• Core Function: Serves as the central processing unit for Emerson’s DeltaV Distributed Control System (DCS), executing control logic for process automation.
Manufacturer: Emerson Part number: EMERSON KJ1710X1-BA1
Our extensive Emerson catalogue, including
: EMERSON KJ1710X1-BA1
, is available now for dispatch to the worldwide.
KJ1710X1-BA1: Product OverviewThe EMERSON KJ1710X1-BA1 is a central controller module for Emerson’s DeltaV™ Distributed Control System (DCS), a platform renowned for its use in process automation across industries such as chemical, pharmaceutical, oil & gas, and power generation. This controller acts as the computational brain of a DeltaV station, responsible for executing complex control strategies including continuous regulatory control, batch sequencing, and advanced process optimization algorithms. It interfaces with I/O modules—particularly the innovative CHARM (Characterization Module) I/O cards—via a high-speed backplane to read process data from field instruments and execute control commands to final control elements.The controller is designed for the Electronic Marshalling architecture, which eliminates traditional marshalling cabinets and reduces wiring by allowing any I/O type (e.g., AI, AO, DI, DO) to be assigned to any channel on a CHARM I/O card via software configuration. This provides tremendous flexibility and significantly reduces installation and commissioning time. The controller runs the DeltaV real-time operating system and application code, providing deterministic performance essential for precise process control in demanding industrial environments.
EMERSON KJ1710X1-BA1
KJ1710X1-BA1: Technical Specifications
• Model Number: KJ1710X1-BA1
• Manufacturer: Emerson
• Product Type: Process Controller (CPU)
• Compatible System: DeltaV DCS with CHARM I/O
• Processor: High-performance processor
• Memory: Extensive application memory with battery backup
• I/O Communication: Interfaces with CHARM I/O bases via a high-speed backplane
• Network Communication:
• DeltaV Network: Ethernet for communication with operator stations and other controllers.
• Plant Network: Optional interface for integration with higher-level systems.
• Redundancy: Supports 1:1 hot-standby redundancy (requires a second controller)
• Power Supply: Powered by the DeltaV power supply module in the chassis
• Operating Temperature: 0°C to 60°C (32°F to 140°F)
• Certifications: cULus, ATEX, IECEx for hazardous locations
• Security Features: User authentication, audit trails, communication encryption
EMERSON KJ1710X1-BA1
Core Features & Customer ValueThe primary value of this controller is its role in the DeltaV Electronic Marshalling system, which drastically reduces wiring, engineering, and commissioning costs. For system integrators, this means unparalleled flexibility—field signals can be changed or added late in the project without rewiring, simply by reconfiguring the software. This de-risks projects and accelerates startup timelines significantly.The controller’s high-performance processor ensures fast and deterministic execution of complex control algorithms, which is critical for maintaining product quality, safety, and efficiency in continuous processes. Support for hot-standby redundancy guarantees high availability for critical applications, with automatic failover preventing unplanned downtime. The integration with the broader DeltaV ecosystem provides advanced features like built-in diagnostics, cybersecurity protocols, and seamless data exchange for plant-wide optimization.Typical ApplicationsIn a pharmaceutical batch process, the KJ1710X1-BA1 executes complex recipes, managing precise sequences for charging reactants, controlling temperature and pressure in reactors, and ensuring compliance with regulatory standards (e.g., FDA 21 CFR Part 11).In a continuous chemical process, it performs regulatory control for distillation columns or reactors, executing advanced control strategies to maximize yield and energy efficiency while ensuring safe operation within design limits.
