilities, the 3500/05-01-02-00-00-01 serves as the primary power source for 3500 systems monitoring turbine and generator vibration, position, and speed. Installed in 3500/20 racks, it provides stable power to 3500/15 monitors, communication modules, and interface cards that process data from proximity sensors and accelerometers. Its ability to accept both AC and DC inputs makes it suitable for integration with emergency power systems, ensuring continuous monitoring during mains power interruptions.

Oil and gas processing plants utilize the 3500/05-01-02-00-00-01 to power 3500 monitoring systems on compressor skids and pump stations. The module’s rugged design withstands the harsh environmental conditions of processing facilities, while its comprehensive protection features safeguard against power surges common in industrial electrical systems. When integrated with expansion modules like the 136719-01 through system gateways, it ensures consistent power delivery across extended monitoring networks.

Manufacturing facilities deploy the 3500/05-01-02-00-00-01 in 3500 systems monitoring critical production machinery such as large motors, gearboxes, and precision manufacturing equipment. The module’s stable voltage outputs ensure accurate data collection from vibration and position sensors, while its compact design allows installation in space-constrained control cabinets. Its compatibility with various input power sources simplifies integration into diverse factory electrical systems.

BENTLY 3500/05-01-02-00-00-01

Related model recommendations

3500/20 (Bently Nevada): System rack that houses the 3500/05-01-02-00-00-01 power supply.

3500/15 (Bently Nevada): Monitor module powered by the 3500/05-01-02-00-00-01.

3500/33 (Bently Nevada): Communication module receiving power from the 3500/05 series.

136719-01 (Bently Nevada): Expansion module compatible with systems using 3500/05-01-02-00-00-01 via integration gateways.

330180-90-05 (Bently Nevada): Proximity sensor whose monitoring system relies on 3500/05 power.

3500/09 (Bently Nevada): Redundant power supply adapter for 3500/05 systems requiring redundancy.

125800-01 (Bently Nevada): Complementary power supply for auxiliary components in mixed systems.

3500/42 (Bently Nevada): Display module powered by the 3500/05-01-02-00-00-01.

Installation, commissioning and maintenance instructions

Installation preparation: Before installing the 3500/05-01-02-00-00-01, verify that the 3500/20 rack is properly grounded and that input power matches the facility’s supply (AC or DC). Ensure the installation environment is within the 0°C to +60°C operating temperature range with adequate ventilation. Required tools include a screwdriver set, torque wrench, multimeter, and insulated tools for power connections. Inspect the module for shipping damage, checking for loose components, damaged connectors, or visible signs of stress.

Mounting and wiring: Insert the 3500/05-01-02-00-00-01 into the designated power supply slot in the 3500/20 rack, securing it with the front panel screws to the specified torque. Connect input power wiring following proper electrical safety protocols, ensuring correct phase and ground connections according to the wiring diagram. For AC input, connect to L1, L2, and ground terminals; for DC input, connect to positive, negative, and ground terminals. Verify all connections before applying power.

Commissioning procedures: After wiring, perform a visual inspection of all connections before applying power. Energize the input power and verify the module’s status indicators show normal operation. Use a calibrated multimeter to check all output voltages (5 VDC, ±15 VDC, 24 VDC) at the rack’s backplane connectors, ensuring they fall within specified tolerances. Power up the entire 3500 system and confirm all modules receive proper power and initialize correctly. Document all voltage measurements as part of the commissioning record.

Maintenance suggestions: Conduct quarterly visual inspections of the 3500/05-01-02-00-00-01 to check for dust accumulation, loose connections, or signs of overheating (discoloration, unusual odors). Monitor output voltages periodically using a multimeter to ensure they remain within regulation limits. Clean ventilation openings as needed to maintain proper airflow. In systems with redundant power supplies, test failover functionality annually by temporarily disconnecting the primary supply and verifying seamless transition. During scheduled maintenance, inspect input wiring for signs of corrosion or overheating and retorque connections if necessary.

Service and guarantee commitment

Bently Nevada provides the 3500/05-01-02-00-00-01 with a 36-month warranty covering manufacturing defects and component failures under normal operating conditions. Our technical support team offers expert guidance on proper installation, wiring, and integration with 3500 series components and compatible expansion modules like the 136719-01.

We offer specialized training on 3500 system power requirements, redundancy implementation, and power supply maintenance best practices for the 3500/05-01-02-00-00-01. Beyond the warranty period, our service agreements include preventive maintenance checks, performance testing, and expedited replacement services to minimize downtime. Bently Nevada’s commitment to quality ensures the 3500/05-01-02-00-00-01 delivers stable, reliable power throughout its operational lifecycle, backed by our global network of service professionals.
