Bently Nevada 3500/15-04-00-01 133292-01 | Power Supply Module & 3500 Monitoring System

  • Model: 3500/15-04-00-01 133292-01
  • Alt. P/N: 3500/15-04-00-01 (base config), 133292-01 (firmware/redundancy variant)
  • Series: 3500 Monitoring System (Machinery Protection Framework)
  • Type: Power Supply Module (AC/DC Converter)
  • Key Feature: Dual AC inputs (120/240V), 24V DC output (150W), 1:1 redundant configuration, hot-swappable
  • Primary Use: Providing stable 24V DC power to 3500 monitoring system racks (monitors, communication modules, etc.)
Get a Quote
Manufacturer:

Our extensive catalogue, including , is available now for dispatch to the worldwide.

Description

Key Technical Specifications​
  • Model Number: 3500/15-04-00-01 133292-01
  • Manufacturer: Bently Nevada (Baker Hughes)
  • Input Voltage: 120/240V AC (±10%, 50/60Hz, auto-ranging)
  • Output Voltage: 24V DC (±5% regulation, 150W continuous)
  • Efficiency: 85% typical (at 240V AC input)
  • Redundancy: 1:1 (supports parallel operation with identical module for failover)
  • Power Factor Correction: Active (≥0.95 at full load)
  • Operating Temperature: 0°C to +65°C (rack-mounted, with derating above +50°C)
  • Storage Temperature: -40°C to +85°C
  • Cooling: Convection (no fan; relies on rack airflow)
  • Electrical Isolation: 3000Vrms (input-to-output, per IEC 60664-1)
  • Dimensions: 119mm x 25mm x 102mm (WxHxD, 3500 half-height slot)
  • Weight: 0.20kgBently Nevada 3500/15-04-00-01 133292-01
Field Application & Problem Solved​
In the field, the 3500 Monitoring System is the backbone of machinery protection—but it’s useless without reliable power. I’ve seen too many plants lose protection because a single power supply failed, or worse, a cheap replacement couldn’t handle voltage sags in a refinery. This module solves that with industrial-grade stability: dual AC inputs (120/240V auto-ranging) handle unstable grids, 150W output powers a full 3500 rack (monitors, comms, keyphasors), and 1:1 redundancy means if one module fails, the other takes over without dropping a single alarm. You’ll find it in power plants feeding turbine protection racks, chemical plants powering compressor monitors, or offshore platforms where salt air demands corrosion-resistant design. Its core value is uptime: convection cooling avoids fan failures (common in dusty mills), and 85% efficiency cuts heat buildup. For example, in a Gulf Coast refinery, it survived three 240V spikes in a month—thanks to active PFC and overvoltage protection—while the old module would have fried.
Installation & Maintenance Pitfalls (Expert Tips)​
  • Incorrect Input Voltage Setting: Rookies leave the input jumper at 120V in a 240V plant (or vice versa). The 3500/15 auto-ranges, but mismatched jumpers can cause voltage division errors. Verify with a multimeter beforeplugging in—check the label on the terminal block.
  • Skipping Redundancy Testing: Just installing two modules isn’t enough. Simulate a failure: pull the primary module’s power cord while watching the 3500 rack LEDs. The secondary should take over in <100ms—if not, check the “parallel” dip switch (often overlooked).
  • Ignoring Rack Airflow: No fan means it relies on rack ventilation. In a crowded cabinet, blocked vents cause thermal shutdown (above +65°C). Leave 2-inch clearance above/below, and clean dust quarterly—especially in paper mills.
  • Loose Terminal Screws: Vibration from nearby pumps loosens input/output screws, causing intermittent power drops. Torque to 8 in-lbs (0.9 Nm) and use lock washers. I’ve fixed 3 “random” trips this year by tightening these.
  • Outdated Firmware Risks: The 133292-01 firmware fixes a rare “brownout recovery” bug (v4.8 and earlier). If your plant has frequent voltage sags, update via Bently Update Manager—unpatched modules may not restart automatically.

    Bently Nevada 3500/15-04-00-01 133292-01

    Bently Nevada 3500/15-04-00-01 133292-01

Technical Deep Dive & Overview​
The 3500/15-04-00-01 133292-01 is a half-height power supply module for Bently’s 3500 Machinery Protection System. It’s the “heart” of the rack: converting 120/240V AC to stable 24V DC for all 3500 modules (monitors, keyphasors, comms). Inside, it uses a switched-mode power supply (SMPS) with active PFC to boost efficiency (85%) and meet global voltage standards. The 1:1 redundancy feature lets two modules share the load; if one fails (detected via current monitoring), the other ramps up seamlessly. No fan means it’s silent and avoids dust-clogging failures—critical in food plants or mines. It mounts in any 3500 half-height slot, drawing power from the grid and feeding the backplane. The 133292-01 variant adds better brownout handling (survives 80V dips for 10ms) and enhanced LED diagnostics (flashing codes for overtemp, overload). In short, it’s the unsung hero keeping your 3500 system alive—simple, rugged, and built to outlast the machines it protects.
