EMERSON EC10-2416BRA | Industrial DIN Rail Power Supply

  • Brand:​ Emerson
  • •
    Model:​ EC10-2416BRA
  • •
    Product Type:​ DIN Rail Mount Switching Power Supply
  • •
    Series:​ EC10 Series
  • •
    Core Function:​ Converts AC mains voltage (100-240V AC) to a regulated 24V DC output to power control systems, PLCs, sensors, and other industrial electronics.
  • •
    Key Specs:​ 24V DC Output, 10A, 240W, Wide-range AC input, DIN Rail mount.
Get a Quote
Manufacturer:
Part number: EMERSON EC10-2416BRA
Our extensive catalogue, including : EMERSON EC10-2416BRA , is available now for dispatch to the worldwide.
  • Full 12-month warranty
  • Available for dispatch immediately
  • We deliver worldwide

Description

EC10-2416BRA: Product Overview
The EMERSON EC10-2416BRA is a compact, high-efficiency switching power supply designed for industrial control applications. This unit functions as the primary DC power source for a wide range of equipment, including Programmable Logic Controllers (PLCs), relays, sensors, actuators, and other low-voltage devices within an enclosure. Its primary role is to take a potentially unstable AC mains voltage and convert it into a clean, stable, and regulated 24V DC output, ensuring the reliable operation of sensitive electronic control systems.
Installed on a standard TS35 DIN rail inside a control panel, the power supply features a wide input voltage range, allowing it to operate reliably despite fluctuations in the mains supply. The robust metal housing provides mechanical protection and aids in heat dissipation. It is engineered for high efficiency, which minimizes heat generation and energy loss, contributing to lower operating costs and increased system reliability. The design includes protection against overcurrent, overvoltage, and short circuits, safeguarding both the power supply itself and the connected load.

EMERSON EC10-2416BRA

EMERSON EC10-2416BRA

EC10-2416BRA: Technical Specifications
  • •
    Model Number:​ EC10-2416BRA
  • •
    Manufacturer:​ Emerson
  • •
    Product Type:​ DIN Rail Mount Switching Power Supply
  • •
    Input Voltage:​ 100 – 240 VAC, 50/60 Hz (Auto-ranging)
  • •
    Output Voltage:​ 24 VDC
  • •
    Output Current:​ 10 A
  • •
    Output Power:​ 240 W
  • •
    Efficiency:​ >89% (typical)
  • •
    Line Regulation:​ ±1%
  • •
    Load Regulation:​ ±1%
  • •
    Ripple & Noise:​ <150 mV peak-to-peak
  • •
    Mounting:​ Standard TS35 DIN Rail
  • •
    Operating Temperature:​ -25°C to +70°C (with derating above 50°C)
  • •
    Cooling:​ Convection cooling (fanless)
  • •
    Protections:
    • •
      Overload Protection (Auto-recovery)
    • •
      Overvoltage Protection
    • •
      Short-Circuit Protection
  • •
    Safety Standards:​ UL 508, CSA C22.2 No. 107.1, CE
  • •
    EMC:​ Complies with EN 55011, EN 61000-6-2, EN 61000-6-4

    EMERSON EC10-2416BRA

    EMERSON EC10-2416BRA

Core Features & Customer Value
The primary value of this power supply is its high reliability and robust design​ in a compact form factor. For system integrators, the wide input voltage range (100-240V AC) means the same unit can be deployed globally without modification, simplifying inventory. The high efficiency​ reduces energy consumption and heat buildup inside the control panel, which can lower cooling requirements and increase the lifespan of all components.
The fanless (convection) cooling​ ensures silent operation and higher reliability by eliminating a common mechanical failure point (the fan). Comprehensive protection features​ (overload, overvoltage, short-circuit) enhance the overall robustness of the control system, preventing downtime due to power issues. The DIN rail mounting makes installation and maintenance quick and easy within a standardized enclosure.
Typical Applications
  • •
    Industrial Control Panels:​ Providing 24V DC power to PLCs, I/O modules, contactors, and relays in automated machinery.
  • •
    Process Automation Systems:​ Powering sensors, transmitters, and valve positioners in a Distributed Control System (DCS).
  • •
    Telecommunications:​ Powering equipment in industrial networking and telecom cabinets.
