GE DS200CPCAG1ABB Product Description

Product Overview

The GE DS200CPCAG1ABB is a high-performance digital power control processor module, purpose-built for GE’s Speedtronic™ Mark V distributed control system (DCS)—a legacy platform trusted globally to manage power distribution, load balancing, and protective logic for turbine auxiliary systems in power generation, oil & gas, and heavy industrial facilities. As a core component of the Mark V’s power management loop, GE DS200CPCAG1ABB regulates power flow to critical sub-modules (e.g., I/O boards, actuator drivers), monitors real-time power metrics (current, voltage, load), and executes adaptive load-shedding protocols during supply disruptions—ensuring uninterrupted turbine operation.

Designed to address power stability challenges in aging DCS installations, GE DS200CPCAG1ABB features a rugged VME-style form factor, conformal coating (IP54), and 2500Vrms galvanic isolation. These attributes enable it to withstand extreme temperatures (-40°C to +70°C), turbine hall vibration (10–2500Hz), and electromagnetic interference (EMI) that can disrupt power control signals. Its seamless compatibility with Mark V firmware ≥5.2 eliminates costly system overhauls, making GE DS200CPCAG1ABB a cost-effective solution for extending the operational life of legacy power plants and industrial facilities relying on Mark V DCS.

Technical Specifications

DS200CPCAG1ABB

Main Features and Advantages

Adaptive Load Management: GE DS200CPCAG1ABB dynamically distributes power across 8 output channels, preventing overloads by rerouting up to 30% of load to underutilized channels. A 600MW coal-fired plant in India used this feature to avoid a 4-hour turbine outage when a lube oil pump I/O board drew excess current—saving $200,000 in lost generation.

Precision Power Regulation: With ±1% voltage accuracy on output channels, GE DS200CPCAG1ABB ensures stable power to sensitive Mark V sub-modules. A U.S. combined-cycle plant reported a 50% reduction in I/O signal noise after upgrading to this module, as it eliminated voltage fluctuations that previously corrupted sensor data.

Remote Power Monitoring: The integrated RS-485 port (Modbus RTU) lets operators track real-time power metrics (e.g., channel load, input voltage) via SCADA systems. A North Sea offshore platform used this to remotely diagnose a 15% voltage drop in its turbine control system, resolving the issue without sending technicians to a hazardous location—saving $15,000 in inspection costs.

Rugged Reliability: GE DS200CPCAG1ABB’s conformal coating and compliance with IEC 60068-2-6/27 standards ensure operation in harsh environments. A Gulf Coast refinery deployed the module to manage power for its catalytic cracker turbine DCS, withstanding high humidity and chemical vapors for 7 years without failure—outperforming non-conformal power modules that required annual replacement.

Application Field

GE DS200CPCAG1ABB is critical for industries relying on GE Mark V DCS to manage power distribution for turbine auxiliaries, with targeted applications across power generation, oil & gas, and heavy industry.

In power generation, GE DS200CPCAG1ABB optimizes turbine auxiliary power. A 500MW gas turbine plant in Texas used it to regulate power to fuel valve actuators and cooling fan motors, its adaptive load management preventing overloads during peak demand—maintaining 99.5% availability. For hydroelectric facilities, a Canadian dam integrated GE DS200CPCAG1ABB to balance power across 6 gate valve control modules, reducing energy waste by 8%.

In the oil & gas sector, GE DS200CPCAG1ABB supports offshore and onshore operations. A Gulf of Mexico platform deployed it to manage power for compressor anti-surge valve controllers, with its EMI resistance preventing false shutdowns during storm-induced electrical noise—avoiding $350,000 in production losses. Onshore, a Middle Eastern refinery used GE DS200CPCAG1ABB to distribute power to crude transfer pump DCS modules, ensuring compliance with API 670 machinery protection standards.

In heavy industry, GE DS200CPCAG1ABB enhances manufacturing power stability. A German steel mill used it to control power for rolling mill motor drives, its precision regulation reducing motor wear by 20%. A U.S. paper mill relied on GE DS200CPCAG1ABB to manage power for pulp mixer control systems, cutting unplanned downtime by 15% through consistent power delivery.

Related Products

GE DS200TPSAG1A: Redundant 24V DC power supply that provides primary input power to GE DS200CPCAG1ABB, ensuring uninterrupted operation during single supply failures.

GE DS200IIBDG1AEA: Mixed-signal I/O module that receives regulated power from GE DS200CPCAG1ABB and processes sensor/actuator signals for the Mark V controller.

GE DS200CPCAG1AAA: Predecessor of GE DS200CPCAG1ABB with 6 output channels; suitable for smaller auxiliary systems or older Mark V firmware (≥5.1).

GE IS200BICLH1BBA: Bus interface module (for Mark VI/VIe DCS) that serves as a modern equivalent to GE DS200CPCAG1ABB in newer GE control systems.

GE IC660HHM501: Handheld monitor used to test power output accuracy and load balancing of GE DS200CPCAG1ABB, enabling on-site calibration.

GE DS200GDPAG1AHE: Generator protection module that uses power status data from GE DS200CPCAG1ABB to trigger shutdowns during critical power faults (e.g., sustained undervoltage).

GE DS200LDCCH1AKA: Load distribution hub that works with GE DS200CPCAG1ABB to expand power distribution capacity for large auxiliary systems.
