BENTLY 3500/22M 138607-01

Product introduction

The 3500/22M 138607-01 from Bently Nevada is a compact transient data module designed for the 3500 Machinery Protection System, specializing in capturing time-critical vibration and position data during machinery events. This 1-slot rack-mounted module serves as a flexible solution for monitoring transient conditions in mid-sized machinery protection applications, offering a balance of performance and space efficiency within the 3500 system architecture.

As a complementary model to the higher-channel 3500/22M 288055-01, 3500/22M 138607-01 provides targeted transient data capture for applications requiring fewer channels but maintaining the same core functionality. It seamlessly integrates with sensors connected via cables like 177230-01-01-05, preserving critical signal integrity needed for accurate diagnostic analysis of machinery behavior during startups, shutdowns, or fault events.

In industrial monitoring ecosystems, 3500/22M 138607-01 plays a vital role in capturing pre- and post-event data that reveals the root cause of machinery issues. Its ability to record transient waveforms helps engineers distinguish between normal operational variations and early fault indicators, supporting proactive maintenance strategies that minimize downtime in power generation, manufacturing, and oil and gas facilities.

Core advantages and technical highlights

Optimized channel configuration: 3500/22M 138607-01 offers 8 simultaneous input channels with sampling rates up to 64,000 samples per second, providing an ideal balance of performance and resource utilization for medium-complexity machinery. This configuration delivers sufficient resolution to capture critical transient details from sensors connected via 177230-01-01-05 cables while occupying only one rack slot, maximizing monitoring capability in space-constrained enclosures compared to larger modules like 3500/22M 288055-01.

Flexible triggering system: The module features a comprehensive triggering system that includes alarm-based triggers from other 3500 modules, external voltage triggers, manual activation, and scheduled captures. Pre-trigger buffering (configurable up to 10 seconds) ensures data from before the trigger event is preserved, providing essential context for understanding event initiation, while adjustable post-trigger recording captures the full event evolution.

Efficient data management: With 4 GB onboard flash memory and SD card expansion capability, 3500/22M 138607-01 provides ample storage for hours of high-resolution transient data. The module employs intelligent data prioritization that protects critical event recordings even when storage capacity is limited, ensuring valuable diagnostic information isn’t lost. Data is stored in open formats compatible with Bently Nevada diagnostic software and third-party analysis tools.

Seamless system integration: Designed for the 3500 architecture, 3500/22M 138607-01 communicates via the system backplane with other modules, maintaining precise timing synchronization across the entire monitoring system. It works alongside 3500/22M 288055-01 in larger installations, allowing scalable transient monitoring from 8 to 24+ channels. Ethernet connectivity enables remote configuration and data retrieval, supporting centralized analysis of machinery events.

Typical application scenarios

In biomass power plants, 3500/22M 138607-01 modules monitor boiler feed pumps, capturing transient vibration data during startup sequences and load changes. The 8-channel configuration provides dedicated monitoring of pump bearings and motor vibration via 177230-01-01-05 cables, recording how equipment responds to fuel quality variations. This data helps engineers optimize maintenance intervals for these critical auxiliary systems, preventing unplanned outages in renewable energy facilities.

Chemical processing plants utilize 3500/22M 138607-01 to monitor centrifugal pumps handling corrosive fluids, capturing transient data during cavitation events or valve transitions. The module’s rapid sampling preserves the unique vibration signatures of cavitation, enabling operators to adjust process parameters before pump damage occurs. Its compact 1-slot design fits easily in control cabinets alongside other 3500 modules, providing comprehensive protection for medium-sized rotating equipment.

Water treatment facilities employ 3500/22M 138607-01 to monitor large motor-driven agitators and mixers, capturing transient vibration patterns during startup and shutdown cycles. The module triggers on abnormal vibration spikes, recording data that helps distinguish between normal mechanical looseness and serious issues like bearing degradation. This targeted monitoring ensures reliable operation of equipment critical for water purification processes and distribution systems.

BENTLY 3500/22M 138607-01

Related model recommendations

3500/22M 288055-01: Higher-channel transient module compatible with this model in scalable systems.

177230-01-01-05: Extension cable transmitting sensor signals to 3500/22M 138607-01.

3500/15 127610-01: Power supply module providing regulated power to this transient recorder.

3500/40M 140734-01: Vibration monitor whose alarms trigger data capture in this module.

3500/62-04-02: Display module used to configure and view data from 3500/22M 138607-01.

330106-05-30-10-02-00: Proximity probe system whose signals are captured by this module.

3500/05-01-01-00-00-01: Communication module enabling remote access to captured data.

3500/72M: Temperature monitor whose data correlates with this module’s transient recordings.

Installation, commissioning and maintenance instructions

Installation preparation: Before installing 3500/22M 138607-01, ensure the 3500 rack has an available slot and a properly sized 3500/15 127610-01 power supply. Verify rack backplane compatibility with the module firmware version to ensure proper communication. Prepare shielded Ethernet cabling for remote access, routing cables away from high-voltage lines to minimize interference. Confirm the installation environment maintains temperatures within 0°C to +60°C with adequate ventilation for heat dissipation during high-speed data capture.

Maintenance suggestions: Include 3500/22M 138607-01 in quarterly system inspections, checking storage status and archiving critical data to external systems. Inspect backplane and Ethernet connections for corrosion or 松动 (loosening), cleaning contacts with approved electronic cleaner if needed. Test trigger functionality monthly using manual activation to ensure proper data capture. Update firmware during scheduled maintenance to maintain compatibility with other 3500 components like 3500/22M 288055-01. If data capture issues occur, verify signal integrity from connected sensors via 177230-01-01-05 cables before troubleshooting the module itself.

Service and guarantee commitment

Bently Nevada provides the 3500/22M 138607-01 with a 36-month warranty covering manufacturing defects and performance issues under normal operating conditions, including data capture accuracy, trigger reliability, and communication functionality when integrated with compatible 3500 series components. Our technical support team offers expert guidance on configuration, trigger setup, and data analysis specific to this transient module.

We offer specialized training on maximizing the diagnostic value of transient data captured by 3500/22M 138607-01, including integration strategies with modules like 3500/22M 288055-01 in larger systems. Beyond the warranty period, our service agreements include technical support, firmware updates, and calibration verification services. Bently Nevada’s commitment to quality ensures reliable performance throughout the module’s operational lifecycle, backed by our global network of service professionals dedicated to protecting your critical machinery assets.
