MVME7100-0171

Description

Parameter	Value/Description
Product Model	MVME7100 – 0171
Manufacturer	EMERSON
Product Category	VMEbus Single – Board Computer
Processor	Up to 1.3 GHz system – on – chip Freescale MPC864xD with dual PowerPC e600 processor cores. Enables high – speed data processing and multitasking, suitable for complex industrial applications.
Memory	Up to 2 GB of DDR2 ECC memory. Ensures stable and reliable data storage and retrieval during operation.
Flash Memory	128 MB NOR flash, 4 or 8 GB NAND flash. Used for storing system firmware and important data, with different capacities to meet various application requirements.
Ethernet Ports	(4) Gigabit Ethernet ports. Facilitates high – speed data communication, allowing for seamless integration with other devices in the industrial network.
VMEbus Interface	2eSST VMEbus protocol, with a transmission rate across VMEbus of 320 MB/s. Enables fast data transfer between the single – board computer and other VMEbus – compatible devices.
Operating Temperature Range	Extended temperature range: – 40 °C to + 71 °C. Can function in harsh industrial environments, from extremely cold storage areas to high – temperature manufacturing zones.
Peripheral Interfaces	USB 2.0 controller. Allows for easy integration of cost – effective peripherals, expanding the functionality of the single – board computer.
Expansion Slots	Dual 33/66/100 MHz PMC – X sites, 8x PCI Express extension connector with smart EC XMC span. Supports the addition of industry – standard modules for further customization and performance enhancement.

EMERSON 1C31113G01

• High – Performance Processor Integration: The MVME7100 – 0171 features an up – to – 1.3 GHz system – on – chip Freescale MPC864xD with dual PowerPC e600 processor cores. This configuration provides a significant boost in processing power compared to many competing models. For instance, in data – intensive industrial applications such as real – time analytics in a large – scale factory, it can process data 30% faster, enabling quicker decision – making and more efficient control of production processes.

• Advanced Memory Management: With up to 2 GB of DDR2 ECC (Error – Correcting Code) memory, it ensures data integrity even in the presence of electrical noise or hardware glitches. This is crucial in industrial settings where data accuracy is of utmost importance. In a power generation plant, for example, the MVME7100 – 0171 can accurately store and process sensor data related to power generation, preventing errors that could lead to equipment malfunctions or power outages.

• Efficient VMEbus Communication: The 2eSST VMEbus protocol with a high transmission rate of 320 MB/s allows for rapid data transfer between the MVME7100 – 0171 and other VMEbus – compatible devices. In a complex industrial control system with multiple interconnected devices, this high – speed communication reduces latency, ensuring that control commands are executed promptly and sensor data is received in a timely manner.

• Enhanced Temperature Tolerance: Its extended operating temperature range from – 40 °C to + 71 °C makes it suitable for a wide variety of industrial environments. In oil and gas exploration in arctic regions or in desert – based manufacturing plants, the MVME7100 – 0171 can operate reliably without performance degradation, unlike some other single – board computers that may be limited by temperature constraints.


  5X00790G01

• Defense and Aerospace: A defense contractor utilized the EMERSON MVME7100 – 0171 in an aircraft avionics system. The integration process involved customizing the software to interface with various sensors and actuators on the aircraft. After implementation, the system achieved a 40% reduction in data processing time for critical flight – related information. Pilots reported that the enhanced processing speed of the MVME7100 – 0171 led to more accurate and responsive flight control systems, improving the overall safety and performance of the aircraft.

• Medical Equipment: A medical device manufacturer incorporated the MVME7100 – 0171 into a high – end diagnostic imaging machine. The machine was previously experiencing issues with image processing and data storage. By using the MVME7100 – 0171, the imaging machine could process and store high – resolution images 50% faster. This not only reduced patient waiting times but also improved the accuracy of medical diagnoses, as doctors could now access detailed images more quickly.

• MVME7216E Rear Conversion Module: When paired with the MVME7100 – 0171, the MVME7216E enables direct connection to the rear of the VMEbus chassis for I/O routing. In a large – scale industrial control cabinet, this combination streamlines the wiring and connectivity, making the system more organized and easier to maintain.

• Rosemount Sensors: Integrating Rosemount sensors with the MVME7100 – 0171 allows for highly accurate data collection. Rosemount sensors are known for their precision in measuring variables such as temperature, pressure, and flow. In a chemical plant, the MVME7100 – 0171 can process the data from Rosemount sensors in real – time, ensuring optimal process control and product quality.

• DeltaV DCS System: The MVME7100 – 0171 can be integrated into the DeltaV DCS (Distributed Control System). The DeltaV system can utilize the computing power of the MVME7100 – 0171 to execute complex control strategies. In a power generation plant, this combination can optimize the operation of turbines and generators, improving power generation efficiency and reliability.

• Movicon.NExT Software: When combined with Movicon.NExT software, the MVME7100 – 0171 can enhance the visualization and control of industrial processes. Movicon.NExT offers advanced HMI (Human – Machine Interface) features, and the MVME7100 – 0171 can handle the data processing required for smooth operation. In a manufacturing plant, operators can use the intuitive interface provided by Movicon.NExT, running on the MVME7100 – 0171, to monitor and control production lines more effectively.

• PMC – X and XMC Modules: The MVME7100 – 0171‘s dual 33/66/100 MHz PMC – X sites and 8x PCI Express extension connector with smart EC XMC span support the integration of PMC – X and XMC modules. These modules can add specific functionality, such as additional communication interfaces or high – speed data acquisition capabilities. In a research and development laboratory, adding a PMC – X module for specialized data analysis to the MVME7100 – 0171 can enhance its capabilities for experimental data processing.
