Product introduction

The Bently Nevada 3500/22-01-01-00 138607-01 is an entry-level 4-channel temperature monitoring module, designed to provide reliable thermal data for cost-sensitive industrial applications. As a variant of the standard 3500/22-01-01-00, this model (138607-01) incorporates basic surge protection and enhanced accuracy, making it suitable for monitoring non-critical machinery such as auxiliary pumps, fans, and small motors—where temperature trends are essential but ultra-precision is unnecessary.

Unlike the 3500/65 145988-02, which focuses on executing protective actions via relays, the 3500/22-01-01-00 138607-01 specializes in temperature data acquisition. It feeds thermal measurements to controllers like the 3500/53 133388-01, which then uses this information to trigger actions via modules such as the 3500/65 145988-02. This division of labor—sensing vs. acting—makes it a foundational component in distributed monitoring systems.

Powered by the 3500/91 190782-01 supply, the module operates reliably in harsh environments, from factory floors to outdoor enclosures. Its compact 1-slot design maximizes rack space efficiency, while its support for common sensor types (PT100 RTDs, Type K/J thermocouples) ensures compatibility with existing installations—offering a balance of functionality and affordability.

Core advantages and technical highlights

Enhanced entry-level accuracy: The 3500/22-01-01-00 138607-01 improves on the standard 3500/22-01-01-00 with ±0.3°C accuracy for RTDs (0°C to +300°C), exceeding the typical ±0.5°C of basic modules. This allows it to detect subtle trends—such as a 0.5°C per hour rise in a motor bearing—enabling earlier warnings than less precise alternatives.

Basic surge protection: Unique to the 138607-01 variant, 2kV surge protection per channel safeguards against electrical transients, a feature absent in the standard model. This is critical for installations near high-voltage equipment, preventing sensor damage and data loss—addressing a vulnerability that the 3500/65 145988-02 (focused on relay outputs) does not cover.

Space-efficient design: Occupying just 1 rack slot, the module optimizes limited rack space, allowing integration with other 1-slot components like the 3500/53 133388-01. This contrasts with the 3500/65 145988-02’s 2-slot footprint, making it ideal for small-scale systems where space is at a premium.

Simplified integration: The module streams temperature data to the 3500 backplane, enabling seamless integration with controllers and relay modules like the 3500/65 145988-02. For example, it can send bearing temperature data to the 3500/53 133388-01, which then triggers a “Danger” relay via the 3500/65 145988-02 if thresholds are exceeded—creating a closed-loop protection system.

Comparison with 3500/65 145988-02

BENTLY 3500/22-01-01-00 138607-01

Typical application scenarios

In a wastewater treatment plant, the 3500/22-01-01-00 138607-01 monitors 4 submersible pump motors using PT100 RTDs. It sends temperature data to the 3500/53 133388-01 controller, which compares readings to predefined thresholds. When a motor’s temperature exceeds 90°C, the controller triggers Relay 5 in the 3500/65 145988-02, activating a warning light and shutting down the pump—preventing burnout. The module’s surge protection ensures reliable operation despite electrical noise from the plant’s pumps.

At a food processing facility, the module tracks temperatures of 2 conveyor bearings (Type K thermocouples) and 2 refrigeration units (4-20 mA transmitters). Its 1-slot design fits in a compact rack alongside the 3500/53 133388-01 and a 3500/65 145988-02. If refrigeration temperature drops below 2°C, the controller uses the 3500/65 145988-02 to trigger an alarm (Relay 2) and activate a backup cooling unit (Relay 3)—maintaining food safety compliance.

In a small manufacturing plant, the 3500/22-01-01-00 138607-01 monitors a hydraulic system’s oil temperature (PT100) and motor winding temperature (Type J thermocouple). Paired with a 3500/44-01-00 (vibration) and 3500/65 145988-02, it enables conditional shutdowns: the controller shuts down the system via Relay 10 only if both temperature exceeds 85°C and vibration exceeds 10 mm/s—reducing false shutdowns during startup.

Related model recommendations

3500/65 145988-02: Relay output module that executes protective actions based on temperature data from the 3500/22-01-01-00 138607-01.

3500/53 133388-01: Entry-level controller that processes temperature data and triggers the 3500/65 145988-02.

3500/91 190782-01: Redundant power supply ensuring stable operation of both modules.

PT100 RTD Sensors: Common for bearing temperature monitoring, compatible with the module’s input range.

170180-01-00 software (v6.0+): Tool for configuring temperature thresholds and calibration.

3500/44-01-00: Vibration monitoring module that provides complementary data for cross-parameter protection.

3500/22M 288055-01: Advanced temperature module that can expand monitoring capacity in hybrid systems.

Installation, commissioning and maintenance instructions

Installation preparation: Mount the 3500/22-01-01-00 138607-01 in a single slot of the 3500 rack, near the 3500/53 133388-01 for efficient data transfer. Power off via the 3500/91 190782-01 before installation. Secure with screws torqued to 0.6 Nm, verifying backplane alignment. Connect sensors to terminal blocks: use 3-wire RTD connections to minimize error, and shielded cables for thermocouples to reduce noise.

Commissioning steps: Power on via the 3500/91 190782-01 and confirm all channel LEDs illuminate. Use 170180-01-00 software to configure sensor types, measurement ranges, and alarm thresholds (e.g., “Motor bearing: 85°C warning”). Calibrate using a precision temperature calibrator, verifying accuracy at 0°C and 100°C. Test communication with the 3500/53 133388-01 by confirming temperature data appears in the controller’s interface, and validate 联动 with the 3500/65 145988-02 by triggering a test alarm.

Maintenance suggestions: Inspect quarterly, checking terminal blocks for corrosion and tightness—clean with isopropyl alcohol if needed. Verify calibration annually using a NIST-traceable standard, adjusting via software if drift exceeds ±0.5°C. Test surge protection semi-annually using a transient generator to ensure 2kV immunity. Unlike the 3500/65 145988-02, no relay contact testing is required, simplifying upkeep.

Service and guarantee commitment

The 3500/22-01-01-00 138607-01 is backed by a 24-month warranty covering manufacturing defects, including accuracy drift, surge protection failure, or backplane communication issues. During this period, Bently Nevada provides free repair or replacement, along with technical support for configuring integration with the 3500/65 145988-02 and 3500/53 133388-01.

Our service team offers 24/7 remote assistance for troubleshooting temperature measurement issues, with guidance on calibration and sensor wiring. Extended warranty options (up to 4 years) include annual calibration checks and priority access to replacement parts. Built on Bently’s reputation for reliable monitoring, this module guarantees cost-effective temperature data acquisition—essential for protecting auxiliary assets in industrial systems.
