EMERSON KJ4001X1-CA1 | DeltaV Controller Module

  • Brand:​ Emerson
  • •
    Model:​ KJ4001X1-CA1
  • •
    Product Type:​ Process Controller (CPU Module)
  • •
    Series:​ DeltaV™ S-series
  • •
    Core Function:​ Serves as the central processing unit for Emerson’s DeltaV Distributed Control System (DCS), executing regulatory control, logic, and sequencing functions for process automation.
  • •
    Key Specs:​ High-performance processor, supports Electronic Marshalling (CHARMs), redundant configuration support.
Get a Quote
Manufacturer:

Our extensive catalogue, including , is available now for dispatch to the worldwide.
  • Full 12-month warranty
  • Available for dispatch immediately
  • We deliver worldwide

Description

KJ4001X1-CA1: Product Overview
The EMERSON KJ4001X1-CA1 is a central controller module for Emerson’s DeltaV™ S-series Distributed Control System (DCS). This controller acts as the computational brain of a DeltaV station, responsible for executing complex control strategies including continuous regulatory control, batch sequencing, and advanced process optimization algorithms. It interfaces with I/O modules—particularly the innovative CHARM (Characterization Module) I/O cards—via a high-speed backplane to read process data from field instruments and execute control commands to final control elements.
The controller is designed specifically for the DeltaV Electronic Marshalling architecture, which eliminates traditional marshalling cabinets and reduces wiring by allowing any I/O type (e.g., AI, AO, DI, DO) to be assigned to any channel on a CHARM I/O card through software configuration. This provides unprecedented flexibility and significantly reduces installation and commissioning time. The controller runs the DeltaV real-time operating system and application code, providing deterministic performance essential for precise process control in demanding industrial environments.

EMERSON KJ4001X1-CA1

EMERSON KJ4001X1-CA1

KJ4001X1-CA1: Technical Specifications
  • •
    Model Number:​ KJ4001X1-CA1
  • •
    Manufacturer:​ Emerson
  • •
    Product Type:​ Process Controller (CPU)
  • •
    Compatible System:​ DeltaV S-series with CHARM I/O
  • •
    Processor:​ High-performance multicore processor
  • •
    Memory:​ Extensive application memory with battery backup
  • •
    I/O Communication:​ Interfaces with CHARM I/O bases via high-speed backplane
  • •
    Network Communication:
    • •
      DeltaV Network:​ Ethernet for communication with operator stations
    • •
      Plant Network:​ Optional interface for higher-level system integration
  • •
    Redundancy:​ Supports 1:1 hot-standby redundancy
  • •
    Power Supply:​ Powered by DeltaV power supply module in chassis
  • •
    Operating Temperature:​ 0°C to 60°C (32°F to 140°F)
  • •
    Certifications:​ cULus, ATEX, IECEx for hazardous locations
  • •
    Security Features:​ User authentication, audit trails, communication encryption
Core Features & Customer Value
The primary value of the KJ4001X1-CA1 is its role in the DeltaV Electronic Marshalling system, which dramatically reduces wiring, engineering, and commissioning costs. For system integrators, this means unparalleled flexibility—field signals can be changed or added late in the project without rewiring, simply by reconfiguring the software. This de-risks projects and accelerates startup timelines significantly.
The controller’s high-performance processing capability​ ensures fast and deterministic execution of complex control algorithms, which is critical for maintaining product quality, safety, and efficiency in continuous processes. Support for hot-standby redundancy​ guarantees high availability for critical applications, with automatic failover preventing unplanned downtime. The integration with the broader DeltaV ecosystem provides advanced features like built-in diagnostics, cybersecurity protocols, and seamless data exchange for plant-wide optimization.
Typical Applications
In pharmaceutical manufacturing, the KJ4001X1-CA1 executes complex batch recipes, managing precise temperature and pressure profiles for reactor control while ensuring compliance with FDA 21 CFR Part 11 regulations.
In chemical processing plants, the controller performs advanced regulatory control for distillation columns and reactor systems, implementing model predictive control strategies to maximize yield and energy efficiency.
