EMERSON KJ2201X1-PW1 | DCS Power Supply Unit

  • Brand:​ Emerson
  • •
    Model:​ KJ2201X1-PW1
  • •
    Product Type:​ Power Supply Module
  • •
    Series:​ DeltaV™ S-series
  • •
    Core Function:​ Provides regulated DC power to DeltaV controller chassis and I/O modules, ensuring continuous system operation.
  • •
    Key Specs:​ Hot-swappable, redundant configuration, wide input voltage range.
Get a Quote
Manufacturer:
Part number: EMERSON KJ2201X1-PW1
Our extensive catalogue, including : EMERSON KJ2201X1-PW1 , is available now for dispatch to the worldwide.
  • Full 12-month warranty
  • Available for dispatch immediately
  • We deliver worldwide

Description

KJ2201X1-PW1: Product Overview
The EMERSON KJ2201X1-PW1 is a power supply module designed for Emerson’s DeltaV™ S-series Distributed Control System (DCS). This module serves as the primary power source for DeltaV controller chassis and I/O modules, converting AC mains voltage to regulated DC power required for system operation. Installed in a DeltaV power supply slot, its primary function is to provide clean, stable power to all system components while supporting hot-swap replacement and redundant configuration for maximum system availability.
The power supply features advanced monitoring and diagnostics capabilities, communicating its status to the DeltaV system for proactive maintenance. The robust design ensures reliable operation in industrial environments, with protection against over-voltage, over-current, and over-temperature conditions. The module’s hot-swap capability allows for replacement without system shutdown when used in redundant pairs.

Emerson SLS1508

Emerson SLS1508

KJ2201X1-PW1: Technical Specifications
  • •
    Model Number:​ KJ2201X1-PW1
  • •
    Manufacturer:​ Emerson
  • •
    Product Type:​ Power Supply Module
  • •
    Input Voltage:​ 100-240 VAC, 50/60 Hz (auto-ranging)
  • •
    Output Voltage:​ +5 VDC, +24 VDC (regulated)
  • •
    Output Power:​ 500-600W (typical)
  • •
    Efficiency:​ >85% (typical)
  • •
    Redundancy:​ Supports N+1 redundant configuration
  • •
    Hot-Swap:​ Yes (when used in redundant configuration)
  • •
    Cooling:​ Internal fan with speed control
  • •
    Protection:​ Over-voltage, over-current, over-temperature protection
  • •
    Status Indicators:​ LED indicators for power, fault, and status
  • •
    Communication:​ System status reporting via backplane
  • •
    Operating Temperature:​ 0°C to 60°C (32°F to 140°F)
  • •
    Safety Standards:​ UL, cUL, CE, ATEX

    Emerson SLS1508

    Emerson SLS1508

Core Features & Customer Value
The primary value of the KJ2201X1-PW1 is its high reliability and redundancy support, which ensures continuous system operation critical for process automation. The hot-swap capability​ allows for maintenance and replacement without system downtime, significantly improving overall system availability. The wide input voltage range​ (100-240 VAC) provides flexibility for global deployment and stable operation during voltage fluctuations.
The power supply’s advanced diagnostics and status monitoring​ enable predictive maintenance, reducing unexpected failures. The high efficiency rating​ minimizes energy consumption and heat generation, contributing to lower operating costs and improved system longevity. For system integrators, the modular design simplifies installation and maintenance while ensuring compatibility with the DeltaV ecosystem.
Typical Applications
  • •
    Providing primary power to DeltaV controller stations in continuous process plants
  • •
    Supporting redundant power configurations in critical control applications
  • •
    Powering I/O modules in distributed field enclosures
