FOXBORO P0961CA

Description

Main Parameters	Value/Description
Product Model	P0961CA
Manufacturer	FOXBORO
Product Category	Fiber Optic LAN Module
Communication Interface	Standard fiber optic interface, compatible with single – mode or multi – mode fiber. Supports common connector types like LC/LC and LC/ST
Transmission Rate	Up to 100Mbps, enabling fast data transfer
Transmission Distance	In single – mode fiber, it can reach several kilometers. In multi – mode fiber, it can achieve hundreds of meters, depending on fiber specifications and environment
Network Protocols	Supports common industrial network protocols such as TCP/IP and Modbus TCP for easy integration with various devices and systems
Operating Voltage	24V DC (with an allowable deviation of ±10%)
Operating Temperature Range	– 20°C to +60°C, suitable for most industrial temperature fluctuations
Storage Temperature Range	– 40°C to +85°C, for harsh storage conditions
Relative Humidity	5% – 95% (non – condensing), adaptable to humid environments
Dimensions (L x W x H)	Approximately 38 cm x 19 cm x 8 cm, compact for easy installation in control cabinets
Weight	Approximately 2.0 kg
Protection Class	IP20, protecting against objects larger than 12 mm (like fingers) and providing basic dust protection
Certifications	Passed CE, UL, cUL, etc., meeting strict international safety and quality standards

FOXBORO P0916DC

• Innovation Point 1: Fiber Optic Technology

• Innovation Point 2: Multiple Protocol Support

• Innovation Point 3: Robust Industrial Design

From its hardware materials to its structural design, the P0961CA adheres to industrial – grade standards. The high – strength housing can withstand certain mechanical impacts and vibrations. The internal circuit is specially designed to have excellent anti – interference and stability, ensuring long – term reliable operation in the complex electromagnetic environment of industrial sites.

FOXBORO P0916FH

• FOXBORO FBM Series Modules: The P0961CA can work in tandem with FOXBORO’s FBM (Fieldbus Module) series. The FBM series is responsible for collecting and processing various signals from field devices, such as analog and digital signals. The P0961CA then transmits the processed data at high speed to other parts of the control system, facilitating the seamless transfer of data from the field to the control center.

• FOXBORO CP Series Controllers: When combined with FOXBORO’s CP (Control Processor) series controllers, the P0961CA provides a stable communication link for the controllers. The controllers execute control logic based on the data transmitted by the P0961CA, enabling precise control of industrial processes. For instance, in a chemical production process, the CP controller can adjust valve openings and pump speeds according to temperature and pressure data transmitted by the P0961CA.

• Fiber Optic Cables and Connectors: Matching fiber optic cables and connectors, such as single – mode or multi – mode fibers and LC/LC connectors, can be used with the P0961CA to build a complete fiber optic communication network. Different fiber optic cable specifications can be selected according to transmission distance and environmental requirements, optimizing the performance of the communication system.

• FOXBORO FCM Series: The P0961CA can cooperate with FOXBORO’s FCM (Fieldbus Communication Module) series. The FCM series manages communication with field devices, and the P0961CA helps in transmitting data between different parts of the network, enhancing the overall communication efficiency in the industrial control system.

• FOXBORO I/A Series Systems: As part of the FOXBORO I/A series systems, the P0961CA works in harmony with other components in the series. It contributes to the overall data communication and control functions, ensuring the smooth operation of the entire industrial automation system.
